Arktek YBC-10 User Manual

Solar direct drive refrigerator

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

This manual is described in English, if other languages are required， please contact the

manufacturer or service provider or visit the Website: www.aucmaglobal.com.cn and Email for ：

info@aucma.com.cn

Caution: Read this entire manual carefully

before using the product. Store this manual in a

safe and accessible place for later reference as

necessary.

Solar Direct Drive Refrigerator

User Manual

YBC-10

Rev. 202102

Table of Contents

Need help?

Do you have a question about the YBC-10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arktek YBC-10

Page 1 This manual is described in English, if other languages are required， please contact the manufacturer or service provider or visit the Website: www.aucmaglobal.com.cn and Email for ： info@aucma.com.cn YBC-10 Solar Direct Drive Refrigerator User Manual Caution: Read this entire manual carefully before using the product.
Page 2: Table Of Contents
Specifications........................3 Safety Precautions......................4 PARTS OVERVIEW ........................5 INSTALLATION ...........................6 Preparation ........................6 Positioning the Device .....................6 USE OF THE YBC-10 ........................7 Cool Down.........................7 Cool Down.........................7 Daily Use ...........................7 Electronic System ......................11 MOVE AND TRANSPORT INSTRUCTIONS ................14 CLEANING AND STORAGE ..................... 15 Cleaning..........................
Page 3: Introduction
The Device The YBC-10 SDD refrigerator (Figure 1) is designed to safely store vaccines only using the energy from the sun. It can maintain stable 2 °C to 8°C storage.
Page 4: Device Features
• Easy to use and maintain. (simple, safe, robust and reliable) • Specifications ITEM SPEC Model identifier YBC-10 Alpha-numeric designation Alpha-numeric designation Ambient Temperature 5°C to 43°C Expected conditions of surrounding environment of use Vaccine storage temperature range 2°C to 8°C...
Page 5: Safety Precautions
Safety Precautions (To ensure your safety, please read this section carefully) Appliance is rated for use with specified solar panel. (For details, See Solar Panel Instruction • Manual ,it is packed in plastic bags with the user manual and placed in the device) Use reliable grounding that is not connected to any grid, heating pipe, gas pipe, etc.
Page 6: Parts Overview
PARTS OVERVIEW...
Page 7: Installation
INSTALLATION Preparation Read the user manual carefully. • Remove all packaging material, including the foam base and tape. • Note: Discard plastic wrappers and bags safely, to avoid suffocation of children . Note: Discard plastic wrappers and bags safely, to avoid suffocation of children . Check that all parts are not damaged.
Page 8: Use Of The Ybc-10
USE OF THE YBC-10 Check the temperature display daily and make sure the inner temperature is between 2 °C to • 8 °C before using for vaccine storage . Keep vaccine cap tightly closed and latched when not in use to maintain the storage •...
Page 9 Figure 2: Removing the stacks Removing the stacks 1. Unlatch and remove the cap from the device. 2. Remove the stack in the middle first. 3. Remove other stacks one by one. 3. Remove other stacks one by one. 4. Replace and latch the cap. Loading the stacks 1.
Page 10 Figure 4: Loading cup stack with Loading cup with vaccines vaccines Note: Foam protective pads and plastic dividers can be • used to organize them. Vaccines can be placed in the cups vertically or horizontally. Do not overfill the vaccine cups. Leave gaps between vials and cups to enable cold air circulation.
Page 11 4. Moving quickly (on a flat work surface) twist apart the cup stacks and lids. 5. Place the current day’s supply of vaccines into the day use container. 6. Twist to reconnect the containers and lids into stacks, placing the day use container at the top of one of the stacks.
Page 12: Electronic System
Electronic System The electronic system provides different functions. Please read this section carefully. Display Power state • Temperature state • Running state • Time, Date • Alarm Out-of-range temperature alarm • Abnormalities alarm • Charging • Data export Data export •...
Page 13 Power state (Press “SET “and choose “View Powers”) Panel power. TECs power, Fans power, Battery voltage. • Setting Choose “Silence Alarm” to close the (Press “SET” and alarm sound. choose “Settings”, Input passcode “1234”) Choose “Set Clock” to set the time and date.
Page 14 Out-of-range temperature alarm • The device will alarm when the inner temperature is out of range. If the temperature is below 2°C or above 8°C, the device's alarm will sound. List of alarm state: State State Power supply Power supply Audible alarms Audible alarms Error code...
Page 15: Move And Transport Instructions
MOVE AND TRANSPORT INSTRUCTIONS The device must be kept upright when loaded with ice and/or Figure 7: Lifting the device vaccines. Do not drop or roll the device. Keep the cap on and latched securely. This will help to prevent damage to the vaccines and the device.
Page 16: Cleaning And Storage
CLEANING AND STORAGE Cleaning Note: For safety reasons, worker should turn off the power switch before starting the cleaning work. Do not use wet cloth to wipe any electrical parts or touch any electrical components (such as plugs, switches, etc.) with wet hands in order to avoid electric shock. The exterior of the device can be cleaned as needed.
Page 17: Condensate
To clean the solar panel The front of the solar panel must be cleaned every week or when necessary in dusty areas. Use water and soft rag to clean. Do not use corrosive solvents. You need to use a duster as primary tool when it’s not easy to get (on the pole).
Page 18: Troubleshooting
TROUBLESHOOTING Record any issues that you encounter and any related solutions that you have attempted. You play a very important role in identifying potential recurring issues and solution s. There are several types of trouble codes in different conditions. Please call the customer service for help when you find the following codes.
Page 19: Disposal And Recycle Consideration
DISPOSAL AND RECYCLE CONSIDERATION Waste treatment methods Disposal must be made according to local regulation . II. Recommendation 1. Tank, plastic, electronic parts, lithium battery and others parts disposal must be made according to local regulation. 2. The vacuum tank sealed tube removal or drilling in the tank shell to prevent use for 2.
Page 20: Warranty
WARRANTY To facilitate inquiries, please copy the model number and serial number in the following table. Model To avoid losing the invoice, you can affix it to this page. To avoid losing the invoice, you can affix it to this page. (Paste or staple your invoice here.) Warranty Information Thank you for using the device.
