Page 1 SUA 125 NUMERIC UNIVERSAL CENTRE LATHE SUA 125 NUMERIC (VERSION WITH AUTOMATIC SHIFT OF REVOLUTIONS) OPERATING INSTRUCTIONS TOS a.s.
Page 2 SUA 125 NUMERIC Member of the CTY GROUP Stankovského 1892 250 88 Čelákovice Czech Republic YOUR PARTNER FOR SOLUTION OF TECHNICAL PROBLEMS IN TURNING OF WORKPIECES Commercial section Service section Tel.: +420 296 583 213 Tel.: +420 326 633 230...
Page 3 - charakteristics for use - service - maintenance - safe and hygienic operation of SUA 125 NUMERIC universal centre lathe. The performance of the SUA 125 NUMERIC; centre lathe and this Manual, are full in harmony line with the instructions and valid Standards for machinery in member states of the European Union (hereinafter called EU).
Page 4 SUA 125 NUMERIC This Manual is intended only for the SUA 125 NUMERIC / 2000 centre lathe of serial number mentioned below. Order number: 34200003 Customer: SERIAL NUMBER OF LATHE: 34200003 Serial number must be stamped on the front bed part of lathe and on the right hand end of an active surface (in tailstock part) and should be mentioned in all instructions concerning the lathe.
Page 5: Table Of Contents
PURPOSE OF USE OF SUA 125 NUMERIC LATHE....................33 4.1............... 33 EQUIREMENTS FOR LATHE OPERATOR CONNECTED WITH PERSONAL SAFETY DESCRIPTION OF MAIN ASSEMBLIES OF SUA 125 NUMERIC CENTRE LATHE FROM POINT OF VIEW OF THEIR FUNCTIONS............................37 5.1..............................37 ENERAL PRINCIPLES 5.2.
Page 6 SUA 125 NUMERIC 9.1................................88 ANIPULATION 9.2. . 9.2)......................90 IMENSIONS AND MASS OF THE LATHE ERECTION OF LATHE AND ITS PUTTING INTO OPERATION..............91 10.1............................91 UILDING OF FOUNDATION 10.2............................91...
Page 7: Basic Information For User Of Sua 125 Numeric Universal Centre Lathe
2.1. Preface. This Manual of the SUA 125 NUMERIC centre lathe (hereinafter called Manual) is set up in accordance with “The Directive 89/392/EEC“ of June 14, 1989 (hereinafter called Directive) which gives basic demands on safe, hygienic and ecological machinery operation in the states of “European Union“ (hereinafter called EU).
Page 8: Form Of Manual Arranging
SUA 125 NUMERIC 2.2. Form of Manual Arranging. Instructions for operator, data of maintenance and tests, information of possible lathe out of operation together with analysis of operational safety conditions are arranged in this Manual by: - functional and service description - instructions for the operator (Manual) - instructions for maintenance carried out daily by the operator for ensuring the operation capacity.
Page 9: Analysis Of Risk Factors
SUA 125 NUMERIC 2.3. Analysis of risk factors Risk situation. Activity. Dangerous space. Other references. Risk factors in accordance with EN 292 Number. Name. 1. Mechanical risks: 1.1. Crush risk (compression). Workpiece clamping . Workpiece change. Tool change. Between clamp (jaws) and workpiece.
Page 10 SUA 125 NUMERIC 3. Heat risks: No heat risks are occurred. 4. Noise risk with consequent: Noise metering record. 4.1. Reduction of hearing Motion of power and geared parts. Cutting In course of machining. In lathe proximity. process. Noise resonance of machined material.
Page 11 SUA 125 NUMERIC 8. Risks caused by neglecting of ergonomical principles: 8.1. Unhealthy possitions or excessive Lifting and handling of materials In course of loading and unloading, In places of loading, unloading, tool working stress. machined, tools and lathe parts.
Page 12 SUA 125 NUMERIC 10. Risks caused by electric power supply brake, damage of lathe parts and other function defects: 10.1. Electric power supply brake. Lathe control failure with consecutive wrong In the course of work, working At lathe and its parts which are kept use of accumulate energy.
Page 13 SUA 125 NUMERIC 11. Risks caused by missing of wrong located agents seccuring with safety of work: 11.1. All kinds of covers Drive cover 1 60 4891 spindle measuring cover 1 45 8629 lead screw cover 3 08 8049 longitudinal feed cover...
