ELC focus BRAIN XL User Manual

focus BRAIN XL
512 channel intelligent wireless DMX riggers remote
Users Manual
Software version: 3.0
Version: 0404
focus BRAIN XL
System description
focus BRAIN is the enhanced version of the success full focus
HAND. Where the focus hand was mainly meant as a third
hand for focusing lighting fixtures, replacing the person behind
the lighting desk and the intercom. The focus BRAIN has more
possibility's.
•
Intelligent wireless remote control for DMX-512
•
512 Channels selectable from ranges 1-512 or 513-1024
•
Connected between console and dimmers
•
Merging remote- and console DMX in HTP
•
51 memory's
•
50 groups
• X-Fade possibility, x-fadetime can be programmed to each
memory
•
Focus and Scene mode
• Direct memory mode, including Go button
• 2 Contact closure inputs, as Go or emergency scene
• 2 Contact closure outputs, to be controlled by the remote
• Remote (de-)activation
• Hardware bypass via a relay in case of power failure
The focus BRAIN can store and recall up to 51 memories.
These memories can be created on the remote unit's and / or
capture of the DMX input from the lighting desk. Memories can
be called up directly or with a x-fade time up to 10 sec. The x-
fadetime can be programmed for each memory individually. A
default memory can be created to be automatically recalled at
power on.
The DMX input from the lighting desk can be merged with the
DMX created inside, so that 1 person can focus the fixtures
while the other is programming the lighting desk.
This means focus BRAIN is a versatile controller for the lighting
This product may only be used for controlling dimmers and
moving lights. Using the product out of these specifications will
remove all responsibility from the supplier
