- Page 1 GOT810-316 10.4” XGA TFT Touch Panel Computer User’s Manual IP69K certification distinguishes the highest level of reliability...
-
Page 2: Disclaimers
Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. -
Page 3: Safety Precautions
Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not spray any liquid cleaner directly onto the screen. The GOT810-316 may come with or w/o a touchscreen. Although the touchscreen is chemical resistant, it is recommended that you spray the liquid cleaner on a cloth first before wiping the screen. -
Page 4: Table Of Contents
USB Port ..............11 2.1.4 DC Power Jack w/ M12 connector......11 Water-proof Cables ........12 2.2.1 Power cable(optional) ..........12 2.2.2 Power adapter for GOT810-316 (optional) ....13 2.2.3 COM ................14 2.2.4 USB cables ............... 14 Mounting Method ........15 2.3.1 VESA mount ............. - Page 5 3.4.2 South Bridge ..............31 Security Menu ........... 33 Boot Menu..........34 Save & Exit Menu ........36 Drivers Installation ... 39 CHAPTER 4 System ............39 4.1.1 Installing System Drivers .......... 39 Touch Screen ........... 40 4.2.1 Specification .............. 40...
- Page 6 This page is intentionally left blank.
-
Page 7: Chapter 1 Introduction
Package List General Description The GOT810-316 is a fan-less and compact-size touch panel computer, equipped with a 10.4” XGA TFT LCD display and an Intel® Celeron® Processor N3350 (2M Cache, up to 2.4 GHz), providing excellent computing performance and thermal resistance. This fanless platform is especially designed for space-limited applications in food and beverage industry. -
Page 8: Specifications
GOT810-316 User’s Manual Specifications 1.2.1 Main CPU Board ⚫ ◼ Intel® Celeron® Processor N3350 (2M Cache, up to 2.4 GHz) onboard ⚫ System Memory ◼ One 204-pin DDR3L-1866 SO-DIMM socket ◼ Maximum memory up to 8GB ◼ BIOS ◼ AMI UEFI BIOS ◼... - Page 9 GOT810-316 User’s Manual ◼ 1 x Full Mini-card slot w/ SIM slot (PCIe+USB) ◼ 1 x Full Mini-card slot (PCIe+USB+SATA) (mSATA supported as an option) ⚫ Storage ◼ 1 x mSATA ◼ 1 x 2.5” SATA HDD ⚫ Power connector ◼...
-
Page 10: System Specification
Vibration ◼ 2G / 10 ~ 500Hz / operation (SSD/mSATA, random) 1. All specifications and images are subject to change without notice. 2. The GOT810-316 is suited on serious environment; please choose the wide temperature DRAM and SSD. Note ℃... -
Page 11: Dimensions
GOT810-316 User’s Manual Dimensions This diagram shows you dimensions and outlines of the GOT810-316. Introduction... -
Page 12: I/O Outlets
GOT810-316 User’s Manual I/O Outlets Please refer to the following illustration for I/O locations of the GOT810-316. Function Backlight ON/OFF Brightness Adjust Power Switch(ATX) Ventilation valve DC power connector (A-coded) COM1(configure RS422/485, default RS-232, A-code) COM2(RS232 Only, A-code) USB2.0 × 2 (A-code) -
Page 13: Antenna Installation (Optional)
GOT810-316 User’s Manual Antenna installation (optional) Please refer the following steps to install the optional wireless module, the antenna kits will be placed in the accessory box if we have ordered it. Introduction... -
Page 14: Package List
M12 DC cable x1 (optional) ⚫ Power Adapter (optional) ⚫ Water-proof Power / USB / RS-232 cables (optional) ⚫ Water-proof Antenna for Wifi or UMTS/HSPA+ (optional) If you can not find the package or any items are missing, please contact Axiomtek distributors immediately. Introduction... - Page 15 GOT810-316 User’s Manual This page is intentionally left blank. Introduction...
