SERVICE MANUAL
MODEL
COMMANDER DEST. CHASSIS NO.
KV-XF25M21
RM-954 New Zealand SCC-U26A-A
KV-XF25M63
RM-954 India
KV-XF25M93
RM-954 India
MODEL
SCC-U22C-A
SCC-U22D-A
TRINITRON
Self Diagnosis
BG-3S
CHASSIS
COMMANDER DEST. CHASSIS NO.
COLOR TV
®
Supported model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRINITRON KV-XF25M21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony TRINITRON KV-XF25M21

Summary of Contents for Sony TRINITRON KV-XF25M21

  • Page 1 Self Diagnosis Supported model SERVICE MANUAL BG-3S CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KV-XF25M21 RM-954 New Zealand SCC-U26A-A KV-XF25M63 RM-954 India SCC-U22C-A KV-XF25M93 RM-954 India SCC-U22D-A TRINITRON COLOR TV ®...
  • Page 2 CARBON PAINTED ON THE CRT, AFTER REMOVING THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE ANODE. THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KV-XF25M21/XF25M63/XF25M93 RM-954 TABLE OF CONTENTS Section Title Page Section Title Page SELF DIAGNOSIS FUNCTION 5. DIAGRAMS ........ 4 5-1. Block Diagram ............43 1. GENERAL ................ 8 5-2. Frame Schematic Diagram ........46 Circuit Boards Location .......... 49 2. DISASSEMBLY 5-4.
  • Page 4 KV-XF25M21/XF25M63/XF25M93 RM-954 SELF DIAGNOSTIC FUNCTION The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically begin to flash. The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference.
  • Page 5 KV-XF25M21/XF25M63/XF25M93 RM-954 DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT 2 times 5 times Lamp ON 0.3 sec. Lamp OFF 3 sec. Lamp OFF 0.3 sec. STANDBY/SLEEP lamp Diagnostic Item Flash Count* +B overcurrent/overvoltage 2 times Vertical deflection stopped White balance failure 5 times * One flash count is not used for self-diagnostic.
  • Page 6 KV-XF25M21/XF25M63/XF25M93 RM-954 SELF-DIAGNOSTIC SCREEN DISPLAY For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurances of failure for confirmation on the screen: [To Bring Up Screen Test] In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below: [Screen display] / channel [5] / Sound volume [-] / Power ON ˘...
  • Page 7 KV-XF25M21/XF25M63/XF25M93 RM-954 SELF-DIAGNOSTIC CIRCUIT IC301 IC001 IC003 Y/CHROMA JUNGLE SYSTEM MEMORY FROM IK-IN IO-8DAT B-DAT FROM [+B] Q604 C O-LED PROTECT IO-SDAT [V] Q509/507 [+B overcurrent ªOCPº] Occurs when an overcurrent on the +B(135) line is detected by Q604. If Q604 go to ON and the voltage to pin 18 of IC301 should go down when V.SYNC is more than seven verticals in a period, the unit will automatically turn off.
  • Page 8 SECTION 1 The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of GENERAL the Operating Instruction Manual remain as in the manual. Using Your New TV WARNING • Dangerously high voltages are present inside the TV. Getting Started •...
  • Page 9 Connecting the 3D WOOFER Notes • If you connect a monaural VCR, connect the yellow plug to (the yellow jack) and the black plug to -L (MONO) (the white jack). (KV-XF25M63/XF25M93 only) • If you connect a VCR to the ˘ (antenna) terminal, preset the signal output from the VCR to the program number 0 on the TV.
  • Page 10 Connecting optional components Securing the TV You can connect optional audio/video components, such as a VCR, multi disc player, To prevent the TV from falling, secure the TV using one of the following methods: camcorder, video game or stereo system. To watch the picture of the connected equipment, press …F (see page 10).
  • Page 11 Watching the TV Watching the TV (continued) ¤ Additional tasks This section explains functions used Do this … while watching TV. Most operations Turn off temporarily Press u. The u indicator on the TV lights up red. can be done using the remote. Press U on the TV.
  • Page 12 Advanced Operations Selecting the Setting the Wake Up timer SOUND MODE SURROUND FAVORITE picture and sound SOUND MODE PIC MODE MENU Press until the modes WAKE UP TIMER:10M PIC MODE desired period of time ENTER After 10 minutes appears. You can select picture and sound modes and adjust the setting to your preference WAKE UP TIMER:OFF WAKE UP TIMER:12H00M...
  • Page 13 Viewing your Listening with favorite channels surround sound SOUND SURROUND FAVORITE MODE SURROUND MENU PIC MODE You can display and select six of your The surround feature enables you to Number buttons ENTER favorite channels directly from your TV enjoy the sound effects of a concert hall screen.
  • Page 14 Selecting a stereo Selecting a stereo or bilingual program (continued) or bilingual SOUND When receiving an A2 (German) program MODE SURROUND FAVORITE PIC MODE MENU program Broadcasting On-screen display (Selected sound) ENTER A2 (German) stereo MONO STEREO (KV-XF25M63/XF25M93 only) (Regular sound) (Stereo sound) You can enjoy stereo sound or bilingual programs of NICAM and A2 (German)
  • Page 15 Viewing Teletext Viewing Teletext (continued) (KV-XF25M21only) Additional Teletext tasks … TV stations broadcast an information Do this service called Teletext via some TV display a Teletext page on the TV Press channels. Teletext allows you to receive picture Each time you press , the screen changes as various information, such as shares follows: Teletext n Teletext and TV n TV.
  • Page 16 Select the color system. AUTOnPALnSECAMnNTSC3.58nNTSC4.43 AUTOnPALnSECAMnNTSC3.58nNTSC4.43 * The BBE is manufactured by Sony Corporation under license from BBE * The BBE is manufactured by Sony Corporation under license from BBE Sound, Inc. It is covered by U.S. Patent No. 4,638,258 and No. 4,482,866.
  • Page 17 How to use the Changing the A/V SOUND MODE SURROUND FAVORITE menu SOUND CONTROL setting MODE SURROUND FAVORITE PIC MODE MENU MENU PIC MODE MENU MENU ENTER + / – /ENTER ENTER + / – /ENTER You can use the buttons on the remote The A/V CONTROL menu allows you and on the TV as well to display the to change the picture and sound...
  • Page 18 Changing the SET Changing the A/V CONTROL setting (continued) UP setting Adjusting the ADJUST options under PICTURE MODE Number buttons Press + or – to select the ENTER The SET UP menu allows you to change desired item (e.g., -/-- the menu language, lock channels, COLOR), then press COLOR...
  • Page 19 Changing the SET UP setting (continued) Changing other SET UP menu options Using the CHILD LOCK feature You can prevent your children from watching certain programs by Press MENU. using the CHILD LOCK feature. Press + or – to select the SET UP ENTER Press MENU.
  • Page 20 Changing the Select the desired Channel Preset SOUND MODE SURROUND FAVORITE channel. PIC MODE MENU MENU (CH PRESET) (1) Press + or – to select MANUAL PROGRAM ENTER + / – /ENTER ENTER either VHF LOW, VHF PR:10 setting TV SYS:B/G HIGH or UHF, then VHF LOW press ENTER.
  • Page 21 Changing the Channel Preset (CH PRESET) setting (continued) Changing other CH PRESET menu options If you are not satisfied with the picture and Press MENU. sound quality, you may improve them by using Press + or – to select the CH PRESET fine tuning.

