ABX Air Inc.
Printed: 8/27/2010 at 12:10:53
PM
REV 11 2008/12/11
SERVICING - SERVICING
1. General
A. The left and right main fuel tanks can be gravity fueled through the over-. wing fill
adapters located approximately 10 feet inboard of each wing tip. Procedures for gravity
fueling the left and right main tanks are identical.
B. The center and forward auxiliary tank fueling is accomplished by using the right main
tank boost pumps to pump fuel through the defueling line and fuel fill valve, and into the
applicable tank fill line, (see
C. Fuel tank capacities and acceptable fuel specifications are shown on the fuel system
replenishment chart, General Servicing.
2. Tools and Equipment Required
NOTE: Equivalent substitutes can be used instead of following listed items.
Item
Name
A Sump drain tool
B Sump drain tool
C Drain bottle
assembly
3. Gravity Fueling
WARNING: DO NOT OPERATE RADIO, RADAR, OR ANY OTHER
ELECTRICAL/ELECTRONIC EQUIPMENT ON AIRPLANE
EXCEPT AS SPECIFIED.
RADAR AND HIGH-FREQUENCY EQUIPMENT OPERATING IN
VICINITY OF AIRPLANE DURING FUELING OPERATIONS IS
HAZARDOUS.
MAKE CERTAIN FUEL SUPPLY UNIT IS GROUNDED AND
THAT CABLES TO AIRPLANE GROUNDING CONNECTORS
ARE PROPERLY CONNECTED.
CAUTION:
MAKE CERTAIN FUELING SOURCE CONTAINS PROPER FUEL
GRADE AS SPECIFIED BY ENGINE MANUFACTURER. SEE FUEL
SYSTEM REPLENISHMENT CHART, GENERAL SERVICING, FOR
ACCEPTABLE FUEL SPECIFICATIONS.
EFFECTIVITY: 900-905, 909, 928, 930, 934, 939,
953-960, 962-964, 980-984, 986
DC-9
MAINTENANCE MANUAL
Figure 303
).
Number
Manufacturer
799
Service Supply
Systems, Los Altos,
Calif.
4298-1
Roylyn, Inc. Glendale,
Calif.
700200-1
Accessory Products Co.
Whittier, Calif.
To drain sump
To drain sump
To drain sump
This page must not be retained for reference
Use
12-12-00-3
CONFIG 00
Page 1
1999/11/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ABX DC-9
Summary of Contents for ABX DC-9
- Page 1 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 SERVICING - SERVICING 1. General A. The left and right main fuel tanks can be gravity fueled through the over-. wing fill adapters located approximately 10 feet inboard of each wing tip. Procedures for gravity fueling the left and right main tanks are identical.
- Page 2 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 CHECK THAT MAIN GEAR INBOARD DOORS ARE CLOSED BEFORE FUELING AIRPLANE. A. Main Fuel Tanks (1) Connect fueling unit/airplane grounding cable. CAUTION: OBSERVE THE NO STEP AREAS ON WINGS.
- Page 3 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 CAUTION: MAKE CERTAIN FILL ADAPTER CAP IS LOCKED. (9) Install overwing fill adapter cap; lock cap. (10) Disconnect fueling unit/airplane grounding cable. NOTE: Steps (11) and (12) should be performed on condition or at operators discretion.
- Page 4 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 RADAR AND HIGH FREQUENCY EQUIPMENT OPERATING IN VICINITY OF AIRPLANE DURING FUELING OPERATIONS IS HAZARDOUS. MAKE CERTAIN FUEL SUPPLY UNIT IS GROUNDED AND THAT CABLES TO AIRPLANE GROUNDING CONNECTORS ARE PROPERLY CONNECTED.
- Page 5 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 NOTE: If the main tanks are to be fueled individually, fuel the right main tank first. (12) Observe right main tank master fuel quantity indicator. NOTE: The right main tank should be approximately 1/4 full to ensure a continuous fuel supply to the right tank boost pumps when transferring fuel to the center and forward auxiliary tanks.
- Page 6 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 (b) Place fueling control panel power switch in off position. (c) Place manual fill switch in auto position. (24) Place defueling shutoff valve control lever to closed position; safety lever with lockwire.
- Page 7 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 Figure 301 Sheet 01 - Gravity Fueling - Fueling Provisions EFFECTIVITY: 900-905, 909, 928, 930, 934, 939, 12-12-00-3 953-960, 962-964, 980-984, 986 CONFIG 00 Page 7 1999/11/15...
- Page 8 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 Figure 302 Sheet 01 - Gravity Fueling - Fueling Control Station EFFECTIVITY: 900-905, 909, 928, 930, 934, 939, 12-12-00-3 953-960, 962-964, 980-984, 986 CONFIG 00 Page 8...
- Page 9 ABX Air Inc. DC-9 Printed: 8/27/2010 at 12:10:53 MAINTENANCE MANUAL REV 11 2008/12/11 Figure 303 Sheet 01 - Gravity Fueling - Right Main To Center Tank Fueling Transfer - Schematic EFFECTIVITY: 900-905, 909, 928, 930, 934, 939, 12-12-00-3 953-960, 962-964, 980-984, 986...