-
Page 16: Chapter 2 System Configurations
GOT810-316 User’s Manual CHAPTER 2 System Configurations The GOT810-316 provides rich I/O interfacs and flexible expansion ability to meet different application demand. The chapter will show you how to install these hardware configurations, please refer to the following parts. ⚫... -
Page 17: Ethernet
GOT810-316 User’s Manual 2.1.2 Ethernet The GOT810-316 is equipped with a high-performance Plug and Play Ethernet interface, full compliant with IEEE 802.3 standard, and can be connected with a M12 X-CODE LAN connector. Please refer to detailed pin assignment list below:... -
Page 18: Water-Proof Cables
GOT810-316 User’s Manual Water-proof Cables GOT-800 series uses specific M12 connector for water-proof. Therefore you will order each cable base on application. There are four kind cables of GOT810, by the optional, if you will apply the USB, COM or Etherent then you can select a cable for the package. -
Page 19: Power Adapter For Got810-316 (Optional)
GOT810-316 User’s Manual 2.2.2 Power adapter for GOT810-316 (optional) If you order the power adapter, you should choose the power cord type for your location. The power adapter is +24VDC(90W), 110-240V which is combined M12 connector. The power adapter is +24VDC(60W), 110-240V which is combined M12 connector. -
Page 20: Com
GOT810-316 User’s Manual 2.2.3 COM There are two COM cables which are combined M12 connector. Also, you can refer 2.1.1 for the Series port pin assignement. 2.2.4 USB cables The USB cable is combined M12 connector for water-proof. It is extended two USB ports for applicaton. -
Page 21: Mounting Method
GOT810-316 User’s Manual Mounting Method There are two mounting ways for the GOT810-316. One is suspension, the other is VESA mount. 2.3.1 VESA mount The GOT810 can accept VESA 100. System Configurations... -
Page 22: Vesa-Arm Mounting
GOT810-316 User’s Manual 2.3.2 VESA-ARM Mounting Step 1 Find out the 4 screws as marked on the back side of chassis. Step 2 Assemble the VESA-ARM to the back side of the chassis and fix the screws. Step 3 VESA mounting Installation completed. - Page 23 GOT810-316 User’s Manual This page is intentionally left blank. System Configurations...
-
Page 24: Chapter 3 Ami Bios Setup Utility
GOT810-316 User’s Manual CHAPTER 3 AMI BIOS Setup Utility This Section provides users with detailed descriptions about how to set up basic system configurations through the AMI BIOS setup utility. Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the hot keys for the BIOS setup utility can be used at any time during the setup navigation process. -
Page 25: Main Menu
GOT810-316 User’s Manual Main Menu Figure 3-1 Main menu ⚫ System Date / Time Use this option to change the system time and date. Highlight System Time or System Date using the up/ down/ left and right arrow keys (see Figure 3-1). Enter new values through the keyboard. -
Page 26: Advanced Menu
GOT810-316 User’s Manual Advanced Menu Figure 3-2 Advanced Menu The Advanced menu allows users to set configurations of the CPU and other system devices. Select any item on the left to go to the sub-menus (as shown in Figure 3-2). -
Page 27: F81804 Super Io Configuration
GOT810-316 User’s Manual 3.3.1 F81804 Super IO Configuration The ‘F81804 Super IO Configuration’ page is to change the value of the Super IO Configuration. The description of the selected item will appear on the right side of the screen (as shown in Figure 3-3). For items marked with “”, please press <Enter> for further options (as shown in Figure 3-4). -
Page 28: Hardware Monitor
GOT810-316 User’s Manual COM Port Type This option is used to select COM Port Type: RS-232/422/ or 485. Figure 3-4 ‘F81804 Super IO Configuration’ -> ‘Serial Port 1 (COM1)’ 3.3.2 Hardware Monitor Figure 3-5 shows a screen reflecting the health status of the hardware in real time. -
Page 29: Acpi Settings
GOT810-316 User’s Manual 3.3.3 ACPI Settings This screen is used to select options of the ACPI Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. ACPI Sleep State This item allows users to select the Advanced Configuration and Power Interface (ACPI) state to be used for system suspension. -
Page 30: Trusted Computing
GOT810-316 User’s Manual 3.3.4 Trusted Computing This screen is used to select options of the TPM20 Configuration, and then change the value of the selected option. A description of the selected item appears on the right side of the screen. (as shown in Figure 3-7) Figure 3-7 Entering ‘Trusted Computing Settings’... -
Page 31: Cpu Configuration
GOT810-316 User’s Manual 3.3.5 CPU Configuration Figure 3-8 shows a page of CPU configuration with item Intel Enhanced Intel SpeedStep Technology (EIST), Turbo Mode [enable/disable] and Power Limitation Setting related settings. Figure 3-8 Entering ‘CPU Configuration’ AMI BIOS Setup Utility... - Page 32 The default is Comploant 802.3at PoE+ to support PD power input functionality. Power Limitation Setting: Note Since GOT810-316 supports PD power input, we optimized the system configuration to keep the performance and add this item into our BIOS to set the system power consumption limited under 24W to compliance with 802.3at PoE+ standard.
