www.starling-tech.com
Instruction Manual
Warning : Protect Board from electrostatic discharge. Ground yourself before handling.
Protect bottom of board from shorting against anything metal.
Read Entire Manual Before Starting Your Project.
Thank you for purchasing the Pocket Spin Drift lighting kit from Starling
Technologies™.
From the 1960's Irwin Allen Hit Series " Land of the Giants," we've produced a
Plug-N-Play light kit for the Moebius Pocket Spindrift.
Our highly efficient Light kit features pulsing Intake, as seen in the show, engine and interior
lighting, all running off a single CR2032 or CR2025 button cell battery. Runs continuously for
hours with our low power circuit.
Kit features our "No Show" switch design, no external wires or switches, kit uses a magnet
with reed switch to power-on, allowing you to handle the model without a stand.
Built In The U.S.A with top quality components for longevity and long lasting battery life.
Kit Includes:
1x Fully assembled Plug-N-Play Pocket Spindrift board and lighting kit.
With red LEDs soldered to board, with wired reed switch and 2032 battery socket.
1x white LED light panel to illuminate interior of ship.
1x 1/4" magnet
1 PDF manual emailed after purchase.
1
Advertisement
Table of Contents
Related Manuals for Starling Technologies Pocket Spin Drift
Summary of Contents for Starling Technologies Pocket Spin Drift
- Page 1 Protect bottom of board from shorting against anything metal. Read Entire Manual Before Starting Your Project. Thank you for purchasing the Pocket Spin Drift lighting kit from Starling Technologies™. From the 1960's Irwin Allen Hit Series “ Land of the Giants,” we've produced a Plug-N-Play light kit for the Moebius Pocket Spindrift.
- Page 2 Required No soldering required CR2032 or CR2025 battery (Energizer or Duracell recommended for longer life) Normal modeling tools and paints. Xacto knife. Drill bits. Clear polystyrene sheet(optional) Clear epoxy, model glue of choice ParaGrafix Pocket Spindrift photo-etch(Optional) You can drill out the grill holes and light block instead. Battery installation and removal: Caution!! Do not install battery incorrectly.
- Page 3 You can use handiTak reusable adhesive to hold things down while you test everything out. Adjust your LEDs by bending outward and up or down to light the intakes. The rear of the LEDs will provide light for the glowing engines. Position the LED light panel on the upper cockpit section.
- Page 4 paper interior. Make sure you place it where the magnet,that will attach on the outside, will not be noticeable. You can leave it loose or glue it into position. Note: If you leave it loose, you will have more room to extend the wire when replacing battery.
- Page 5 I also added aluminum tape to the back of the paper interior to direct light back to the engines. You may either drill the holes in the grills or use ParaGrafix photo-etch. Follow their instructions for prepping the parts. You may use .015” or thinner clear polystyrene sheet to place behind the grills. Use clear flat acrylic paint or sand paper to diffuse the light.
- Page 6 Photo1 side 1 painted Photo2 side2 unpainted. LED Panel light : if you are using all white to light the cockpit and the rest of interior, peel the white film from the LED Panel and paint it all white. This will reflect the light better below. Blue Cockpit lighting: If you want the cockpit a little blue lighting, do as above, but paint the end that hovers over the cockpit,facing down, clear blue acrylic mixed with future floor polish.
- Page 7 If you install one of these new batteries and yourwhite Lights fade off from the start, the battery is defective. All photos contained in this document are property of Starling technologies. This document may not be copied, sold or transferred without permission.