  • Page 22: Self Diagnosis Function

    • If the sound of some channels are noisy, Noisy sound select the channel, then display the CH Inform your nearest Sony service center about the number of times the u PRESET menu and select the indicator flashes. appropriate TV system. (page 25) Be sure to note the model name and serial number located on the rear of your TV.
  • Page 23 COLOR level. (page 19 and 20) indicator on your • Contact your nearest Sony service • Your TV may need service. • Display the CH PRESET menu and • The color system setting is TV flashes red for about 3 center.
  • Page 24 Identifying parts and controls Remote Control Refer to the pages indicated in parentheses ( ) for details. Front panel !¶ -/-- -/-- !£ !¢ SOUND !∞ SOUND MODE SURROUND FAVORITE MODE SURROUND FAVORITE !§ MENU MENU PIC MODE PIC MODE ENTER ENTER !º...

  • Page 25: Disassembly

    SECTION 2 DISASSEMBLY 2-1. 3D SPEAKER BOX REMOVAL (KV-XF25M63/XF25M93 only) 2-3. CHASSIS ASSY REMOVAL 1 3D Speaker box assy Red wire Black wire 1 Chassis assy 2-2. REAR COVER REMOVAL 2-4. F BRACKET REMOVAL 2 Rear cover 4 Two screws (+BVTP 3 ×...