Page 14: Conception Version Of Safety Devices Of The Sua 125 Numeric Lathe With Numerical Control System According To Eu Standards
SUA 125 NUMERIC 2.4. Conception version of safety devices of the SUA 125 NUMERIC lathe with numerical control system according to EU Standards. The main dangerous working space is: -working area with rotating spindle, with moving components for chucking of workpiece e.g.chuck or face-plate and things moving with carriage tool and workpiece.
Page 15 SUA 125 NUMERIC Emergency stop Emergency stop corresponds to EN 60204, the article9.2.5.4 and EN 418, an actuator is located on the main control panel and panel operated movement of tailstock. Change-over switch for mode selection The lathe is equipped with the mode switch which can be selected as “Operating mode“ as “Adjusting mode“. The selection of modes ensures that in every time is only one active mode.
Page 16 SUA 125 NUMERIC Working area The conditions for workpiece chucking. In general. No workpiece clamping devices are controllable if the spindle is rotating. Work clamping device is equipped with a protective shield for supplying of EN 293 requirements. Programm will not run in operating mode sooner until the following conditions are fulfilled: a) max.
Page 17: Universal Safety, Ecological And Hygienic Demands Applied To Conceptional Lathe Version Of Sua 125 Numeric With Eu Standards
2.5. Universal safety, ecological and hygienic demands applied to conceptional lathe version of SUA 125 NUMERIC with EU Standards. Noise. There are suitable means to minimalize risks cased by noise, for example decrease of supply noise or absorption of emitting noise.
Page 18 SUA 125 NUMERIC Safety information It is in accordance with EN 292-2, the article 5 in this Manual. Marking clamping device of workpiece (face plate) is marked with the max. admissible speed. Manual This Manual is in accordance with EN 292 demands, the article 5.5.
Page 19 SUA 125 NUMERIC EN 60947-5-1(part 3) for controlling switches with positive disconnection which are used as mechanically controlled positional sensors for blocking devices of protective shields and for relays used in auxilliary circuits, EN 60947-4-1 for electromechanical concactors and motor starters used in the main circuits,...
Page 20: General Data Concerning Centre Lathe With Cnc Control
SUA 125 NUMERIC 2.6. General Data Concerning Centre Lathe with CNC Control. CNC lathe: is machine tool with the main circular motion (rotary motion) of a rotary workpiece as a rule. It serves predominantly for the machining of outside surfaces of revolution but it is possible to machine inside surfaces of revolution and plane surfaces.
Page 21 SUA 125 NUMERIC CAUTION: Together with the demands on the safe lathe control, this Manual covers and points up also the demands on the hygienic and ecological lathe operation as mentioned below: the demands ensuring the safety of operator are pointed up with the mark, the demands ensuring the hygiene of operation are pointed up with the mark, the demands ensuring the ecology of operation are pointed up with the mark.
Page 22 SUA 125 NUMERIC General rules for the safe service of the machine. Lathe is the source of danger if controlled wrong. It means that the general rules and rules for safety manipulation are not accepted in accordance with this Manual.
Page 23 As a lathe user you must be full aware of all operating risks which are connected with subcontracts and do not cover the subject of the manufacturer production of the SUA 125 NUMERIC centre lathe. It is allowed to add them in operation but the requirements for these subcontracts should be started from further mentioned analysis.
Page 24 SUA 125 NUMERIC follows: 1. Safety instructions for regular application of workpiece chucks. 2. Information for user how to determinate the clamping force and select the suitable chuck. 3. Information of clamping force change during rotation of chuck equiped with the standard moving chuck jaws.
Page 25 SUA 125 NUMERIC CAUTION: When the specific case of machining is occurred or if there is any untypical kind of workpiece, the special regard must be taken to it. The operator can be endangered by means of undesirable emissions. The emission of oil mist and the other products connected with the machining process.
Page 26: Specification Of Machine
SUA 125 NUMERIC Specification of Machine. Charakteristics Designation Type or some other value mark information 3.1. Basic data. Swing: - over bed 1 250 mm - over carriage 930 mm - over steady rest (small) 420/200 mm (large). 630/410 mm...
