Summary of Contents for Ruijie Networks RG-EasyGate Series
- Page 1 RG-EasyGate Series Hardware Installation Guide V1.28 Hardware Installation Manual RG-EasyGate Series Products...
-
Page 2: Copyright Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused by content omissions, inaccuracies... - Page 3 RG-EasyGate Series Hardware Installation Guide V1.28 Preface Version Description This manual applies to EG series RG-EG1000C, RG-EG1000CM, RG-EG1000S, RG-EG1000L and RG-EG1000M gateways of Ruijie Networks. Readers This manual is suitable for the following readers: Network engineer Technology promotion personnel ...
- Page 4 RG-EasyGate Series Hardware Installation Guide V1.28 Note This installation manual only introduces how to install Ruijie EG series breakout gateway and the configuration guide of some commonly used functions. To further configure the breakout gateway, refer to the configuration guide and command reference document contained in the attached CD.
-
Page 5: Product Overview
Ruijie EG series breakout gateway employs the global-leading semiconductor technologies and communication control technologies, and is an independently developed data communication product of Ruijie Networks with independent intellectual property right. The breakout gateway products of Ruijie are completely developed as per international standards and are similar to the mainstream breakout gateway products in the international market. - Page 6 RG-EasyGate Series Hardware Installation Guide V1.28 One USB port. One reset button (RESET), which is on the right side of the serial port. There are seven LED indicators: PWR, SYS, USB, GE1, GE2, SFP1 LED Indicators and SFP2. Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX...
- Page 7 RG-EasyGate Series Hardware Installation Guide V1.28 Ruijie EG1000-CM Breakout Gateway Appearance of Ruijie EG1000-CM Breakout Gateway Figure 1-3 Front Panel of Ruijie EG1000-CM Breakout Gateway Figure 1-4 Backpanel of Ruijie EG1000-CM Breakout Gateway Basic Configuration of Ruijie EG1000-CM Breakout Gateway...
- Page 8 RG-EasyGate Series Hardware Installation Guide V1.28 Since there are numerous types of U-disk and SD cards, we cannot ensure that the system supports all of them. The Kingston 2G SD card and the 2G U-disk with FAT 32 are recommended to be used.
- Page 9 RG-EasyGate Series Hardware Installation Guide V1.28 Figure 1-6 Backpanel of Ruijie EG1000C Breakout Gateway Basic Configuration of Ruijie EG1000C Breakout Gateway Table 1-5 Basic Configuration of Ruijie EG1000C Breakout Gateway Item Description DDR2 SDRAM: 1 GB BOOTROM: 8 MB...
- Page 10 RG-EasyGate Series Hardware Installation Guide V1.28 For the RG-EG1000C product has the built-in hard disk, please avoid the vibration and collision in the process of moving and usage. When the EG series hosts are in hardware BYPASS mode, the two Ethernet ports connecting with the pair of BYPASS ports of the EG series products are directly connected via network cables actually.
- Page 11 RG-EasyGate Series Hardware Installation Guide V1.28 Basic Configuration of Ruijie EG1000S Breakout Gateway Table 1-7 Basic Configurations of Ruijie EG1000S Breakout Gateway Item Description DDR2 SDRAM: 2 GB BOOTROM: 2 MB Storage FLASH: 512 MB SATA Hard Disk: 320 GB Supports gateway mode (default) and bridge mode.
- Page 12 RG-EasyGate Series Hardware Installation Guide V1.28 When the EG series hosts are in hardware BYPASS mode, the two Ethernet ports connecting with the pair of BYPASS ports of the EG series products are directly connected via network cables actually. As a result, prevent them from being in the same VLAN to avoid broadcast storm.
- Page 13 RG-EasyGate Series Hardware Installation Guide V1.28 Basic Configuration of Ruijie EG1000M Breakout Gateway Table 1-9 Basic Configuration of Ruijie EG1000M Breakout Gateway Item Description DDR2 SDRAM: 4 GB BOOTROM: 8 MB Storage FLASH: 512 MB SATA Hard Disk: 320 GB...
- Page 14 RG-EasyGate Series Hardware Installation Guide V1.28 Voltage 100–240 V; 50–60 Hz Power Consumption Less than 100 W Temperature: 0°C to 45°C Working Environment Humidity: 10% to 90% RH (non-condensing) Since there are numerous types of U-disk and SD cards, we cannot ensure that the system supports all of them.
-
Page 15: Power Modules
RG-EasyGate Series Hardware Installation Guide V1.28 Copper Indicators Solid orange indicates the 10 M/100 M link that the port connects to is Blinking indicates data is being transceived at the port. The green in-position LED is on when the optical module is inserted. - Page 16 RG-EasyGate Series Hardware Installation Guide V1.28 about power temperature and output power. It is worth mentioning that the power temperature range is -5ºC–+50ºC (±2ºC). The temperature value would be incorrect if it is beyond that range. Features of Ruijie EG Series Breakout Gateway Full Support to Extensive Protocols ...
