INSTALLATION AND OPERATION MANUAL
NWKSP2
COMNET SOLAR POWERED SYSTEM
Thank you for purchasing NetWave® from ComNet. This manual will cover how to
install hardware on your enclosure, Configure batteries, cabling and mounting of the
enclosure.
The NetWave® NWKSP2 Solar off the grid power system is designed for applications
where a remote camera or wireless repeater is needed but power is not available
or the cost to run power is too expensive. NetWave Solar is a complete system for
providing remote power to edge communications equipment. The kit includes
high quality photovoltaic solar panels, valve-regulated lead-acid battery, outdoor
enclosure, solar charge controller, PoE midspan injector and mounting hardware.
The steel outdoor enclosure has a gasket hinged lid with two tamper proof locks
operated by a special key for high security. The enclosure can be mounted on a two
to four inch pole or wall mounted with the included mounting hardware. The Solar
Panels include a top of pole mount requiring a 4" diameter pole. A side of pole
mount is available as an optional accessory. The included 30A solar charge controller
supports an LCD screen for local diagnostics and system health monitoring,
Intelligent PWM charging mode and battery protection from overcharge and over
discharge while the battery provides outstanding deep cycle and cold weather
performance.
