Copal PA-838-D Series Instruction Manual

Pressure Transducers
with Amp.
PA-838-D
series
INSTRUCTION MANUAL
1. Attention on handling
...
・The application medium of this product is corrosive gases/liquids compatible with SUS304.
・Never insert any foreign matters, like wire or needle, into the pressure port hole. It causes the breakdown.
・Do not apply exceeding the maximum pressure as shown in the specification. The excessive pressure may affect the sensor characteristics and
may make accurate measurement impossible.
・Do not give unnecessary force to the main body and cable when installing the product. The excessive pressure may affect the sensor characteris-
tics and may make accurate measurement impossible.
・Be sure to connect the output terminals correctly. Wrong connection will cause damage of the internal electric circuit.
・Please supply a stable power source and do not exceed the specified supply voltage. It will cause damage of the electric circuit.
・Please make a high-pressure side the same as the piping condition on a low-pressure side when you lay pipes.（Diameter and length of the
tube etc.）When a transitional pressure fluctuation is caused, it causes the breakdown if the condition is not the same.
・This product is dust proof and drip proof（to IP65 of IEC standards）and is not suitable for use in environments requiring higher standards.
・Please supply a stable power source.
・Place the wiring as far away as possible from the power lines carrying large power. The output becomes unstable because of the noise etc.
2. Part number designation
Please confirm the part number of the product you purchased.
PA−838−□□□D−□□
・F2 type includes 2 pieces of flare fitting in the same package.
3. Instruction for use
Rated pressure, maximum pressure, and line pressure are decided to this product in
each pressure range. Be careful when you use this product.
R a t e d p r e s s u r e : Pressure value in which specification of differential pressure sensor is guaranteed.
（On the specification, it is provided by low pressure side is equal to 0kPa.）
Maximum pressure : Maximum pressure value that can be applied only to one of high pressure side or low pressure side.
L i n e p r e s s u r e : Maximum pressure value in which product is not damaged when equal pressure to high pressure side and low pressure side is applied.
Ver.1.1
This caution mark describes when there is a possibility that user may suffer from damage or physical damage
may occur if the product is used improperly.
Fitting Blank : Rc1/4
F2 : Flare fitting （7/16 -20 UNF）
Rated pressure range １ ０ １： １ ０kPa
５ ０ １： ５ ０kPa
１ ０ ２：１ ０ ０kPa
Thank you for purchasing NIDEC COPAL
ELECTRONICS CORP. product.
In order to use the product correctly and most
appropriately, please completely read this manual
before use and keep it for future reference.
For more details information please ask for the nearest
distributor or the following sales center.
NIDEC COPAL ELECTRONICS CORPRATION
Nishi-Shinjuku Kimuraya Bidg. , 7-5-25
Nishi-Shinjuku Shinjuku-ku Tokyo 160-0023, Japan
Phone ： （03） 3364-7055 FAX ： （03） 3364-7078
1