  • Page 26: Service Position

    2-5. SERVICE POSITION 2-6-2. REPLACEMENT OF LIGHT GUIDE (Note: Remove F Bracket first.) One screw (+BVTP 3 × 12) 2-6. REPLACEMENT OF PARTS 2-7. PWB HOLDER REMOVAL (FOR KV-XF25M21 ONLY) For replacement of the Control Button and Light Guide, unscrew them, exchange with the new parts, and fix them with screws (+BVTP) respectively.

  • Page 27: Terminal Bracket Removal

    2-8. TERMINAL BRACKET REMOVAL 2-10. H3 BOARD REMOVAL 3 Two connectors 1 Two screws (+BVTP 3 × 12) 2 Four connectors 5 H3 Board 1 Two connectors 4 Four claws 2 Two claws 3 Terminal bracket 2-9. V1 BOARD REMOVAL (KV-XF25M21 only) 2-11.

  • Page 28: Picture Tube Removal

    •REMOVAL OF ANODE-CAP 2-12. PICTURE TUBE REMOVAL NOTE: The picture tube for New Zealand model are upside-down, and the position for the anode-cap and tension spring is changed accordingly. NOTE : After removing the anode, short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield or carbon paint on the CRT.

  • Page 29: Set-Up Adjustments

    KV-XF25M21/XF25M63/XF25M93 SECTION 3 RM-954 SET-UP ADJUSTMENTS • The following adjustments should be made when a complete Perform the adjustments in the following order : realignment is required or a new picture tube is installed. 1. Beam Landing • These adjustments should be performed with rated power 2.

  • Page 30: Convergence

    KV-XF25M21/XF25M63/XF25M93 RM-954 3-2. CONVERGENCE Preparation : • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Minimize the brightness setting. Purity • Provide dot pattern. BMC (Hexapole) (1) Horizontal and Vertical Static Convergence Purity Center dot V.
  • Page 31 KV-XF25M21/XF25M63/XF25M93 RM-954 BMC (Hexapole) Magnet. Blue Neck assy Neck assy If the red, green and blue dots are not balanced or aligned, then use the BMC magnet to adjust in the manner described below. Blue VM board VM board Note 1.

  • Page 32: Focus Adjustment

    KV-XF25M21/XF25M63/XF25M93 RM-954 Rotate TLV-2 VOL (29”, 34”) on DY 3-3. FOCUS ADJUSTMENT Rotate TLV VOL (25”) on DY Adjust FOCUS control on the flyback transformer for the best XCV Rotate XCV Adj core on DY focus. YCH Rotate YCH VOL on DY Insert Correction Plate to DY Pocket (Left or Right)

  • Page 33: G2 (Screen) And White Balance Adjustments

    KV-XF25M21/XF25M63/XF25M93 RM-954 2. WHITE BALANCE ADJUSTMENT 3-4. G2 (SCREEN) AND WHITE BALANCE 1) Set to Service Mode (Refer Section 4-1: ADJUSTMENTS ADJUSTMENTS WITH COMMANDER). 1. G2 (SCREEN) ADJUSTMENT 2) Input white raster signal. 1) Set the PICTURE to normal. 3) Set the PICTURE to minimum. 2) Put to VIDEO input mode without signals.

  • Page 34: Circuit Adjustment

    KV-XF25M21/XF25M63/XF25M93 SECTION 4 RM-954 CIRCUIT ADJUSTMENTS 4-1. ADJUSTMENTS WITH COMMANDER Service adjustments are made with the RM-954 that comes with this unit. 1, 4 Select the adjustment item. ↓ a. ENTERING SERVICE MODE 3, 6 Raise/lower the data value. With the unit on standby ↓...

