SCHEIDT & BACHMANN SV|51 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Fare collection
systems
Customer Documentation
State: December 2017
SV|51
Edit: Stevens
Art.#.: 86 -----, Version: 1.02
Date:13.12.2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV|51 and is the answer not in the manual?

Questions and answers

Summary of Contents for SCHEIDT & BACHMANN SV|51

  • Page 1 Fare collection systems Customer Documentation State: December 2017 SV|51 Edit: Stevens Art.#.: 86 -----, Version: 1.02 Date:13.12.2017...
  • Page 2 This manual, including all of its component parts, is copyright protected. Scheidt & Bachmann GmbH reserves all rights to its contents. Any use not expressly approved by copyright law is subject to prior approval by Scheidt & Bachmann GmbH. This applies particularly to copying, processing, translations and microfilming, as well as to storage and data processing in any electronic systems.

  • Page 3: Table Of Contents

    Systeme für Fahrgeldmanagement Chapter 1 Introduction and Safety SV|51 Description .................. 1-5 1.1.1 Components ......................1-5 Overview....................1-5 Safety Features ..................1-6 Protective Equipment................1-8 Special Tools..................1-8 1.5.1 Warning Symbol ....................... 1-9 1.5.2 Caution Symbol ......................1-9 1.5.3 Information Symbol....................1-9 1.5.4...
  • Page 4 Tools Required ....................... 4-39 4.1.8 Mounting the base plate ..................4-40 4.1.8.1 Drilled solution....................4-40 4.1.9 SV|51 Provisioning Prerequisites ................. 4-49 4.1.9.1 Technical Specifications................. 4-50 Chapter 5 Module Removal Module Removal ................. 5-51 MicroSD Card Removal and Replacement ........5-55 Tools and Consumables ..............

  • Page 5: Chapter 1 Introduction And Safety

    Introduction and Safety systems Chapter 1 Introduction and Safety 1.1 SV|51 The SV|51 Station Platform Validator is a device with read and write capabilities Description with contactless smartcards. The SV|51 will be floor mounted. 1.1.1 Components The SV|51 is comprised of six main components as shown below (Figure 5): Base Plate ...

  • Page 6: Safety Features

    Chapter 1 Introduction and Safety Full documentation that would be needed by maintenance personnel is available through Scheidt & Bachmann. The manual assumes that comprehensive repair procedures will be performed by fully trained contractor technicians. This manual reflects Scheidt & Bachmann’s commitment to providing our cus- tomers with comprehensive technical documentation, along with training guide- lines to augment our customer training program.
  • Page 7 Chapter 1 Fare collection Introduction and Safety systems Close attention to proper safety precautions is of the utmost importance. Com- ponents should be installed, maintained, and repaired only by trained, qualified personnel using reasonable care. Improper installation, maintenance, or repair procedures may damage the machine or cause serious personal injury or death.

  • Page 8: Protective Equipment

    Chapter 1 Introduction and Safety General This chapter provides the technician with the safety information necessary to Safety Guide avoid personal injury or equipment damage. Only qualified, trained technicians using reasonable care should perform maintenance or repair. As with any mechanical system, the AFC components can pose certain safety hazards.

  • Page 9: Warning Symbol

    Chapter 1 Fare collection Introduction and Safety systems Use of Symbols for cautions and warnings are used frequently throughout this manual. Symbols in Each symbol appears on the left side of the page with the associated text printed Manual to the right. There are several different types of symbols that indicate varying levels of safety hazards.

  • Page 10: Hot Hazard Symbol

    Chapter 1 Introduction and Safety This symbol indicates a TOOL is required to perform the task described in the text. 1.5.7 Electrical The Electrical Hazard Symbol indicates the potential for serious damage to the Hazard Symbol machine caused by electrical voltage surges or serious injury to the service tech- nician caused by electrical shock.

  • Page 11: Labels On Inside Of Most Afc Enclosures

    Chapter 1 Fare collection Introduction and Safety systems 1.6.1 Labels On There are several labels used on the assemblies located on the inside of the typ- Inside Of Most ical AFC device enclosure. These labels and their meanings are described below.

