OPERATOR
INSTRUCTION BOOK
Tractor Model:
ITM 470
(2WD & 4WD)
Iran Tractor Industrial Group

Advertisement

loading
Need help?

Need help?

Do you have a question about the ITM 470 and is the answer not in the manual?

Questions and answers

Парахат
March 18, 2025

Метка зажигания

0
1 comments:
Mr. Anderson
May 14, 2025

The ignition mark for Iran Tractor part number ITM 470 is the fourth key position turned clockwise to engage the starter.

This answer is automatically generated

0

Related Manuals for Iran Tractor ITM 470

Summary of Contents for Iran Tractor ITM 470

  • Page 1 OPERATOR INSTRUCTION BOOK Tractor Model: ITM 470 (2WD & 4WD) Iran Tractor Industrial Group...
  • Page 2 OPERATOR INSTRUCTION BOOK ITM 470 TRACTOR (2WD-4WD) Ver.: 01 Collect and edited by research and development center of IRAN TRACTOR MANUFACTURING COMPANY (ITMCo)
  • Page 4 The present manual (Operator Instruction Book) has been compiled by Iran Tractor Manufac- turing Company (ITMCo) and has been intended for tractor owners and drivers operating ITM 470 (2WD/4WD) tractors. It supplies in detail the most essential information about your farm tractor.

  • Page 6: Table Of Contents

    Contents Chapter 1: General information Seat ......... Driving in deep water ....Owner and product specifications Four-wheel drive ....... form ......... Chapter 3: Tractor operation Differential lock ......Introduction ....... Before starting ......Power Take-Off (PTO) ....Warranty, pre-delivery & installa- Normal starting - warm weather .
  • Page 7 Contents Front-mounted weight frame ..level ........Fuel handling and storage .... Roll-Over Protective Structure Power steering pump and reser- (ROPS) ........voir .......... Chapter 5: Specifications Front wheel hubs ....... Engine ........Chapter 4: Maintenance and Front wheel alignment (2WD) ..Transmission ......
  • Page 8 General information Chapter Owner and product specifications form ..Introduction ......... Warranty, pre-delivery & installation ..Safety Symbols and Notes ...... General safety rules ......Safety before operating ......Safety - starting ........Safety — during operation ...... Safety — after operation ......Safety decals ........

  • Page 9: Owner And Product Specifications Form

    NOTE Record the serial numbers of your tractor. Always quote the serial numbers in any communication to your Iran Tractor Manufacturing Company (ITMCo.) Dealer. Tractor serial number (Figs. 1 & 2): ..............Engine serial number (Fig. 3): ....

  • Page 10: Introduction

    General information Introduction vice parts are used.ITMCo Dealers supply (deep water or paddy fields) consult your genuine parts and can give advice regard- ITMCo Dealer for special instructions, or NOTE ing their fitment and use. the warranty may be invalidated. These This book is published for world-wide Extensive damage may occur as a re- tractors are designed solely for use in...

  • Page 11: Warranty, Pre-Delivery & Installa- Tion

    General information Warranty, pre-delivery & installa- full instruction in the basic principles of tion operation and maintenance of the tractor. These instructions will cover instruments The Company, when selling new goods and controls, routine maintenance and to its Dealers, gives a warranty which, safety precautions.