-
Page 33: Sata Configuration
GOT810-316 User’s Manual 3.3.6 SATA Configuration This screen allows users to select options for SATA Configuration, and change the value of the selected option (see Figure 3-9). SATA Controller Highlight this item to set up SATA Controller to be Enable or Disable. -
Page 34: Usb Configuration
GOT810-316 User’s Manual 3.3.7 USB Configuration Please see Figure 3-10 to see what items can be set up under the page of USB Configuration. Figure 3-10 Entering ‘USB Configuration’ 3.3.8 Utility Configuration Figure 3-11 shows the page once entering Utility Configuration. -
Page 35: Pcie/Msata Mini Card Configuration
GOT810-316 User’s Manual 3.3.9 PCIE/mSATA Mini Card Configuration Highlighting item PCIE/mSATA Mini Card Configuration under the Advanced Menu, hit <Enter> to enter a sub-screen as shown in Figure 3-12. There are two choices for Mini Card Mode: PCIE and mSATA. -
Page 36: Chipset Menu
GOT810-316 User’s Manual Chipset Menu The Chipset menu gives memory information about the North Bridge and TXE information about the South Bridge (see Figure 3-13). Figure 3-13 Chipset Menu 3.4.1 North Bridge Memory information about the North Bridge is show in Figure 3-14. -
Page 37: South Bridge
GOT810-316 User’s Manual 3.4.2 South Bridge TXE information about the South Bridge is show in Figure 3-15. Figure 3-15 Entering ‘South Bridge’ OS Selection allows users to select Windows 10(Default) or Intel Linux. AMI BIOS Setup Utility... - Page 38 GOT810-316 User’s Manual AMI BIOS Setup Utility...
-
Page 39: Security Menu
GOT810-316 User’s Manual Security Menu Figure 3-16 Security Menu Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled). AMI BIOS Setup Utility... -
Page 40: Boot Menu
GOT810-316 User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. Users can highlight any of the items on the left frame of the screen to go to any particularsub menus (as shown in Figure 3-17). - Page 41 GOT810-316 User’s Manual ⚫ Setup Prompt Timeout Enter a numeric value here as the length for timeout. ⚫ Bootup NumLock State Use this item to select the power-on state for NumLock. The default setting is [On]. ⚫ Quiet Boot Use this item to enable or disable the Quite Boot state. The default setting is [Disabled].
-
Page 42: Save & Exit Menu
GOT810-316 User’s Manual Save & Exit Menu The Save & Exit menu allows users to load system configurations with optimal or fail-safe default values. Figure 3-18 Save & Exit Menu Save Changes and Exit When users have completed the system configuration changes, select this option to leave Setup and return to Main Menu. - Page 43 GOT810-316 User’s Manual Save Changes Having completed the system configuration changes, select this option to save changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes to save changes. Discard Changes Select this option to quit Setup without making any permanent changes to the system configurations.
- Page 44 GOT810-316 User’s Manual This page is intentionally left blank AMI BIOS Setup Utility...
-
Page 45: Chapter 4 Drivers Installation
CHAPTER 4 Drivers Installation System The GOT810-316 is compatible with operating systems Windows 10 and Windows 10 IoT Enterprise. To facilitate the installation of system drivers, please carefully read the instructions in this Section before any of such installation. 4.1.1 Installing System Drivers Download the driver from Axiomtek website. -
Page 46: Touch Screen
GOT810-316 User’s Manual Touch Screen The GOT810-316 uses the projected capacitive touch. There is the specification which are listed below. 4.2.1 Specification Touch Screen Projected capacitive touch Touch Screen Controller eGalaxy Communications USB interface Resolution 4096 x 4096 Power Input Power Consumption Active<200mA / Idle Mode<100mA... - Page 47 GOT810-316 User’s Manual This page is intentionally left blank. Drivers Installation...