  • Page 12: Tüv Süd Nrtl Label

    Chapter 1 Introduction and Safety HVIN:SV51 FCC ID: O5K-NVP IC: 8312A-NVP Figure 1-4 FCC-License 1.6.1.4 TÜV SÜD The TÜV-SÜD-NRTL label shown in Figure 1-5 appears on the backside of the NRTL Label device. Figure 1-5 NRTL-Label 1.6.1.5 Electrical The Electrical Hazard label shown in Figure 1-6 appears on or near certain Hazard Label components located inside the device door and/or enclosure.
  • Page 13 Chapter 1 Fare collection Introduction and Safety systems Figure 1-8 Electrical Hazard Label used for the MEM 1.6.1.6 Hot Surface The Hot Surface label shown in Figure 1-9 below is used on the heater/blower Label unit to indicate the possibility of burns when touching the heater/blower unit. This label can also be found where other heat or burn hazards may exist.
  • Page 14 Chapter 1 Introduction and Safety THIS PAGE INTENTIONALLY BLANK. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 1-14...

  • Page 15: Glossary Of Terms And Abbreviations

    Chapter 2 Fare collection Glossary systems Chapter 2 Glossary 2.1 Glossary of Many terms and abbreviations are used to describe Fare Collection Equipment. Terms and Some are Automated Fare Collection (AFC) industry standard terms, some are application-specific, such as networking and telecommunications terms, and Abbre- some are unique to the customer’s system.
  • Page 16 Chapter 2 Glossary ANSI American National Standards Institute Application Server NT-based server which runs the Central Com- puter System Application processes APTA American Public Transportation Association ASCII American Standard Code for Information Inter- change Audio Speaker A speaker that broadcasts messages in the lan- guage of choice with content similar to the mes- sage on the customer display.
  • Page 17 Chapter 2 Fare collection Glossary systems Command Codes See “Service Command”. Commuter Rail Server A computer system that acts as a data conduit between the Central Computer System (CCS) and the Station Controllers at commuter rail stations. COTS “Commercial Off The Shelf “equipment Central Processing Unit Cyclic Redundancy Check.
  • Page 18 Chapter 2 Glossary Error Codes Also called an error message, which is gener- ated automatically when a particular set of abnormal conditions occurs. Error information concerning a system fault or equipment mal- function can be viewed on the Customer Dis- play, Service Terminal Display, or on a printed report.
  • Page 19 Chapter 2 Fare collection Glossary systems Abbreviation for Hard Disk Heater The heater is located in the bottom of the AFC machine housing. It provides heat when acti- vated by a thermal sensor. Also, see Heater/ Blower Unit (HBU). Heater/Blower Unit The Heater/Blower Unit (HBU) is activated by an environmental temperature sensor, which is typically located above the ECU Main Com-...
  • Page 20 Chapter 2 Glossary Keyboard The keyboard is used by the user to enter data into the system. KiloHertz – a measure of frequency equal to one thousand Hertz (cycles per second) See “Local Area Network”. Language Marker Displays the language the device is equipped with.
  • Page 21 Chapter 2 Fare collection Glossary systems Abbreviation for Message Authentication Codes. An mAh is a milliampere-hour. It is one thou- sandth of an ampere-hour and is commonly used as a measure of charge in batteries. An ampere-hour is the amount of energy charge in a battery that will allow one ampere of current to flow for one hour.
  • Page 22 Chapter 2 Glossary NEMA National Electrical Manufacturers Association Network Interface Card The Network Interface Card (NIC), installed in the ECU, provides an Ethernet-based commu- nications interface between an AFC machine and the Local Area Network (LAN). Network Interface Card. Adapter for LAN Noise Extraneous or interfering signals present on a system caused by undesirable voltages or cur-...
  • Page 23 Chapter 2 Fare collection Glossary systems PCMCIA See “Personal Computer Memory Card Inter- national Association”. PCMCIA Personal Computer Memory Card International Association. In the TSMs it is used as a flash card for data transfer. See “Portable Data Unit”. Permit A fare media element issued to a specific per- son that identifies that person as authorized for a reduced fare or adjustment.
  • Page 24 Chapter 2 Glossary Process System Interface The Process System Interface (PSI) is a soft- ware process that both controls a hardware component and interprets its state. This pro- cess is specific to each hardware component. The PSI, which is responsible for communica- tion between separate software modules, oper- ates independently of the operating system.
  • Page 25 Chapter 2 Fare collection Glossary systems Service Display See “Service Terminal Display”. Smart Card Reader A device that reads the encoded value stored on a smart card. SONET See “Synchronous Optical Network”. Sound Card The Sound Card, located in the ECU Main Computer, provides voice messages for the speaker and head phone jack, when available.
  • Page 26 Chapter 2 Glossary Touch Controller Monitors the AFC Machine Customer Display touch screen panel. Reports the results of data input (screen touches) to the Application Soft- ware. (Applies only to systems equipped with Touch Screen devices.) Touch Screen A Touch Screen is the component part of the Customer/Agent Display that detects user input by sensing a touch (or tap) on specific areas of a surface wave-sensitive touch panel.
  • Page 27 Chapter 2 Fare collection Glossary systems Wide Area Network (WAN) Spanning a country or continent, a Wide Area Network is a communication network that serves geographically separated areas and locations. Workstation PC within a network serving as a control, input, or monitoring device.
  • Page 28 Chapter 2 Glossary THIS PAGE INTENTIONALLY BLANK. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 2-28...

