Summary of Contents for REI XD-3000
- Page 1 User Manual XD-3000 HDMI Signal Manager All Rights Reserved Version: XD-3000_2021V1.1...
-
Page 2: Safety Precaution
Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The functions described in this version are updated till May 21, 2021. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. Safety Precaution ▪... -
Page 3: Package Content
Introduction The XD-3000 is an ultra-thin HDMI signal manager supports HDMI V2.0. It is designed to enhance the compatibility between HDMI source and display to match more display devices. The transmission of 4k×2k@60Hz (max) signal from source to display is up to 10m. In addition, it supports 4K downscaling to 1080p output, and HDCP follows the display device ensure device compatibility. -
Page 4: Panel Description
Panel Description ① Power LED: The LED illuminate green when it is powered on ② DC 5V: Micro-USB power port, insert DC 5V 1A power adapter ③ IN: Connect with HDMI source ④ OUT: Connect with HDMI display ⑤ 4K→1080p: ON: Enable downscale 4K signal to 1080p. -
Page 5: Specification
Specification Input & Output Input (1) HDMI Input Connector (1) 19-pin type-A female HDMI Output (1) HDMI Output Connector (1) 19-pin type-A female HDMI General Input≤5m; Output≤5m Transmission Distance HDCP Standard Input supports HDCP2.3 EDID Management EDID pass-through Bandwidth 18Gbps Work Temperature -10~55℃... - Page 6 OREI LLC. ADDRESS: 7444 Long Ave. Skokie, IL 60077 CALL US: 877-290-5530 EMAIL: info@orei.com...
