Part# 1002868-04
1/23/2017
This manual contains important information concerning the
installation and operation of the automobile lift listed above.
Read manual thoroughly and keep for future reference
INSTRUCTIONS
1002868 (L1200S) - 04.xlsx
Herkules Equipment Corporation
2760 Ridgeway Court
Walled Lake, MI 48390-1662 USA
248-960-7100
800-444-4351
Fax 248 960-7109
Patents USA 7070167 4793369, 4960142, 5174317, 5193561, 5485860 Canada 1299468 & Patents Pending
website: www.herkules.us
Made in the USA
e-mail: info@herkules.us
Page 1 of 15
Advertisement
Table of Contents
Related Manuals for HERKULES L1200S
Summary of Contents for HERKULES L1200S
- Page 1 This manual contains important information concerning the installation and operation of the automobile lift listed above. Read manual thoroughly and keep for future reference INSTRUCTIONS 1002868 (L1200S) - 04.xlsx Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA...
-
Page 2: Table Of Contents
The limited liability warranty applies to other components of our Herkules lifts to the initial user against defective materials for a period of one year from the proof of purchase date. -
Page 3: Warnings
Tags - Operating Instructions Warning: This symbol alerts you to the possibility of serious injury or death if you do not follow the instructions Caution: This symbol alerts you to the possibility of damage to or destruction of equipment if you do not follow the instructions. - Page 4 Tag - Operating Instructions (P/N 1006355) Back Tag - Operating Instructions - Air (P/N 1006356) Page 4 of 15...
-
Page 5: Installation
Install 1/2 NPT connector into open port (Port 1) on the foot control valve (see fig.2). STEP 7 Connect your shop air line to connector and test for proper operation. NOTE: Must use clean, dry air only. Herkules recommends using a filter/regulator (see Optional Accessories). 1/4" Hose barb Port 1 5/8"... - Page 6 STEP 8 Obtain wing assemblies and hardware: (see fig.3). Part # Description Qty. 10527 Wing Assembly Hex Bolt 1/2-13 x 1-1/2" Lock Nut 1/2-13 STEP 9 Slide the wing assembly (10527) into the wing guides on the top pan of the lift (see fig.3). STEP 10 Secure the wing assembly to the lift using (2) 1/2-13 x 1-12"...
- Page 7 STEP 15 Move the lift clear of the location and drill the (4) anchor holes with a 7/8" diameter drill to a depth of 2-1/4". STEP 16 Insert the anchors (008-384) into the drilled holes, making sure that the threaded cone end is inserted first (see fig.6). STEP 17 Return the lift to the desired position and install (4) 1/2"...
-
Page 8: Operation
Operation STEP 1 Check the weight of the vehicle to be sure that it does not exceed the rated load capacity of the lift: 5,000 lbs. STEP 2 Drive the vehicle onto the lift so that it is approximately centered by weight over the center of the lift. Once the vehicle is in the desired position, set parking brake and put the ramps into the locked position by tilting them up (see fig.8). -
Page 9: Duty Cycle
Items that will need repair may include: 1) air bag, 2) safety ratchet, 3) scissors, 4) pivots, and 5) valves. For heavy duty scissor lift systems that requires little maintenance Herkules recommends our Herkules Ball Screw or Belt Drive Scissor Lift Systems. These lift systems are designed and manufactured for high duty cycles and long life. -
Page 10: Maintenance Instructions
Maintenance Instructions STEP 1 Check clamps and hose connections periodically for tightness to prevent air leakage. STEP 2 Make sure all moving parts are clean and unobstructed by foreign objects. STEP 3 Clean filter element every 3 months if applicable. STEP 4 Grease and oil pivot points once every 3 months. -
Page 11: Optional Accessories
Optional L1200 Accessories Part # Description Units 12853 Control Valve Assembly - Hand - Lift Only - 2 x Muffler 12854 Control Assembly - Hand - Lift Only - Wall Mount 12858 Control Assembly - Hand - Lift Only - Pedestal Mount 12880 Filter / Regulator Assembly 12881... -
Page 12: Parts List
Parts List Part # Description Quantity Units 10182 RAMP FOR K-900 SGR 10527 WING ASSEMBLY FOR 10526 11177 BOTTOM PAN WLDMT FOR L-1200 11178 INNER SCISSOR WLDMT FOR L-1200 11179 TOP PAN WLDMT FOR L-1200 11182 OUTER SCISSOR L WLDMT FOR L-1200 11183 OUTER SCISSOR R WLDMT FOR L-1200 11185... -
Page 13: Controller Layout
Controller Layout Part # Description Units VALVE 4-WAY FOOT CONTROL 1/2 NPT 1004805 HOSE BARB 1/4 X 1/4 NPT BRASS 10071 CNTRL MOUNT WELDM SINGLE FOOT RED. BUSHING 1/2 NPT X 1/4NPT BRASS 1001393 HOSE BARB 5/8 X 1/2 NPT BRASS 1006365 STICKER LIFT UP-DOWN-INDUSTRIAL 1001602... -
Page 14: Layout Drawing
Page 14 of 15... -
Page 15: Schematic
Page 15 of 15...