  • Page 29: Chapter 3 Declaration Of Conformity

    Declaration of Conformity systems Chapter 3 Declaration of Conformity 3.1 Europe The device complies to the European Directive RED 2014/53/EU The SV51 use the following radio frequencies in Europe Characteristic Specification Radio frequency: 2400 - 2483.5 MHz Transmission power: 49 mW...

  • Page 30: Usa/Canada

    Chapter 3 Declaration of Conformity 3.2 USA/ NOTICE: CANADA This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2.

  • Page 31: Chapter 4 Installation And Initialization

     original packaging and Scheidt & Bachmann wrapping. The SV|51 device is installed in locations chosen by the Transit Authority.  The SV|51 is a device that is able to read and write to contactless  smartcards. NOTE: Placement of the SV|51s is at the discretion of the customer.
  • Page 32 Power Supply Base Plate Figure 4-11 The Union Pearson Express Station Fare Transaction Processor The safety labels shown in the section Machine Safety Labels must be followed. Review them carefully before proceeding.SV|51 Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017...
  • Page 33 Approximately 38W Table 4-3 Power Consumption In the event of a power failure, the SV|51 will perform an orderly shutdown based on the energy stored in local capacitors. When power is restored, the SV|51 will start up and return to full operation without the need for manual intervention.
  • Page 34 Gepr. 09.06.17 Norm 09.06.17 --.--.-- Zust. Datum Bearb. Gepr. Norm Blatt/Anzahl 86 35967 0 - Scheidt & Bachmann GmbH D-41238 Mönchengladbach Figure 4-12 Block Diagram SV|51 Page 1 of 2 Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 4-34...
  • Page 35 09.06.17 Gepr. 09.06.17 Norm 09.06.17 --.--.-- Zust. Datum Bearb. Gepr. Norm Blatt/Anzahl 86 35967 0 - Scheidt & Bachmann GmbH D-41238 Mönchengladbach Figure 4-13 Block Diagram SV|51 Page 2 of 2 Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 4-35...
  • Page 36 Chapter 4 Installation and Initialization Column The SV|51 column provides two options for conduit entry ( Figure 4-14). The Variations/ first is at the bottom through the mounting plate. The second is through an open- Conduit Entry ing provided at the rear of the SV|51 column. The PRESTO customized opening has a height of 70 mm and width of 30 mm with a rounded top.

