FORENO FORPT29 Quick Start Manual

Soap Dispenser
Chrome FORPT29
9 421009 512973
Congratulations on your purchase of this high quality product from
Foreno Tapware.
Please read the following before installation and retain (along with
your receipt) for future reference.

TECHNICAL SPECIFICATIONS

Suitable for Standard 1/2 inch BSP Basin Hole (Ø25mm diameter).
Maximum Benchtop thickness = 35mm
For domestic use only.

CONTENTS

• Dispenser Assembly
• 350ml PET Soap Bottle

INSTALLATION

• Dispenser comes fully assembled, requires disassembly to install
• To install in bench or sink top, unscrew and remove soap bottle
• Remove white locknut, leaving rubber washer on threaded flange.
• Remove Pump assembly from threaded flange by gently pulling
pump assembly out of flange
• Insert threaded flange through Ø25mm hole in bench top
ensuring rubber washer is in place for water tight fitment.
• From underneath the bench or sink, handtighten the locknut to
secure the flange to the bench.
• Screw bottle into flange ensuring it is tightened adequately.
• The bottle can be filled with a maximum of 350ml of liquid soap
from above the bench without the need to remove bottle.
• Once filled, gently push the pump assembly into the threaded
flange, and prime pump with 3-4 pumps.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Pump Assembly
Threaded Flange
Rubber Washer
Bench top
(max 35mm)
Locknut
350ml Bottle