  • Page 12: Safety Symbols And Notes

    General information SAFETY — DANGER, WARNING and or are missing. Replacement decals are CAUTION available from your Dealer in the event of CAUTION loss or damage. The actual location of The symbol and the word CAUTION is these Safety Decals is illustrated at the used to indicate a potentially hazardous end of this section.
  • Page 13 General information children. fire and first aid equipment. exposure to noise may damage the hear- ing. It is recommended that a suitable pro- Fire kit and First Aid tective ear defender is worn on tractors A fire extinguisher and first aid box without a cab fitted.
  • Page 14 General information tions given by the chemical supplier and when taking the tractor and attachments Handle fuel safely manufacturer. upon the highway, they comply with the Diesel fuel is flammable and must be statutory requirements. Always remember handled with care. Passenger to observe the restrictions on the use of Never refuel or service the fuel system...
  • Page 15 General information escaping from a very small hole can be Battery tery electrolyte level if necessary. almost invisible; they can penetrate the 11. Do not produce sparks with cable skin causing serious injury. Keep hands clamps when charging the battery or WARNING and body away from pin holes and noz- starting the tractor engine with a slave...
  • Page 16 General information Starting Fluid WARNING DO NOT use aerosol cans of starting aid on tractors with the thermostart connected to the electrical system. Ether combined with thermostart can cause an explosion with damage to engine, personal injury, or both. Your tractor has been fitted with a thermostart cold starting device.

  • Page 17: Safety Before Operating

    General information is fitted also and used correctly adjusted, avoid accidents. at all times. This equipment is available A defective tractor can injure you and through ITMCO Dealer. DO NOT use a seat others. Do not operate a tractor which is belt if operating without ROPS or a Cab.
  • Page 18 General information Before making adjustments or servic- when using a trailer. yond the point where the threads begin to ing the electrical system, disconnect the Check the brake fluid reservoir and show. battery cables (negative (-) cable first). top-up as necessary. If the fluid level con- Radiator &...
  • Page 19 General information points: disengage the PTO, stop tree engine, re- 1. Always use a safety cage if available. move the key , and make sure that the PTO 2. Do not stand over the tyre. driveline has stopped. 3. Use a clip-on chuck and extension hose when inflating a tyre.

  • Page 20: Safety - Starting

    General information Safety — starting DO NOT bypass the safety start sys- firmly and do not attempt to leave the seat tem by shorting across the terminals of until the tractor has come to rest. the starter motor to start the engine. This If the doors are obstructed, leave the WARNING may cause the tractor to move suddenly.
  • Page 21 General information or implement (whether at the front or rear Avoid sudden or heavy brake applica- of the tractor), the operator must ensure tions when operating in wet, muddy or icy WARNING that all persons are well clear before op- ground conditions or on loose surfaces DO NOT remove the tractor PTO shield erating the hydraulics.

  • Page 22: Safety - After Operation

    General information Safety — after operation Always disengage the PTO, stop the Use a safety chain engine and remove the key before: A safety chain Will help control drawn When stopping at any time, bring the 1. Connecting or disconnecting the PTO equipment should it accidentally separate tractor to a secure halt, apply the parking shaft.
  • Page 23 General information The location of safety decals...
  • Page 24 General information The location of general decals...
  • Page 26 Controls and instruments Chapter General symbols ........Instruments .......... Warning light panel ......... Controls - Operating ......Controls - Genaral ........ Seat ............

  • Page 27: General Symbols

    Controls and instruments General symbols As a guide to the operation of your tractor, various universal symbols have been utilized on the instruments and con- trols. The symbols are shown below with an indication of their meaning. Master lighting switch Left direction indicator Right direction indicator Lower beam...
  • Page 28 Controls and instruments Temperature of cooling Response control water Ignition on Hourmeter Ignition off Low range Thermostart engine start Safety start Thermostart only High range Hazard warning Read operators manual...

  • Page 29: Instruments

    Controls and instruments tank. Temperature gauge (2 Fig. 1) This shows the temperature of the coolant in the engine. Fuel cut off control (13 Fig.1) To stop the engine, pull the control fully OUT to cut the fuel supply to the in- jectors and stop the engine.
  • Page 30 Controls and instruments tion energizes the thermostart heater panel. cancelling. The driver must remember to coil for cold weather starting. cancel it after completing the manoeuvre. Headlight and sidelight switch (9 4. Start. Moving the key to the start posi- When the switch is operated, the Fig.