  • Page 37: Drilling Into Concrete

    This method assumes the Transit Agency prepared a concrete surface. Drilling Concrete four holes into the concrete and securing four bolts in these holes allows these bolts to hold the SV|51 in place. This method may utilize either the bottom or side fed conduit entry options. 4.1.3 Adhesive The adhesive option utilizes a floor plate that has four pre-installed bolts.

  • Page 38: Bottom Conduit Entry

    SV|51 baseplate ( Figure 4-16). The conduit lengths must be a minimum of 130mm from bottom of SV|51 column. A minimum length of 300mm of power cable and 600mm of data cable must be available from the bottom of SV|51 col- umn.

  • Page 39: Bill Of Materials

    Scheidt & Bachmann will provide one set of items listed in the Bill of Materials ( Table 4-4) with each SV|51. 4.1.6 Bill of Materials The items in Table 4-4 will be included as part of the SV|51 Bill of Materials. Part Name S&B p/n...

  • Page 40: Drilled Solution

    Chapter 4 Installation and Initialization 4.8.1 SV|51 The following steps demonstrate how to install a SV|51. It is assumed that the Installation conduit requirements have been met prior to the first installation step below: Steps Drilled Solution: four bolts should be permanently fixed into holes drilled ...
  • Page 41 Chapter 4 Fare collection Installation and Initialization systems 4.8.1.1 Adhesive Place the base plate on the floor plate; ensure the four bolts pass through the solution middle screw openings on the base plate. Use a wrench to secure the base plate on the concrete/floor plate by means of a washer and a nut for each of the four bolts as shown in blue in Figure 4-17.
  • Page 42 The Power Supply Mount secures the power supply Junction Box to the base Base Plate plate inside the SV|51 housing ( Figure 4-18). Assemble the Power Supply Mount on the level base plate using two hexagonal screws and tighten. Figure 4-18 Power Supply Mount Edit: Stevens Art.#.: 86 -----, Version: 1.02...
  • Page 43 Chapter 4 Fare collection Installation and Initialization systems Screw Junction Box Screw Figure 4-19 Power Supply Junction Box Mounted Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 4-43...
  • Page 44 Chapter 4 Installation and Initialization 4.8.3 Connecting Cables STEP 1: Switch off main circuit breaker. STEP 2: Open the Power Supply Junction Box by removing the twelve screws and the cover. Set aside the screws. The cable entry into the device must be mechanically strain-relieved. When the cable is pulled out, the connection of the protective earth conductor must be established / existing until the end.
  • Page 45 Note that the power supply is delivered with this Ethernet Cable already mounted. The other side of the pre-installed cable will be connected to the back of the SV|51 main unit. Replace the cover of the Power Supply Junction Box and secure it using the twelve screws previously set aside.
  • Page 46 Chapter 4 Installation and Initialization 4.8.4 Mounting the Column to the Base Plate STEP 1: Place the column onto the base plate such that the lower side of the column aligns with back side of the power supply unit. Figure 4-22 Orientation of the Column with Respect to the Power Supply Unit STEP 2: Ensure that the four outer screw openings on the base plate are aligned with the screw openings on the welded mounting plate attached to the bottom of the column.
  • Page 47 The adapter ring has eight holes, four of which are used for the floor mount solu- Adapter Ring tion and the other four are included for a potential wall-mounted SV|51. Figure 4-23 shows the orientation of the adapter ring on the column and the four holes that are used for the floor mount solution.
  • Page 48 STEP 2: Hold the SV|51 on top of the adapter ring STEP 3: Align the four Mushroom Screws on the back of the SV|51 with the appropriate holes in the adapter ring. STEP 4: Slide the validator down to secure it on top of the adapter ring.

  • Page 49: 51 Provisioning Prerequisites

    Chapter 4 Fare collection Installation and Initialization systems Initialization 4.1.9 SV|51 The following are the prerequisites for device provisioning: Provisioning New Device with the required firmware already installed  Prerequisites Personalized SAM card installed in the Device  Device is connected to the Production network/environment ...

