DORLAND

Industrial Intrinsically Safe Mobilephone TEV8

User Manual

Welcome

Thanks for purchasing the TEV8 series color screen mobile phone. Please read this user guide

to understand the operation of this device and appreciate its perfect functions and simple

operation methods.

This mobile phone is a bar phone designed for GSM/GPRS network. Besides basic

communication functions, it provides you 11 languages input method, phonebook,

personalized 64-chord ring tones, caller ring tone, caller picture, camera, MP3 player, video

player, U-disk, recorder, calculator, schedule power on/off, GPRS service, MMS, hands-free

communication, etc, providing convenience for your work and entertainment. Allow you to

understand the operation of the mobile phone completely with this user guide.

The TEV8 color screen mobile phone accords with the GSM Technical Specification and are

approved by domestic and foreign authoritative organizations.

The contents of this user guide are subject to changes without prior notices.

Table of Contents

Need help?

Do you have a question about the TEV8 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DORLAND TEV8 Series

Page 1 Industrial Intrinsically Safe Mobilephone TEV8 User Manual Welcome Thanks for purchasing the TEV8 series color screen mobile phone. Please read this user guide to understand the operation of this device and appreciate its perfect functions and simple operation methods. This mobile phone is a bar phone designed for GSM/GPRS network. Besides basic...
Page 2: Table Of Contents
Contents General Notices ........................ 2 1. About the device ......................3 2. About the battery ......................3 3. About the charger ......................4 4. Cleaning and maintenance ..................5 Getting Started ......................... 5 1. The battery ........................5 2. Connecting to the network ..................5 Handset appearance ......................
Page 3: General Notices
Safety Instructions  If your device is lost or stolen, please contact your service provider or a sales agent immediately to restrict your SIM card from being used. This will prevent economic loss caused by unauthorized calls made from your mobile phone. ...
Page 4: About The Device
 Do not impacts, shake, or throw your device violently, avoiding it from malfunction or a fire.  Do not place the battery, mobile phone, or charger in a microwave oven or high-pressure equipment. This may lead to unexpected accidents such as damage to the circuitry or fire.
Page 5: About The Charger
 Do not short-circuit the battery with metal objects like electrical wire and needles. Do not put the battery and metal objects together. This may cause the battery to leak, overheat, crack, or catch fire.  Do not solder the contact points of the battery. This will cause the battery to leak, overheat, crack, or catch fire.
Page 6: Cleaning And Maintenance
fire.  Do not charges in high temperature environment like direct sunlight, moist or humid, dusty places or places with excessive vibration, which may cause failure; or near appliances, such as televisions and radios, as the picture and sound effect may be affected.
Page 7 2.1SIM card Please insert a valid SIM (subscriber identity module) card into the phone before use. Everything about setting connection to the network is saved in the SIM card, together with the information of contacts’ names and phone numbers in Phone Book as well as messages. Do not touch the metal surface of the card in case that information in the card may be lost or destroyed.
Page 8: Handset Appearance
After the SIM card is unlocked, the mobile phone will automatically search for the network and the screen displays a searching mark. Once connected, the name of the network provider appears at the central top of the text and image area. Now you are registered on the network. Note: The prompt of “SOS”...
Page 9: Basic Features
Basic Features 1. Making Calls Once the mark of the network provider appears on the screen, you can make or answer a call. The signal bar on the upper left corner of the screen shows the strength of your phone’s connection to the network.
Page 10: Making An Emergency Call
1.3 Making IDD Press * Key and release it to enter the character “+” which replaces the international access code. This allows you to make a call towards any country without knowing the local international access code, for instance, it is “00” in China. Allow you to follow the sequence below to make an international call: “+”, country code, whole telephone number, and Call key.
Page 11: Description Of Function Menu
 End single call To end the current call.  New Call To enter a new interface for you to dial another telephone number.  Phone Book To access the phonebook menu.  Messages To access the SMS menu. Because the network service is under use during a call, the SMS function is not available at this time.