  • Page 35: Adjustment Method

    KV-XF25M21/XF25M63/XF25M93 RM-954 4-2. ADJUSTMENT METHOD Item Number 00 of device GEO Use the same method for all Items. Use 1 and 4 to select the This explanation uses H-Position as an example. 1. Select “GEO 00 HPS” with the 1 and 4 buttons. adjustment item, use 3 and 6 to adjust, write with [MUTING] 2.
  • Page 36 Adjustment Item Table Device Functionality Note Data Range Function Note for Register Slava RAM Address Name Name Different Data No. (bit) Address (bit) H Position 50/60HZ 12 (7-2) CXA2130S(88H) 96 (7-2) H Size 50/60HZ 11 (7-2) 95 (7-2) Pin Amp 50/60HZ 13 (7-2) 97 (7-2)
  • Page 37 Adjustment Item Table Device Functionality Note Data Range Function Note for Register Slava RAM Address Name Name Different Data No. (bit) Address (bit) H Drive Pulse Width Switch 00 (6) 54 (6) AFC Gain Control TV/Video 0F (1-0) A1 (1-0) H Oscillation 0C (7-4) 60 (7-4)
  • Page 38 Adjustment Item Table Device Functionality Note Data Range Function Note for Register Slava RAM Address Name Name Different Data No. (bit) Address (bit) SECAM BELL f0 1C (7-2) CXA2060AS(8AH) 85 (7-2) H Oscillation 0C (7-4) 80 (7-4) Sub Hue Control 05 (7-2) Sub Color Control 04 (7-2)
  • Page 39 KV-XF25M21/XF25M63/XF25M93 RM-954 ITEM INFORMATION. No. OPB0 OP1 Item XTAL 4.43 XTAL 3.58 SECAM 2nd. Lang KV-XF25M21 KV-XF25M63 KV-XF25M93 No. OPB1 OP2 Item NICAM HDEV Thai Bil – DVD Input AV Input KV-XF25M21 KV-XF25M63 KV-XF25M93 No. OPB2 OP3 Item – – Auto PIC Auto TV sys US ST...

  • Page 40: Picture Quality Adjustments

    KV-XF25M21/XF25M63/XF25M93 RM-954 4-3. PICTURE QUALITY ADJUSTMENTS BELL FILTER ADJUSTMENT SUB COLOR ADJUSTMENT 1. Input SECAM color-bar signal. 2. Connect the dual-trace oscilloscope to the pin 9 (R-Y) of 1. Input a PAL color-bar. CN303 (not mounted). 2. Set to the following condition: 3.
  • Page 41 TRU Surround AUDIO PROCESSOR L1 out TV V in AV SW DBFB (3D) AUDIO OUT IC3201 IC3206 IC3207 TDA7315D R1 out MAIN. TUVIF TV L in IC1401 with NJM2187L NJM2150D <slave:80H> O6202 IC6201 STEREO DECODER CXA1855S TV R in <slave: 84H> <slave: 90H>...
  • Page 42 CN5901 CN704 CN701 200V (COMB FILTER) CN1801 VM MUTE PICTURE VD+ OUT TUBE CN703 VD- OUT (RGB OUT) VELOCITY MODULATION N/S ROT N/S MUTE CN4602 AC IN (CISPR) AC IN NECK ASSY DY ASSY CN507 (POWER SUPPLY, HV, MICON, Y/C JUNGLE) NS ROT NS MUTE CN3601...

  • Page 43: Circuit Boards Location

    5-3. CIRCUIT BOARDS LOCATION 5-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Note: • All capacitors are in µF unless otherwise noted. • All electrolytic capacitors are rated at 50V unless otherwise noted. • All resistors are in ohms. kΩ = 1000Ω, MΩ = 1000kΩ •...

  • Page 44: Schematic Diagram Of A (1/2) Board

    (1) Schematic Diagram of A Board (1/2) CN204 CN203 CN102 TO B3 BOARD CN1405 TO H3 BOARD CN201 :BTOB TO B3 BOARD CN3603 CN608 CN1407 CN303 CN106 CN101 :S-MICRO CN105 CN104 :S-MICRO TO B3 BOARD CN205 CN302 TO B3 BOARD TO B3 BOARD :MINI CN1406...
  • Page 45 (2) Schematic Diagram of A (2/2) Board CN507 R501 :S-MICRO NS ROT :CHIP TO C BOARD NS MUTE R500 CN1801 135V 135V R596 135V 135V 135V 135V 135V 135V POWER SUPPLY,HV,MICON 135V L516 R502 L517 C500 R544 L515 3W :RS :DCC NS ROT C514...
  • Page 46 (3) Schematic Diagram of B Board A BOARD N OT E : The circuit indicated at left contains high voltage of over D004 [COMB FILTER] [POWER SUPPLY, HV, MICON, Y/C JUNGLE] D615 D005 600 Vp-p. Please pay attention when inspecting or repair- D616 IC001 B-10...