Page 27 SUA 125 NUMERIC Protection - IP code IP 54 Interference elimination: level 3 34200003 TOS a.s. 02/2011...
Page 28 SUA 125 NUMERIC Data for Instalation and Transport. Overall dimensions of lathe: - lenght 5 400 mm - width 3 550 mm - height 2 100 mm Total weight: - lathe without package 9 500 kg - lathe with seaworthy package...
Page 29 SUA 125 NUMERIC size 80 mm Dead centre: 1 : 10 ČSN 24 3322 - taper - size 80 mm - apex angle of centre 60 degrees Dead centre with nut: - taper 1 : 10 - size 80 mm...
Page 30 SUA 125 NUMERIC - taper 1 : 20 - diameter 100 mm - apex angle of centre 60 degrees Power - controlled movement of tailstock: travel speed 2 m per min. Electrical equipment: push button for tailstock movement - to the right...
Page 31 SUA 125 NUMERIC Numerical control system. FAGOR Type of system: NC 8055 TC Steady rest small with carrying rollers: - max. diameter clamped 420 mm - min. diameter clamped 200 mm Steady rest small with sliding contacts: - max. diameter clamped 420 mm - min.
Page 32: Specification Of Electric Equipment
SUA 125 NUMERIC 3.2. Specification of electric equipment . and electrical schemes included in electrical box. QM 1 Warning: After opening the switchboard the master switch QM 1 will be switched off. Do not make any interventions into its mechanism! 34200003 TOS a.s.
Page 33: Purpose Of Use Of Sua 125 Numeric Lathe
Outside surfaces of revolution of the workpiece supported in centres in lenght equal to the distance between centres can be machined without tool adjustment only in the range of turning lenght. The turning lenght of the SUA 125 NUMERIC lathe is shorter of 80 mm than the distance between centers, when the tailstock sleeve is shifted in.
Page 34 SUA 125 NUMERIC Remove all adjusting wrenches from the working area. Do not touch in the space round the work when remove the chips or sludge. 14. Do not try to handle the guards in turning process. 15. Do not place your hands or body on moving parts of lathe and workpiece. Be careful of the parts which can fall down from the lathe.
Page 35 SUA 125 NUMERIC 38. The aids recommended in this Manual should be used in mounting chuck or face plate. Be sure if the face plate is locked against self - moving when a workpiece is positioned. 39. Tool must be inserted correctly in the tool post.
Page 36 SUA 125 NUMERIC 59. The clamped rotary material which protrudes from of spindle out of the turning area must be secured with auxiliary safety device. 60. Optimal cutting conditions should be selected in turning if there is no technological process.
Page 37: Description Of Main Assemblies Of Sua 125 Numeric Centre Lathe From Point Of View Of Their Functions
- procedure of operator, maintenance and manufacturer for ensuring this functions with the aim of securing the qualitative and quantitative indexes of cutting process. This part of Manual serves for service and maintenance of the SUA 125 NUMERIC lathe. The individual lathe functions are conditioned on: - complying with to the safety requirements of service and maintenance of lathe.
Page 38: Specification Of Functional Assemblies Of Lathe (Fig. 5.1)
SUA 125 NUMERIC 5.2. Specification of Functional Assemblies of Lathe (Fig. 5.1) Suitable arrangement of functional assemblies of lathe is the basic presumption for efficient and safe application of the machine. Description of single units is well - arranged with the aim to make the orientation easy for service and maintenance on the basic of unified terminology.
Page 39 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 40: Driving Section
SUA 125 NUMERIC 5.2.2. Driving Section is located on the left hand rear side of the bed and designed for motion energy transfer from the main electric motor to the input shaft of headstock and consist of: - the main electric motor with V-belt pulley...
Page 41 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 42 SUA 125 NUMERIC - the multi-plate brake mechanical shifting by means of a pair of parallel helical compression springs (herein after called brake) - the single-acting hydraulic cylinder (hereinafter called hydraulic cylinder) -helical compression springs in parallel arrangement (hereinafter called springs).
Page 43: Brake. (Fig. 5.2)
SUA 125 NUMERIC Brake. 5.2.3. (Fig. 5.2) Fig. 5.2 34200003 TOS a.s. 02/2011...
