Gunfather
The
™
ASSEMBLY INSTRUCTIONS
In the event of missing or damaged parts, please contact us at:
Phone 417-673-9000 or Fax 417-673-9081
service@americanfurnitureclassics.com
Verify all parts are included.
Carefully open your box and lay all of the parts out on a
flat surface. Verify all parts shown below are included.
Top Unit
Tools Needed: Screwdriver
(2) sets of Keys
Base Unit
(2) Hinge Pins
Barrel Rest
(20) Panel Screws
Butt Rest
(12) Wood Dowels
Back
Panel
Front Door
Top Shadow Panel
(8) Cam bolts
Right Side Panel
Left Side Panel
(with hinge)
(without hinge)
Bottom Shadow Panel
(8) Cam inserts
