- Page 1 brabura G R I D D L E INSTRUCTIONS MANUAL LID ASSEMBLY M O N S A L U D 2 3 | 0 6 2 2 0 V I L L A F R A N C A D E L O S B A R R O S ( B A D A J O Z ) | S P A I N L A E D 0 0 | b r a b u r a g r i d d l e .
- Page 2 Model No: BGLD0001 LID 40 Model No: BGLD0002 LID 30 Model No: BGLD0003 LID 20 0051...
- Page 3 CONTENTS Introduction Lid dimensions Components list Assembly instructions L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
- Page 4 Please wear gloves when handling. Two or more people should work together to assemble the lid and BRABURA Griddle. To contact us, visit https:/ /www.braburagriddle.com/. * Example image: BRABURA L CLASS 40’’ L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
- Page 5 LID DIMENSIONS LID 20” - Griddle + Lid 22 5/16" 24 1/8" 567mm 613mm 19 11/16" 500mm 7 3/16" 183mm 8 1/4" 210mm front profile Griddle L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
- Page 6 LID DIMENSIONS LID 30” - Griddle + Lid 32 5/16" 24 1/8" 821mm 613mm 19 11/16" 500mm 7 3/16" 183mm 8 1/4" 210mm front profile Griddle L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
- Page 7 LID DIMENSIONS LID 40” - Griddle + Lid 40 5/16" 24 1/8" 1024mm 613mm 19 11/16" 500mm 7 3/16" 183mm 8 1/4" 210mm front profile Griddle L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
- Page 8 COMPONENTS LIST The griddle plate and lid of BRABURA Griddle is designed for easy installation and it is delivered with the components for assembly. The steps for installation are the following: ITEM DESCRIPTION QUANTITY HANDLE L-ENDCAP SCREW M6x16 COUNTERSINK ACORN NUT M6...
- Page 9 ASSEMBLY INSTRUCTIONS The enameled cast iron cooking plate will need to be removed to install the lid Place left-endcap with handle and screw M6-Screw Place right-endcap and screw M6-Screw Excessive Weight Hazard Two or more persons are required to handle the enameled cast iron cooking plate. * Example image: BRABURA L CLASS 40’’...
- Page 10 ASSEMBLY INSTRUCTIONS Assemble and screw M6-Countersink, bearing, lid, washer, lid-bracket and acorn nut M6 Place lid on the chassis and screw with two M4-Screw (both sides) (both sides). Place rubber bumper in each hole * Example image: BRABURA L CLASS 40’’ L A E D 0 0 | b r a b u r a g r i d d l e .
- Page 11 ASSEMBLY INSTRUCTIONS Place enameled cast iron cooking plate Excessive Weight Hazard Two or more persons are required to handle the enameled cast iron cooking plate. * Example image: BRABURA L CLASS 40’’ L A E D 0 0 | b r a b u r a g r i d d l e . c o m...