Page 44 SUA 125 NUMERIC Safety functions. The brake completes the braking system of lathe and makes workpiece fixation possible after its stopping. Description of brake function. Brake 6, springs 2 and hydraulic cylinder V 1 for brake control are located on the input shaft of headstock 1.
Page 45 SUA 125 NUMERIC Brake adjustment . (Fig. 5.3) Fig. 5.3 The brake should be adjusted by setting the hydraulic pressure and discharge rate in the hydraulic circuit. Pressure adjustment in the hydraulic circuit. The oil pressure in the hydraulic circuit is to be adjusted with the VP 1 relief valve at about 0,9 MPa. Its value may be read on the pressure gauge Man 1.
Page 46 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 47: Headstock
SUA 125 NUMERIC 5.2.4. Headstock consists of: - gearbox with gears, - work spindle with its bearing, The headstock transmits the rotary motion from the main electric motor to the work spindle through the driving section. The headstock is located on the left hand side of bed. It is of the divided design for easy mounting and repairs and maintenance.
Page 48: Work Spindle
SUA 125 NUMERIC 5.2.6. Work spindle Fig. 5.4 34200003 TOS a.s. 02/2011...
Page 49 SUA 125 NUMERIC is located on the left hand side end of bed. It is very important for turning because the rotary motion is transmitted by means of its front end with spindle flange to the workpiece. The forces arrising from workpiece mass and turning (machining process, cutting process) are taken up in it.
Page 50 SUA 125 NUMERIC Fig. 5.5 Apply the steady force Q (ca 500 N) on the work spindle end in down vertical direction. The measuring of the change in position of work spindle end should be taken by dial indicator in the force F acting direction and its gradual enlarging (force F must be the same but opposite to the force Q - see fig.
Page 51 SUA 125 NUMERIC a 2 =14,6 . ( . Z 2 - 0,001) According to fig. „a“ the value =0,9 =0,88 Constants 14 and 14,6 mentioned in equations for a1 and a2 are determined from publication “SKF Bearings in machine tools“.
Page 52: Reducing Taper
SUA 125 NUMERIC The axial clearance of spindle bearing is impossible to setup - the bearing 234436 B6 was selected at manufacturer with small pre-loading. The work spindle is possible to take out easy after dismantling the headstock cover and loosening screws of front and rear flanges and pins.
Page 53: Ball Circulating Lead Screw
SUA 125 NUMERIC 5.2.7. Ball circulating lead screw is placed along the front part of bed. The left end of ball circulating lead screw is driven by means of separate driving unit through the indented belt. And the second end is supported on bearing on the right bed end.
Page 54 SUA 125 NUMERIC - tool holder All ways are fitted with the adjustable gibs for taking up the clearance. CAUTION (operator): The carriages are equipped with wipers which preserve the guiding ways of carriage and bed against impurities. Their function must be checked by the operator of the lathe.
Page 55 SUA 125 NUMERIC Warning: The longitudinal and cross direction movement (feed) in this Manual is applied to the longitudinal lathe axis, accordingly to the work spindle axis. MAINTENANCE of carriage. Adjusting of clearence in longitudinal saddle guide of tool slide: •...
Page 56: Tailstock (Fig. 5.6)
SUA 125 NUMERIC Tailstock 5.2.9. (fig. 5.6): Fig. 5.6 The tailstock is: - used for locking or mounting of the turned workpiece between centres which is mounted above the carriage (or above the bed). - of a rigid construction, sliding in its guideway by means of a pinion gear with a rack in bed.
Page 57 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 58 SUA 125 NUMERIC Tailstock 16 - Plate 17 - Washer Rubber 18 - Handle 19 - Gear 20 - Case Screw 22 - Ring Yoke 23 - Pinion Yoke 24 - Cover Yoke 25 - Screw 10 - Yoke 26 -...
Page 59 SUA 125 NUMERIC Dial indicator for measuring axial force applied to tailstock sleeve (fig. 5.6) (herein after called indicator) enables: - adjusting of the axial force intensity acting on the tailstock sleeve in dependence on the workpiece mass mounted between centres relevant component of the cutting force.
Page 60 SUA 125 NUMERIC Fig. 5.7 Procedure for drill clamping to the taper adaptor. The taper adaptor should be: • slid in to the tapered hole of the tailstock sleeve. Having placed the taper adaptor in the tailstock sleeve, care is to be taken for distance ring "2"...
