- Page 1 INfka015_US 331-006 Age for 18 months + Maximum Loading: 20kgs IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
- Page 2 PACKING DETALS:TOTAL 2 BOXES BOX-1/2 PARTS PARTS PARTS BOX-2/2 PARTS...
- Page 3 PACKING DETALS:TOTAL 2 BOXES BOX-2/2 PARTS PARTS PARTS...
- Page 4 PART 26+1 19+1...
- Page 5 PART ① ② ③ ④ ⑤ ⑥ ⑦ 16+2 ⑧ ⑨ ⑩ 1.Connect the long slide plate and 2.Install the slide length guardrail the short slide plate and tighten the M,N to one side of the slide. iron screws.
- Page 6 4.lnstall the slide plate and pedals 3.Install the slide length guardrail on a slide side plate, and tighten the M,N to one side of the slide. flower-shaped nut. 5.Install the corresponding hole on 6.Install the swing backrest, swing the other slide side plate and tighten side panels and swing armrests on the the flower-shaped nut.
- Page 7 ② ① ③ ⑤ ⑥ 10.Fix the football goal frame and the 11.Install the side panel of the football lifting column of the basketball board with goal under the door frame, connect the a ball rack pendant, and tighten the football baffle in the middle, and tighten screws.