  • Page 31: Warning Light Panel

    Controls and instruments If they do not operate correctly or light gine is running, and will come on briefly up this will indicate a fault. Check for a Low beam indicator (green) as the engine stops. faulty bulb (see page 96), faulty flasher If this light comes on with the up- unit (see page 99), or a wiring problem.
  • Page 32 Controls and instruments your dealer. Trailer Flasher light (green) Hydraulic oil filter (red) Differential lock engagement warn- ing light Four wheel drive engagement warn- ing light This orange light comes on when the differential lock is engaged. This orange light comes on when the four wheel drive is engaged.

  • Page 33: Controls - Operating

    Controls and instruments CONTROLS — OPERATING 1. Instrument panel 2. Brake pedals 3. Foot throttle 4. Hydraulic control quadrant 5. Hand throttle control lever 6. Response control 7. Differential lock pedal 8. Dual range selector lever 9. Main gear lever 10.
  • Page 34 Controls and instruments Hand throttle control lever NOTE Move the lever down progressively to The dual range selector lever must be increase the engine speed. placed in the central (Neutral) position to engage the safety start switch before the engine can be started. Brake pedals (2 Fig.
  • Page 35 Controls and instruments Foot throttle (3 Fig. 4) The differential lock (2 Fig. 8) me- NOTE chanically locks the rear axle shafts to- Tractors are fitted with a safety start gether so that both wheels pull together. switch that operates in conjunction with WARNING This is an especially important aid when the PTO lever.

  • Page 36: Controls - Genaral

    Controls and instruments Main gear lever (9 Fig. 4) pattern for the gearbox. Levelling lever (Fig. 11) The gear lever knob has a diagram The right hand lower link has a level- engraved on its top face to indicate the ling device which is operated by turning CAUTION respective gear positions.

  • Page 37: Seat

    Controls and instruments up, see page 97. arrow) of the indicator should be level 2. Height adjustment - To adjust the seat with one another. If detent is below the for height, release the two knobs (2) fixed arrow then the seat suspension and move the seat up or down as re- needs stiffening by turning the adjust- quired.
  • Page 38 Controls and instruments Adjust the belt by pulling the short end (4) of the webbing through the adjuster (5) until the belt is comfortably tight. Slide the end along the webbing to take up any slack after final adjustment. Fig. 14: Seat belt...
  • Page 40 Tractor operation Chapter Before starting ........Hydraulic lift system ......Normal starting - warm weather .... Draft control - outer lever - yellow quad- Normal starting - cold weather (thermo- rant ............. start) ........... Position control - inner lever - red sector . Starting the tractor with jump leads ..

  • Page 41: Before Starting

    Tractor operation BEFORE STARTING • Always start and operate the engine should start. in a well ventilated area. 3. Depress the clutch and brake pedals. • If in an enclosed area, vent the ex- Attempt to start the tractor with the haust to the outside.

  • Page 42: Normal Starting - Cold Weather (Thermostart)

    Tractor operation NORMAL STARTING COLD neutral positions, and move the hy- the thermostart on the intake manifold WEATHER (THERMOSTART) Fig. 2 draulic quadrant levers to the ‘DOWN’ (Fig. 2) and insulate the free end of the position. wire. 4. Open the hand throttle halfway. Use the thermostart, particularly in WARNING 5.

  • Page 43: Starting The Tractor With Jump Leads

    Tractor operation STARTING THE TRACTOR WITH ‘NEUTRAL’ position. Then put all the 12. If the engine does not start, repeat the JUMP LEADS auxiliary hydraulic control levers in reheat and cranking cycle, as described their neutral positions. Move the hy- in operations 8 and 9.

  • Page 44: Stopping The Engine

    Tractor operation RUNNING—IN (1) and the other to the tractor battery 4. Ensure that the PTO engagement lever positive (+) terminal (2). is in the ‘DISENGAGED’ position. The following precautions should be taken 5. Connect one end of the other jump lead 5.

  • Page 45: Driving The Tractor

    Tractor operation DRIVING THE TRACTOR eter, the travel speed chart performs two zontal bar indicates the point within basic functions: each ground speed range at which the 1. Checking the tractor ground speed PTO shaft will be operating at 540 rev/ when travelling in a speed limited area.