  • Page 50: Technical Specifications

    IP 54 (dust protected but not tight / splashing  water from all directions) IP rating (ingress protection) The SV|51 pole is not water tight, but the  power supply is (NEMA3) IK 10 for option without buttons (20 Joule = 5 ...

  • Page 51: Chapter 5 Module Removal

    4.1.4 Side Conduit Entry or 4.1.5 Bottom Conduit Entry. If there is not enough slack in the wires, as specified in the Installation Procedures, alternative steps must be followed. See “Alternative Procedure” on page 57. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 5-51...
  • Page 52 Module Removal 5.9.1 Main Unit The drawing in Figure 5-26 illustrates how to open the SV|51 and remove the main unit. STEP 1: Use the key to unlock the device. STEP 2: Slide the main unit up and then pull up and away to disconnect it from the stainless steel column.
  • Page 53 Chapter 5 Fare collection Module Removal systems 5.10 Accessing the After removing the main unit as described in section 5.9.1, it is necessary to Power Supply access the power supply junction box. Use Figure 5-27 for reference. STEP 1: Loosen the two screws attaching the power supply junction box to the power supply mount.
  • Page 54 The drawing in Figure 5-28 shows how to replace the fuses in the main unit of Replacement the SV|51. STEP 1: Remove the main unit as described in section 5.9.1 and the power supply junc- tion box as described in section 5.10.

  • Page 55: Microsd Card Removal And Replacement

    Chapter 5 Fare collection Module Removal systems STEP 10: Lock the device. Figure 5-29 MicroSD Card Removal 5.2 MicroSD The drawing in Figure 5-29 shows how to remove and replace the MicroSD Card in the main unit. Card Removal and Replacement STEP 1: Remove the main unit as described in section 5.9.1.
  • Page 56 Device or Component Name Part Number SV|51 main unit 86 XXXX Lock 86 XXXX 86 XXXX MicroSD Cards 51 03826 or local purchase Table 5-5 Part Numbers Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 5-56...
  • Page 57 Chapter 5 Fare collection Module Removal systems 5.11 Alternative If there is not enough slack in the wires to follow the preferred procedure for Procedure removing the power supply, follow these steps. STEP 1: Turn off power at the main facility breaker before proceeding. STEP 2: Remove the main unit as specified in 5.9.1 STEP 3: Remove the stainless steel column.
  • Page 58 Chapter 5 Module Removal THIS PAGE INTENTIONALLY BLANK. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 5-58...

  • Page 59: Chapter 6 Preventive Maintenance

    6.1 General The following general preventive maintenance procedures are for the overall Maintenance maintenance and cleaning of the SV|51. This includes testing and validating the equipment to ensure proper operation. During this Preventive Maintenance pro- and Cleaning cess, notify the Network Control Administrator that alarms may be triggered.

  • Page 60: Materials And Replacement Parts

    Every Three Months Cleaning and Visual Section 6.2.1 Inspection of the Interior 6.2 Materials and Table 6-7 provides a complete list of the materials and replacement parts Replacement needed to perform preventive maintenance on the SV|51. Parts ITEM DESCRIPTION WHERE USED Canned Air...

  • Page 61: Cleaning And Visual Inspection Of Interior

    Inspection of Interior STEP 1: Remove any foreign materials from the inside of the SV|51 (see section 6.2). STEP 2: Use canned air to remove small particles from the interior of the SV|51. STEP 3: Clean the interior surface of the SV|51 Housing with alcohol.
  • Page 62 Chapter 6 Preventive Maintenance THIS PAGE INTENTIONALLY BLANK. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 6-62...

  • Page 63: Chapter 7 Ipc

    Chapter 7 Fare collection systems Chapter 7 7.1 IPC Pages IPC in this chapter give the customer an overview of the SV|51. Figure S&B Part Part Description Available as Item Number Spare Part 86XXXX Functional Unit 0371705 Housing 0371292 Welded...
  • Page 64 Chapter 7 THIS PAGE INTENTIONALLY BLANK. Edit: Stevens Art.#.: 86 -----, Version: 1.02 Datum:13.12.2017 7-64...