Page 61: Load Of Clamping Centre In Dependence On Overhang Of Tailstock Sleeve
SUA 125 NUMERIC 5.2.9.1. Load of clamping centre in dependence on overhang of tailstock sleeve Diameter of tailstock sleeve is 165 mm. Workpiece clamped between centres, centre angle 60. H [mm] [kg] 60 000 6 000 53 000 5 600...
Page 62: Liquid Circuits
SUA 125 NUMERIC 5.2.10. Liquid Circuits. Hydraulic oil circuit (hydraulic circuit) (Fig. 5.3). The hydraulic circuit has been designed for: - the single acting hydraulic cylinder control (working cylinder fig. 5.2) - lubrication of gear box. Specification of the hydraulic circuit: - gear pump C 096 XTM ( 6 l.p.m.
Page 63 SUA 125 NUMERIC Hydraulic chart 34200003 TOS a.s. 02/2011...
Page 64 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 65 SUA 125 NUMERIC Hydraulic set • clean the oil tank. • screw on a tank lid. • srew off oil filler cap and pour oil through the filling hole at the top oil level gauge. • screw on oil filler cap.
Page 66: Lubrication Circuit
Lubrication of lathe must be carried out in accordance with Manual instructions for lubrication. Lubricating system of single lathe units is mentioned below. Lubrication of headstock ( gear box, work spindle) is in the conception version of the SUA 125 NUMERIC lathe as an integral part of the hydraulic circuit.
Page 67 SUA 125 NUMERIC The additional lubrication can be carried out by pressing the push- button for a short time; the push-button is located directly at the lubrication aggregate, a green signal indicator will be illuminated. ATTENTION (Maintenance): When the oil...
Page 68 SUA 125 NUMERIC Fig. 5.8 34200003 TOS a.s. 02/2011...
Page 69: Cutting Lubricant Circuit
SUA 125 NUMERIC Main Electric Motor Greasing in prescribed intervals in accordance with the lubrication chart. Warning: 1. Before every fresh feeling the oil tank should be thoroughly cleaned and flushed with benzol or with special flushing oil. It is recommended to clean the entire lathe well once a year and remove impurities, dust and traces of old oil which have settled and dried on it.
Page 70 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 71 SUA 125 NUMERIC WARNING: ALL LUBRICATED POINDS SHOULD BE CLEANED BEFORE LUBRICATION SUA 125 NUMERIC Running hours for inspection and maitenance of lubrication Machine part Hydraulic and lubricating set Cross Lossy lubrication Power movement of Tailstock feed (TRIBOTEC or bearing...
Page 72 SUA 125 NUMERIC COMPARATIVE TABLE OF LUBRICANTS CZECH OILS Kinematic KORAMO PARAMO AGIP ESSO MOBIL SHELL TEXACO CASTROL 6743 viscosity LUBRICATING OILS ENERGO TERESS VACTR VITRE MAGN POLITE MOGUL OL - J46 FC 46 ACER O 46 A OIL LIS 46 RANDO 40C...
Page 73 SUA 125 NUMERIC COMPARISON TABLE OF CUTTING LUBRICANT L - M ISO 6743/7 Manufacturer: 6743/7 TRIGA BENZINA CINCINNATI SHELL CASTROL BLASER ESSO MOBIL TOTAL OEMETA MILACRON VASCOMILL USK 22 L-MHA VASCOMILL USK 42 SICAMOL NF BLASOMILL LF 1 BLASOMILL LF 2...
Page 74 SUA 125 NUMERIC COMPARISON TABLE OF CUTTING LUBRICANT L - M ISO 6743/7 Manufacturer: 6743/7 TRIGA BENZINA CINCINNATI SHELL CASTROL BLASER ESSO MOBIL TOTAL OEMETA MILACRON BLASOCUT BOHROEL BS 30 LACTUCA L-MAE KS FLUID E Grindex S SOLVAC 1535 G TR 300 BIO Art.890...
Page 75 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 76 Recommended kinds and concentration of cutting coolants used on machine tools TOS a.s. a.s. as manufacturer of machines recommends for user of this machine to use some if bellow mentioned cutting coolant. These liquids dont influence perceptible on the surface of painting film as well as on its adherence of the coating composition used on this machine.
