Installation
24V/1A DC is required to power converter. Standard consumption is lower, but switched-mode power
supply requires high inrush current.
Peripherals description
1.
Jumper - RS485 terminator
2.
RS 485 [C-bus] connector
3.
RS 232/MMI connector
4.
Ethernet
5.
USB Slave
6.
Do not connect
7.
Jumper - MMI power supply bridge between RS 232 DB9 and port 3.
8.
Power supply 24V DC
RS 485 connector
1.
Shielding
2.
A+
3.
B-
4.
GND
RS 232 connector
1.
GND
2.
MMI power
3.
TxD
4.
RxD
Power supply 24V DC
1.
-24VDC
2.
+24VDC
With reverse polarity protection
©2022 Apli s.r.o.
Zapli SCADA
1/3
Installation
Advertisement
Table of Contents
Summary of Contents for Apli Zapli SCADA
- Page 1 Zapli SCADA Installation 24V/1A DC is required to power converter. Standard consumption is lower, but switched-mode power supply requires high inrush current. Peripherals description Jumper - RS485 terminator RS 485 [C-bus] connector RS 232/MMI connector Ethernet USB Slave Do not connect Jumper - MMI power supply bridge between RS 232 DB9 and port 3.
- Page 2 Zapli SCADA RS 232 DB9 USB Host HDMI Do not connect Micro SD slot M-Bus M-Bus connector M-Bus M-Bus With protection against overvoltage and short circuit In the event of prolonged short-circuit situation, converter will reduce output voltage. To restore converters function it is required to break converters power supply.
- Page 3 Zapli SCADA Changing system language Integrated helper You can also access integrated helper by directly accessing following links, each for different language: <converters IP>/wiki/sk/blacky_max.html <converters IP>/wiki/en/blacky_max.html <converters IP>/wiki/de/blacky_max.html ©2022 Apli s.r.o. Installation...