- Page 17 The independently developed Chinese URL database: The independently developed URL system will constantly collect URL information, and the URL database of Ruijie Networks is divided into 41 categories, with 6 million entries covering almost all websites in Mainland China.
- Page 18 RG-EasyGate Series Hardware Installation Guide V1.28 The transparent bridging does not change the configurations of other devices, allowing complete URL filtering, flow control and content auditing. The bypass mode ensures that the network is free from single point failure and will not affect network performance.
-
Page 19: Preparations Before Installation
Install and use the device in restricted access locations. Use of wrong battery may cause damage to the device. Do not replace the battery by yourself. Please contact the Customer Service Department of Ruijie Networks for help. Invite professionals and related technicians to install this type of device. -
Page 20: Temperature/Humidity Requirements
RG-EasyGate Series Hardware Installation Guide V1.28 Temperature/Humidity Requirements To ensure normal operation and prolong the service life of the device, the equipment room must maintain constant temperature and humidity. If the equipment room is overheated for a long time, the insulation materials may result in defective insulation and even electric leakage. -
Page 21: Anti-Static Requirements
RG-EasyGate Series Hardware Installation Guide V1.28 Average (mg/m3) Maximum (mg/m3) Sulfur dioxide Sulfured hydrogen 0.006 0.03 Nitrogen dioxide 0.04 0.15 Ammonia 0.05 0.15 Chlorine 0.01 Anti-Static Requirements The breakout gateway has already given consideration to electrostatic prevention during circuit design, but excessively strong static electricity will still damage the circuit board. -
Page 22: Installation Tools And Devices
RG-EasyGate Series Hardware Installation Guide V1.28 Make sure the cabinet and workbench is equipped with a good ventilation and cooling system. Make sure the cabinet and workbench is steady enough and capable of withstanding the weight of the breakout gateway and its accessories. - Page 23 RG-EasyGate Series Hardware Installation Guide V1.28 Installing the Breakout Gateway Installation Procedure of Breakout Gateway To avoid the damage of breakout gateway caused by rush or mal-operation during the installation process, install the device as per the following steps shown in Figure 3-1.
-
Page 24: Installing Power Cables
RG-EasyGate Series Hardware Installation Guide V1.28 Mounting into a Cabinet Ruijie breakout gateway products are designed based on the dimension of a standard cabinet. You can install the device with the enclosed fixing accessories. Mounting on a Workbench In most cases, the user does not have a standard cabinet. Instead, the user can place the device on a clean workbench. -
Page 25: Connecting Console
RG-EasyGate Series Hardware Installation Guide V1.28 Connecting Console Ruijie EG series breakout gateway provides an EIA/TIA-232 asynchronous serial console port, through which the user can complete the local configuration of the breakout gateway. The attributes of a console are shown in Table 3-1. In case of WEB based configuration, the console port will be of no use. - Page 26 RG-EasyGate Series Hardware Installation Guide V1.28 Starting and Configuring the Breakout Gateway Starting a Breakout Gateway Building Configuration Environment When the breakout gateway is used for the first time, you must configure the breakout gateway via the console port as...
- Page 27 RG-EasyGate Series Hardware Installation Guide V1.28 Figure 4-4 Select the Terminal Emulation Type...
- Page 28 RG-EasyGate Series Hardware Installation Guide V1.28 After building the configuration environment, you can then power on the breakout gateway. Powering on the Breakout Gateway Checks before Power-on Before power-on, perform the following checks on the breakout gateway: Whether the power cable and the ground wire are properly connected;...
-
Page 29: Starting Process
RG-EasyGate Series Hardware Installation Guide V1.28 Whether the LED indicators on the front panel of the breakout gateway works normally. Checking procedure: Refer to the section of indicators description about each product in the first chapter “Product Overview”. ... - Page 30 RG-EasyGate Series Hardware Installation Guide V1.28 The above startup information is for reference only. Breakout gateway with different hardware configurations or software versions will display different startup information. In case of using the breakout gateway for the first time, you are advised to use a configuration function to configure the basic parameters of the breakout gateway.
-
Page 31: Power Supply Troubleshooting
RG-EasyGate Series Hardware Installation Guide V1.28 Troubleshooting Power Supply Troubleshooting Ruijie EG1000C/EG 1000-CM/EG1000S/EG1000M/EG1000L breakout gateway provides a PWR LED on the front panel for indicating whether the power system works normally. Refer to “Product Overview” for the normal state descriptions of LED indicators.