  • Page 47: Schematic Diagrams Of A (2/2) And F Boards

    (4) Schematic Diagrams of H and VM Boards TO B3 BOARD TO B3 BOARD TO A BOARD TO SP TO J2 BOARD TO B3 BOARD TO A BOARD TO F BOARD TO A BOARD CN6204 CN6202 CN904 CN3451 CN1400 CN104 CN4602 CN5901 CN601...
  • Page 48 (5) Schematic Diagram of B Board CN1400 TU1401 :S-MICRO C1461 R1411 C1460 D1415 470p :CHIP AUDIO(R) CH:CHIP F:CHIP UDZSTE-179.1B R/L/Y/S/C/CV R3272 6.8k R IN :CHIP R1420 C1450 C1453 R1412 R1409 C1462 JR1409 R1474 220k F:CHIP :CHIP JW1481 C1437 C1463 :CHIP R3211 L IN AUDIO(L)
  • Page 49 BOARD IC3201 NJM2187L PRINTED WIRING BOARD Lch out Lch in [AUDIO PROSESSOR, AV SWITCH] BYPASS FIL 1 3D–STEREO Rch in Rch out SPACE VR 3D–STEREO BYPASS CENTER VR FIL 2 – B Board – Schematic diagram board...

  • Page 50: Schematic Diagram Of B3 Board

    (6) Schematic Diagram of F Board C BOARD IC701 STV5112 BLUE FEEDBACK (RED FEEDBACK, GREEN FEEDBACK) (CISPR) BLUE OUTPUT CN4601 T4602 F4601 (RED OUTPUT, VDR461 JW4603 250V GREEN OUTPUT) T4601 :FUSE AC IN AC OUT JW4604 R4601 AC IN AC OUT 1/2W BLUE CATHODE CN4602...
  • Page 51 (7) Schematic Diagram of C Board CN702 R701 PRINTED WIRING BOARD :TAB 100k D1808 1/2W RV1801 GP08DPKG23 [RGB OUT] CN1801 SG701 C1809 C701 GAP,SPARK 1000 0.0047 333.3 :S-MICRO C705 R1806 4.7k G1-1 R1800 1/2W CN701 VD+OUT D1803 R1825 :RN-CP R1804 D700 1SS119-25TD 3.3k...

  • Page 52: Exploded Views

    KV-XF25M21/XF25M63/XF25M93 SECTION 6 RM-954 EXPLODED VIEWS NOTE: • • Items marked " ∗ " are not stocked since Items with no part number and no The components identified by description are not stocked because they are seldom required for routine shading and mark ! are critical they are seldom required for routine service.

  • Page 53: Chassis

    KV-XF25M21/XF25M63/XF25M93 RM-954 6-2. CHASSIS SCREW BVTP 3 × 12 r: 7-685-648-71 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1372-576-A H3 BOARD, COMPLETE (KV-XF25M21) 4-046-797-01 SCREW (3X12), (+)BVTAP * A-1372-606-A H3 BOARD, COMPLETE * A-1131-375-A B2 BOARD, COMPLETE (KV-XF25M21) (KV-XF25M63/XF25M93) * A-1131-417-A B2 BOARD, COMPLETE * A-1136-985-A B3 BOARD, COMPLETE (KV-XF25M21)

  • Page 54: Picture Tube

    KV-XF25M21/XF25M63/XF25M93 RM-954 6-3. PICTURE TUBE SCREW BVTP 3 × 12 r: 7-685-648-71 NOTE: The picture tube for New Zealander model is upside-down, and the position for tension spring is changed accordingly. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK 1-451-475-11...

  • Page 55: Speaker (Kv-Xf25M63/Xf25M93 Only)

    KV-XF25M21/XF25M63/XF25M93 RM-954 6-4. 3D SPEAKER (KV-XF25M63/XF25M93 ONLY) SCREW BVTP 4 × 12 4: 7-685-661-71 SCREW BVTP 4 × 16 p: 7-685-663-71 REF. NO. PART NO. DESCRIPTION REMARK * 4-065-515-01 BOX (TP), 3D SPEAKER 1-529-172-11 SPEAKER, LOUD (10CM) * 4-065-516-01 BOX (BT), 3D SPEAKER 4-302-428-03 SCREW (WASHER HEAD) (+P 3X12) –...

