- Page 1 Doc. No. Y054277 (EN - Rev. 002) May 2022 USER MANUAL TIM G2 Trailer Information Module...
- Page 2 The information contained in this document is intended for the exclusive use of trained persons within the commercial vehicle industry, and must not be passed on to any third party. All recommendations regarding products and their servicing or usage are with reference to Knorr-Bremse products and should not be considered applicable to products from other manufacturers.
-
Page 3: Table Of Contents
» User Manual - TIM G2 Trailer Information Module CONTENTS Safety and Environment Guidelines 1 Navigation Buttons and Functionality Navigation Buttons Cursor Function display 2 Behaviour with Ignition on / off Ignition on Ignition off 3 Examples Setting next service distance to 10,000 km... -
Page 4: Safety And Environment Guidelines
The use of impact screwdrivers or impact wrenches in conjunction with Knorr-Bremse service tools for air disc brakes is not permitted. The service tools are not designed for such use. It is likely that the tools or the vehicle will be damaged and there is a serious risk of injury – see Caution above. - Page 5 » User Manual - TIM G2 Trailer Information Module Welding To avoid damage to electronic components when carrying out electrical welding, the following precautions should be ob- served: In all cases, before starting any electrical welding, remove all connections from any electronic control units or modules, noting their position and the order in which they are removed.
- Page 6 » Y054277 – (EN - REV. 002) | MAY 2022...
-
Page 7: Navigation Buttons And Functionality
» User Manual - TIM G2 Trailer Information Module NAVIGATION BUTTONS AND FUNCTIONALITY Navigation Buttons Moves menu cursor down Short hold jumps down one position, long hold jumps to end of list (Exit) Moves menu cursor up Short hold jumps up one position, long hold... -
Page 8: Behaviour With Ignition On / Off
» Y054277 – (EN - REV. 002) | MAY 2022 BEHAVIOUR WITH IGNITION ON / OFF Ignition on Ignition on – Display activates automatically, all configured menus are available KNORR-BREMSE TEBS G2 Initial Menu Srv Km: 10000km DISCLAIMER Load Rear:... -
Page 9: Examples
» User Manual - TIM G2 Trailer Information Module EXAMPLES Setting next service distance to 10,000 km Main Menu Stored Faults Distance & Serv. Operating Info System Info Srv Km: 10000km Save & Exit Exit Srv Date: 27-09-99 Srv Km:... -
Page 10: Changing The Language Default (English To German)
» Y054277 – (EN - REV. 002) | MAY 2022 EXAMPLES Changing the language default (English to German) Main Menu System Info ECU Info Tim Info Exit Sprache: Deutsch Screenbild: Lade Set LCD Kontrast Lang.: English Hersteller Info Scr Saver: Load Set LCD Contrast Manufacturing Info... -
Page 11: Ilvl Configurtion
Set Mem1 level Setting the drive level will change the shown text on the TIM G2 display e g : Set Drive1 level will change to Setting Drive1…; As soon as the set level is active the text will be reset to original text: Set Drive1 level! -
Page 12: Setting Pre-Configured Drive Or Memory Levels
Set Mem1 level • • • Setting the memory level will change the shown text on the TIM G2 display Set Mem1 level will change to Setting Mem1…; As soon as the set level is active the text will be reset to original text: Set Mem1 level! -
Page 13: Tim G2 Default Structure
TIM G2 Default structure Adjust TIM G2 Default structure By using the ECUTalk® for TIMG2 the user is able to adjust and configure the TIM G2 menu structure: Make sure that ECUTalk® for TIM G2 is installed on your device Installation will be shown in the ECUTalk®... -
Page 14: Menu Overview
» Y054277 – (EN - REV. 002) | MAY 2022 Menu overview Initial Menu Main Menu Repeat until Trailer Information Module Trailer Information Module “Main Menu” LL switched Off Stored Faults <Active faults> Distance & Serv. ODO: Operating Info Srv.Km: 10000km System Info LL switched Off *... - Page 15 » User Manual - TIM G2 Trailer Information Module NOTES...
- Page 16 The information contained herein is subject to alteration without notice and therefore may not be the latest release. Please check our website truckservices.knorr-bremse.com for the latest update or contact your local Knorr-Bremse representative. The figurative mark “K” and the trademarks...
