- Page 1 Angekis ASP-C-01 Digital Signal Processer Quick start guide(v1. 1 ) | EN Please refer this ducument before using.
-
Page 2: Product Overview
Product Overview This is a high quality audio mixing system, developed for use in lecture halls, meetings rooms, houses of worship, or any other large space that needs professional audio. It consists of a Digital Signal Processor main unit with phoenix terminals, 3.5mm and USB connectivity, as well as two HD voice hanging area microphones. -
Page 3: What's In The Box
What's in the box Digtal Signal Processer 2 x ceiling area microphones Ceiling microphone cables *2 (20m/pc) AEC cable *2 Speaker cable *2 (1.5m) (1.5m) Ty pe B USB cable *1 (1 .5m) Phoenix terminal Power adapter... -
Page 4: Installation
Installation sound console mic3 Ceiling mic1 USB cable UC Communication Power adapter Monitor earphone Recording box Speaker Ceiling mic 2 Note: 1. Single-ended signals can only be connected with "+" and "GND", but "-" can not be connected. 2. Dif ferential signals need to be connected with "+", "GND" and "-" 3. -
Page 5: Operation
Operation Audio connection method 1 ： Ceiling mic1 Power adapter Ceiling mic2 Speaker Audio connection method 2 ： Ceiling mic1 USB cable Power adapter Ceiling mic 2 Speaker... - Page 6 Operation Local amplification: mic3 Power adapter Speaker Local console usage: Ceiling mic1 Wireless microphone Speaker Power adapter Ceiling mic2...
- Page 8 Right click "Recording" to check whether "Angekis ASP-C-01" is the default microphone. If not, please click "Angekis ASP-C-01" and and set to default.
- Page 9 1 . R ight click the speaker icon at the bottom right of the screen, and then click "recording device". Display "recording device" interface. 2. C lick " A ngekis ”a nd properties. Display the "Properties" ASP-C-01 interface 3. C lick the levels tab to adjust microphone sensitivity in the microphone field...
- Page 10 Mac OS 1 . C lick the apple icon at the top left of the screen, and then click "system preferences " a nd "sound". Click”Recording”to check whether “Angekis -C-01 ”is the default microphone. If not, please click “Angekis "...
- Page 11 Attention 2.Click the output and input tabs respectively.To check if you have selected " from the device field. sound output and input as “Angekis ASP-C-01 " . If not, click"Angekis ASP-C-01 Angekis ASP-C-01 Angekis ASP-C-01...