  • Page 56: Electrical Parts List

    KV-XF25M21/XF25M63/XF25M93 SECTION 7 RM-954 The components identified by shading and mark ! are critical for safety. ELECTRICAL PARTS LIST Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK NOTE: • Items marked " ∗ " are not stocked since they •...
  • Page 57 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C531 1-107-903-11 ELECT 2.2MF C620 1-163-133-00 CERAMIC CHIP 470PF C532 1-128-528-11...
  • Page 58 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <DIODE> D613 8-719-046-74 DIODE AU-01Z-V1 D614 8-719-046-74 DIODE AU-01Z-V1 D001 8-719-988-61...
  • Page 59 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK JR005 1-216-295-91 SHORT Q303 8-729-216-22 TRANSISTOR 2SA1162-G JR006 1-216-295-91 SHORT...
  • Page 60 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R042 1-216-295-91 SHORT R346 1-216-051-00 RES,CHIP 1.2K 1/10W R043 1-216-025-91...
  • Page 61 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R541 1-216-065-91 RES,CHIP 4.7K 1/10W R617 1-247-791-91 CARBON 1/4W R542...
  • Page 62 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <THERMISTOR> C112 1-126-933-11 ELECT 100MF C113 1-126-967-11 ELECT...
  • Page 63 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C536 1-136-165-00 FILM 0.1MF C625 1-102-002-00 CERAMIC 680PF 500V...
  • Page 64 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <DIODE> D614 8-719-046-74 DIODE AU-01Z-V1 D620 8-719-110-72 DIODE RD30ESB2 D001...
  • Page 65 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK JR005 1-216-295-91 SHORT Q302 8-729-230-49 TRANSISTOR 2SC2712-YG JR006 1-216-295-91 SHORT...
  • Page 66 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R038 1-216-049-91 RES,CHIP 1/10W R334 1-216-125-00 RES,CHIP 1.5M 1/10W...
  • Page 67 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R534 1-216-361-00 METAL OXIDE 0.22 R611 1-216-089-91 RES,CHIP 1/10W...
  • Page 68 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK T505 1-426-981-11 TRANSFORMER, FERRITE (PMT) C1416 1-164-346-11 CERAMIC CHIP...
  • Page 69 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C3244 1-164-346-11 CERAMIC CHIP C6222 1-164-505-11 CERAMIC CHIP 2.2MF C3245 1-164-005-11...
  • Page 70 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CHIP CONDUCTOR> R1433 1-216-025-91 RES,CHIP 1/10W R1435 1-216-022-00 RES,CHIP 1/10W...
  • Page 71 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3205 1-216-069-00 RES,CHIP 6.8K 1/10W R3262 1-216-115-00 RES,CHIP 560K 1/10W...
  • Page 72 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1136-001-A B3 BOARD, COMPLETE (KV-XF25M63/XF25M93) C3220 1-163-037-11 CERAMIC CHIP...
  • Page 73 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK C6216 1-125-797-91 ELECT 10MF D1411 8-719-158-35 DIODE RD9.1SB C6217 1-164-004-11...
  • Page 74 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <IC LINK> R1457 1-216-073-00 RES,CHIP 1/10W R1458 1-216-073-00 RES,CHIP...
  • Page 75 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R3239 1-216-073-00 RES,CHIP 1/10W R6236 1-216-075-00 RES,CHIP 1/10W...
  • Page 76 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> <RESISTOR> CN700 1-695-915-11 TAB (CONTACT) R700 1-249-393-11 CARBON 1/4W F...
  • Page 77 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK * A-1331-911-A C BOARD, COMPLETE (KV-XF25M63/XF25M93) D722 8-719-911-19 DIODE 1SS119-25...
  • Page 78 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK R1805 1-220-969-91 METAL CHIP 1/2W <VARISTOR>...
  • Page 79 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <COIL> * A-1372-606-A H3 BOARD, COMPLETE (KV-XF25M63/XF25M93) ********************** L3901 1-408-603-31...
  • Page 80 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M63 KV-XF25M21 KV-XF25M93 KV-XF25M93 ONLY ONLY REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <TRANSISTOR> <JACK>...
  • Page 81 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M21 KV-XF25M21 ONLY REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CHIP CONDUCTOR> R850 1-216-105-91 RES,CHIP 220K 1/10W R851...
  • Page 82 KV-XF25M21/XF25M63/XF25M93 RM-954 The components identified by shading and mark ! are critical for safety. Replace only with part number specified. KV-XF25M63 KV-XF25M21 KV-XF25M93 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK <CONNECTOR> R5931 1-249-413-11 CARBON 1/4W R5932 1-249-413-11 CARBON...
  • Page 83 CLIP (KV-XF25M63/XF25M93) *********************************************************************** *********************************************************************** REMOTE COMMANDER ********************** 1-418-038-11 REMOTE COMMANDER (RM-954) 9-933-895-01 BATTERY COVER, REMOTE COMMANDER Sony Corporation English 99AA70082-1 SONY TV Industries (M) Sdn. Bhd. Printed in Malaysia © 9-965-729-01 TV Business of General Area 1999. 1 – 110 –...