Page 77 SUA 125 NUMERIC ČSN 65 6218 viscosity index °C ČSN EN ISO 2592 Flash point °C ČSN 65 6072 Congealing point ČSN 65 6070 Acidity number Mg KOH/g 0.02 °C ČSN 65 6180 Aniline point MOGUL LK ISO VG 10, 22, 32, 46, 68, 100...
Page 78 SUA 125 NUMERIC CHARACTERISTIC PROPERTIES: ▪ protect very good against wear ▪ protect against corrosion ▪ very good endurance against oxidation is a guarantee of long live time ▪ are not agresive on elastomers in which they are in contact (high aniline points) ▪...
Page 79 SUA 125 NUMERIC function. They also are used for lubrication of helical transmissions especially by circulating lubrication and also as the lubricant for mechanical transmissions. Typical applications of individual viscosity classes of oils this group are following: MOGUL GLISON 46 a MOGUL GLISON 68 - oils used usually for horizontal guideways of machine...
Page 80 SUA 125 NUMERIC BLASER BLASOCUT 2000 UNI Chemical Toxicity and Risk Information CAS Number:98608-26-6 Chemical Name: Blasocut 2000 Universal Synonyms: Mixture of Severely hydrotreated Mineral oil, Chlorinated paraffins European Risk Category for This Chemical: 1.Extremely Dangerous: the LD50 for rabbits exposed by the dermal route is less Risk than 50 mg/kg body weight.
Page 81 SUA 125 NUMERIC NFPA Health Rating for this Chemical 0 = NONE: Materials result in injury under unusual conditions or by NFPA Health: overwhelming dosage. 1= SLIGHT: Short term exposure may result in minor injury that is reversible. 2 = MODERATE: Short term exposure may result in minor temporary or permanent injury;...
Page 82 SUA 125 NUMERIC 4 = EXTREME: Readily explosive under normal conditions. If "YES", this chemical has been identified by the American Conference of ACGIH Skin Governmental Hygienists as one that may permeate intact skin and may cause Notation: toxic effects.: If "NO", this chemical has not been shown to permeate intact skin.
Page 83: Rests
SUA 125 NUMERIC 5.2.13. Rests (fig. 5.8) is designed: for resting of the workpiece when clamped above the carriage. The rests are split, enclosed and equipped with rollers which can be replaced by sliding shoes. For a greater safety and there better function, the motion screws of the cylindrical guiding sleeves are rested in axial direction on plate springs which take up the elastic overload caused by inaccuracy of workpiece.
Page 84 SUA 125 NUMERIC Maintenance of rest. Rest opening: • loosen nuts 1 • swing down screws • raise the upper part of the rest by crane Seting of jaws of rest sleeves: • loosen screws 3 • set the jaws to the working position by means of the crank put on the square end of screw 2 •...
Page 85: Description Of Safety Devices
SUA 125 NUMERIC Description of Safety Devices. The lathe is equipped with following safety devices to prevent or reduce the possibility of an accident when the lathe is in operation: 1) The drive guard - a sheet guard screwed on the rear part of the headstock. The guard serves to prevent the acces to moving parts of the main drive (pulleys, belt).
Page 86: Acoustic Emission Data
SUA 125 NUMERIC Acoustic Emission Data. Acoustic emission data are described in noise metering record in this Manual. 34200003 TOS a.s. 02/2011...
Page 87: Other Emission Data
SUA 125 NUMERIC Other Emission Data. Other emission data are the part of the technical collection and record letters of measuring as far as they are taken individually (connected with emissions of oscillation and vibration and electromagnetic compatibility). 34200003 TOS a.s.
Page 88: Transport Of Lathe
SUA 125 NUMERIC Transport of Lathe. The lathe completaly assembled is transported in packing case or container. 9.1. Manipulation. The lathe completaly assembled is transported on the wooden runners. There are only disconnected the following parts: switchboard, chip pan, current supply incl. coolant supply and current supply to the tailstock.
Page 89 SUA 125 NUMERIC For the transport by crane the lathe bed is provided in front and rear sides by holes for steel bars - signed in front bed body part A and B. Caution: Before hooking on the cran (Fig. 9.1) the forwarder...
