Summary of Contents for LEXIN B4FM
- Page 5 "B4FM" channel@lexinmoto, (Con el bot6n del icono X) Instruction Find en Sie das Video" B4FM " Instruction. •• Par el video de instrucciones mas actualizado, haga clic en el en lace que muestra el bot6n con el icono X y el conector tipo-c.
-
Page 6: Function Introduction
Profile (A2DP). It supports universal pairing with almost all Bluetooth headsets on the market. Battery The B4FM features an 800 mAh battery which can provide the intercom device with 15 hours of music or 15 hours of intercom talk with over one week of standby time. Function Priority: (The B4FM operates in the following order of priority) l.Mobile phone... - Page 7 #Hearthedifference LEXIN B4FM USER GUIDE WARNING LEASE CHECK ALL LOCAL LAWS AND REGULATIONS REGARDING THE USE O IN-HELMET S EAKERS WHILE OPERAT I NG MOTORIZED VEHICLES.
-
Page 8: Package Contents
LEXIN B4FM USER GUIDE #Hearthedifference Package Contents B4FM Main Unit · 3M Tape Bracket 36mm HD Ultra-Slim Speakers · User Manual/Quick Start Guide Boom/Button Microphones · USB-C Cable Boom Microphone Holder · Speaker Pad Mounting Bracket · Allen Wrench & Screws •4 Clamp Plate ·... -
Page 9: Installation Instructions
Even though the 3M Tape bracket is provided for convenience, LEXIN recommends Note: using the bracket mounting. The 3M Tape bracket is offered as an option that you may use at your own risk and responsibility, LEXIN does not assume any responsibility for use of it. - Page 10 Dismounting Stick to insert it between B4FM unit and the mounting bracket, then push the B4FM main unit up from the bracket. Installing Speakers Note: The speaker with the shorter wire is for the left ear and the speaker with the longer wire is for the right ear, this will enhance the FM radio reception as well.
- Page 11 LEXIN B4FM USER GUIDE #Hearthedifference Installing Microphone Note: The button microphone and boom microphone can be interchanged between full face or open face helmet. Choosing between the two is based on your preference and what fits best in the helmet(s).
- Page 12 LEXIN B4FM USER GUIDE #Heartheditference General Operation Instructions Power on/off =Hold + C, for 1 second simultaneously • Power Button • UP Button • • USB-C Headset Port • Intercom Button Down Button USB-C Charging Port Powering On/Off Power On: Long press the Power Button and Intercom Button for about 1 second to power on.
- Page 13 Battery Life Prompt: Every time you turn on the unit, it will automatically report the current battery life. While in standby mode, long press the Down Button for about 1 second, the B4FM device will prompt the current battery life.
- Page 14 LEXIN B4FM USER GUIDE #Hearthedifference Step 2: Follow pairing instructions for your specific GPS Navigation to connect to B4FM; Note: You will be able to listen to Bluetooth voice instructions from Bluetooth GPS navigation once paired. 14,M,IJiiUI Answer Call: Click the Power Button to answer when phone call is coming.
- Page 15 LEXIN B4FM USER GUIDE #Hearthedifference Music Sharing: A B4FM device (A) that is playing music can share music to another B4FM device (B). When device A is playing music, double click Power Button on device A to enter music sharing mode. Then make sure device B is in standby state, double click Power Button on device B to search and connect device A, it will play the same music automatical...
- Page 16 Step G)(2-Way Pairing): Press the Intercom Button to pair2 B4FM devices Power on two B4FM units. Long press the Intercom Button on both two units about 1 second. LED of both two units will flash red and blue alternately which indicate they enter pairing mode.
- Page 17 Note: 1. If you only need to pair three B4FM devices, you only need to complete Step@, and then start the intercom talk . 2. If the second device is disconnected, other devices will also be disconnected.
- Page 18 Four-way Pairing: While completed Step CD and Step@, units 1&2&3 are paired, press the Intercom Button to pair the third and forth B4FM devices. On the standby mode, long press the Intercom Button on the third and the fourth units about one second, the voice will prompt "pairing", then the LED light on both two units...
- Page 19 #Hearthedifference Multi-way group intercom Every time you turn on the B4FM device, the default is 4-way intercom mode, and to switch into the multi-way intercom mode which is for more than five riders (including five riders), in the standby state, you need to long press Power Button for about 8 seconds on all units, there will be a beep and the indicator light flashes red quickly at the same time.
- Page 20 Step 2: Follow your other Bluetooth device pairing instructions to enter pairing mode; Step 3: Click the Intercom Button on B4FM to search the other device and the LED light will flash blue and red quickly. After the pairing is completed, the LED light returns to the blue light flashing slowly;...
- Page 21 Product and is not assignable or transferable to any subsequent purchaser/end-user. This warranty is limited to the repair or replacement, at LEXIN' s discretion, of defective or non-conforming Product, and LEXIN shall not be responsible for the failure of the Product to perform specified functions, or any other non- conformance caused by or attributable to: (a) any misapplication or misuse of the Product;...
- Page 22 By using the Product, you are irrevocably releasing, indemnifying from any liability, loss, claim and expense (including attorney's fees) and holding LEXIN harmless for any bodily injuries, harm or death as well as losses or damages in goods, to any vehicles including...
- Page 23 LEXIN B4FM USER GUIDE #Hearthedifference others, including LEXIN. By using the Product, you confirm that you have read this release of liability and fully understand and accept its terms and conditions. RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