  • Page 46: Selecting The Correct Gear

    Tractor operation al and slowly increase the hand throt- L - Low - work range. clutch failure. tle opening until the required engine The main gear lever (1) provides the 3. The use of flotation aids such as cage speed is reached. operating gears within the range selected.

  • Page 47: Brakes

    Tractor operation BRAKES stationary work, even if only for short 1. Release the brake pedal latch (1). periods, always engage the parking brake. 2. Apply the brake (2) on the side to 2. The independent brakes (1) may be which the turn is to be made and turn WARNING used to assist turning when travel- the steering wheel.

  • Page 48: Driving In Deep Water

    Tractor operation DIFFERENTIAL LOCK (Fig. 10) iliary position and push the fuel cut-off To engage the four-wheel drive push control fully in. the control knob ‘DOWN’. A green light on 5. DO NOT exceed 3 km/hr (2 mile/hr). the instrument panel will indicate engage- CAUTION 6.

  • Page 49: Power Take-Off (Pto)

    Tractor operation 3. Release the clutch pedal slowly, while working on PTO driven implements, In this tractor the Power Take-Off maintaining foot pressure on the differ- disengage the PTO, stop the engine (PTO) is, Live Drive from the engine using ential lock pedal.

  • Page 50: Attaching To The Pto Shaft

    Tractor operation HYDRAULIC LIFT SYSTEM shield to be bolted to the tractor when pull-type PTO driven equipment is be- ing used. A hole (2) is also provided for WARNING the PTO driveline shield chain. Before operating any of the controls 4.

  • Page 51: Draft Control - Outer Lever - Yellow Quadrant

    Tractor operation sector , the tractor’s lift pump hydrau- slow, and ‘DOWN’ (+) for fast. lic power supplements the auxiliary NOTE system to give additional speed. The control is very sensitive, move slowly and a little at a time. DRAFT CONTROL — OUTER LEVER —...

  • Page 52: Position Control - Inner Lever - Red Sector

    Tractor operation Leaving work: the Position Control Lever. Stop. On reaching the headland, raise the Set the Response Control towards TRANSPORT POSITION implement by moving the Draft Control ‘SLOW’ but in a position to allow ade- Lever back to the ‘UP’ position. Re-enter quately fast entry into work.
  • Page 53 Tractor operation Lever positions (Fig. 17): tween the Sector Marks (4), to find a po- HYDRAULIC MOTORS (Fig. 19) Draft Control (1), fully ‘UP’. sition where the ram neither extends nor NOTE Move Position Control Lever (3) to retracts. Set the adjustable stop (2) below Before connecting a hydraulic motor raise the links to the required height.

  • Page 54: Lifting Linkage

    Tractor operation Operation: rod to adjust the length. Top link To engage the hydraulic motor, move the Draft Control Lever (1) to the fully ‘UP’ WARNING position. DO NOT, in any circumstances, at- To disengage the hydraulic motor, tempt to pull or tow from the top link move the Draft Control Lever (1) to the connection.
  • Page 55 Tractor operation hole (5 Fig. 20). This latter position reduc- out from one side only. es the operating arc of the lower link end. 3. Fit the new ball by locating it with the narrow section in line with the slot, NOTE then refit the spring clip as shown in The lift rod bolts must always be ad-...
  • Page 56 Tractor operation check chain length as shown in Fig. 24. For Category 2 implements set the check chain length as shown in Fig. 26. NOTE Always ensure that with the im- NOTE plement fitted the linkage can travel Always ensure that with the im- through its full range without straining plement fitted the linkage can travel the check chains or stabilizers.

  • Page 57: Attaching An Implement

    Tractor operation ATTACHING AN IMPLEMENT fully raised. 6. Attach the top link to one of the three hitch points on the control beam if fit- ted (Fig. 28). WARNING If two people are involved in attaching an implement, great care must be taken. When making any adjustment to the hy- draulic lift system, the person in the area of the linkage must stand clear.

  • Page 58: Detaching An Implement