Page 12 Anti-flicker：to have a choose of 50Hz or 60Hz.  Effect Settings：to choose a setting of images.  Storage: to choose phone or memory card.  Restore Default：to have the settings restore default. 1.5 Video Player Select Video Player submenu to access movie list and you can access “Option” for the following operations: ...
Page 13: Phone Book
set it as OFF (No Repeated Play), repeat single music and repeat all.  Shuffle: set the play sequence, separately set as ON (Random Play) and OFF (play as per the current list sequence).  Background play: choose this function; you can play the music when in other operations. (Except mute operation, camera operation and record operation.) ...
Page 14 2.3 Add new contact Add a new entry in the directory To SIM or To Phone. If saved To Phone, you can also set the items below besides information of Name, Number, Home Number, Company Name, E-mail Address, Office Number, Fax Number, and Birthday. ...
Page 15: Call Center
3. Call center 3.1Call history 3.1.1 SIM1 Call history To view information about call records, select Call History in the main menu. The information includes the Missed Calls, Dialed Calls, Received Calls, Delete Call Log, Call Timers, Call Cost, SMS Counter, and GPRS Counter etc. ...
Page 16  Reset counter: clear all data and restart counting. 3.1.2 SIM2 Call history The same as SIM1 Call history. 3.2 Call settings 3.2.1 SIM1 Call settings Caller ID You can select the presetting of system, hidden numbers or send numbers provided by the network operator.
Page 17: Organizer
Set it as Open or Off to activate or deactivate this function. 3.2.3.3 Speed dial Allow you to set status, speed dial list and 8 speed dial calls. Set it as on to access the standby interface, hold down the number from 2to 9, and you can directly allocated by the set of numbers.
Page 18: Messages
You can view the time around the world. 4.6 Calculator The phone provides you with a calculator featuring basic functions. To perform addition, subtraction, multiplication, and division, press corresponding direction key. Note: This calculator features rounding error due to limited accuracy. 4.7 Unit Converter Input the current exchange rate to convert between weight and length.
Page 19 To read a message, press “Ok”. In this interface, press Option and you will find the following entries : Reply , Delete , Forward , Copy to Phone/SIM ,Move to Phone/SIM , Delete All, Copy all, Move all , Use Number , Use URL, chat. 5.1.3 Outbox Select it to view the messages you save in the device or the SIM card.
Page 20: File Manager
 Add audio: Allow you to add voice files.  Add video: Allow you to add images.  Add attachment: Allow you to add attachment.  Add slide before: Allow you to add a new page in the front of the previous one. ...
Page 21: Services
 Rename：Change the name of the current folder.  Delete: Press it to delete the current folder.  Sort by: Press to sort the folder and files by name, by type, by time, by size, or none (At random).Select a file. Then, press Option to display the following options. 7.
Page 22: Settings
9. Settings Select “Settings” in the Main Menu. Then, you can perform Dual SIM setup, Phone Setup, Network Setup, Security Setup, and Restore Factory Settings etc. 9.1 Dual SIM settings Dual SIM open, only SIM 1 open, only SIM 2 open, flight mode. 9.2 Phone setup 9.2.1 Time and Date Allow you to Set home city，Time/Date ,Set Format.
Page 23: Input Method
9.4.1 SIM 1 security setup SIM1 lock To turn SIM1 lock on or off. Fixed dial If supported by your SIM card, you can select some telephone numbers to dial. If this service is activated, you can only dial the telephone number in the FDN list or the number started with some numbers in front of the telephone number in the list.
Page 24 While editing a message, press it to access the “Option” submenu, and finish editing or enter the EMS menu for edit. Navigation key (Up/Down/Left/Right key): Press to move the cursor or for selection. 10.3 Instructions on input method 9.3.1 English For this input method, the keypad is defined as below.
Page 25: Common Troubles And Trouble Removal
Number key “4” Number key “5” Number key “6” Number key “7” Number key “8” Number key “9” Number key “0” # key Change the input method Up key Move the cursor upward Down key Move the cursor downward Left key Move the cursor leftward Right key Move the cursor rightward...
Page 26  Signals are too weak, please try to another place with stronger signal; Impossible  to connect The cell phone is out of the network coverage of network network service provider;  SIM card is invalid, please contact your network supplier; ...
Page 27  Please make sure if dial key is pressed after dialing;  Please make sure if calling is barred for charges in arrears; Calls  cannot be Please make sure if SIM card is valid; dialed  Please make sure if call barring function is set; ...
Page 28 North standardization: from the main menu, enter “tools” → “outdoor tools”→ “e-compass”. Press “options” to get in to standardization page. Select “north standardization” Beijing Dorland System Control Technology Co., Ltd. Address: Room 11B5, Huajie Plaza DaZhongsi Street,Haidian District, Beijing,P.R.China Postal Code: 100098...