Page 90: Dimensions And Mass Of The Lathe (Fig. 9.2)
SUA 125 NUMERIC Transport facilities. When the lathe is being slung: - care should be taken to its correctly balance. Any differences in balance can be partly equalized by displacement of the carriage and the tailstock. - care should be taken the rope not to slip and rest against the protruding parts of lathe.
Page 91: Erection Of Lathe And Its Putting Into Operation
SUA 125 NUMERIC Erection of Lathe and its Putting into Operation. 10.1. Building of foundation. (fig. 10.1) The erection of the lathe in the acurate position on the foundation has a substantial effect on the acuracy of work. Therefore a firm foundation has to be built in due time before the erection of the lathe. The depth of the excavation depends on the local bearing power of the soil and should be sufficient to prevent settling of the foundation under the mass of the lathe.
Page 92 SUA 125 NUMERIC Note: Transport locking part og axis Z marked Z fixed by means of 3 screws the saddle with the bed. Transport locking part og axis X marked X fixed the cross slide with saddle. The bolth locking parts are painted with yellow signal color.
Page 93 SUA 125 NUMERIC Fig. A - transport locking 34200003 TOS a.s. 02/2011...
Page 94 SUA 125 NUMERIC ATTENTION! Do not remember to remove the transport safety element before putting the machine into operation - DANGER OF CRASH ! 34200003 TOS a.s. 02/2011...
Page 95 SUA 125 NUMERIC 34200003 TOS a.s. 02/2011...
Page 96: Working Area
SUA 125 NUMERIC Working area. It is a place which takes the machine including optional extras and a necessary place for lathe operator and materials handling. Workshops where the lathe working area is delimitated must be pursuant to the valid hygienic rules.
Page 97: Ensuring Of Ecological Conditions
SUA 125 NUMERIC 3 x 380 ÷ 415 b) Connection of lathe to the switchboard cabinet: • The main motor with individual cable to the connectors 1, 2, 3, 4, 5, 6 , PE • Other motors with separate cables fitted with the connectors ( 16 + PE ) The 3 phase wires are connected to the terminal connectors marked U, V, W.
Page 98: Determination Of Service Procedures To Achieve Of Working Capacity Of Functional Assemblies
SUA 125 NUMERIC Determination of Service Procedures to Achieve of Working Capacity of Functional Assemblies. Fig. 11.1 Panel FAGOR 8055 TC 34200003 TOS a.s. 02/2011...
Page 99: Basic Information For The Lathe Service
SUA 125 NUMERIC 11.1. Basic information for the lathe service. Description of following service procedures gives only the procedures blocked on conceptional version of lathe. Detailed description of the lathe service procedures is mentioned in “The Operational Manual FAGOR 8055 TC CNC“...
Page 100: Running-On On Reference Points
SUA 125 NUMERIC e) Profile turning (manual) f) Part programmes (manual) 11.1.1. Running-on on reference points When the lathe was switched on, or if a fall-out of electric energy occured, it is necessary to put mechanical components for motion in individual axes in compliance with measuring devices. This is carried out with the aid of running-on on reference points of the lathe.
Page 101 SUA 125 NUMERIC SB19 - Push button for turning spindle - tipping SB20 - Push button for turning spindle - tipping SB23 - push button - emergency stop Fig. 11.2 Panel on the headstock 34200003 TOS a.s. 02/2011...
Page 102: Basic Procedures For Lathe Service
SUA 125 NUMERIC SB 6 – push button for tailstock motor shifting to the left SB 5 – push button for tailstock motor shifting to the right SB 21 – push button - emergency stop Fig. 11.3 Panel on the tailstock 11.2.
Page 103: Spindle Control
SUA 125 NUMERIC CAUTION: For the correct approach to the reference points of lathe it is necessary to finish turning in this way so that the single axes would always be off the home points. 11.2.2. Spindle control Spindle control enables:...
Page 104: Lathe Output Utilization (Fig.11.1)
SUA 125 NUMERIC 11.3. Lathe output utilization (Fig.11.1) In Fig. 11.1 there are mutual relations between: • spindle revolutons per minute and power output transmitted by work spindle. • cutting speed for diameter range 50 to 1050 mm and cutting speed.
Page 105 SUA 125 NUMERIC CAUTION: These values are target, the actual cutting force depends on the chip shape and other factors. Example: Workpiece of 700 mm dia is to be turned by cutting speed v = 50 m/min. According to the table (Fig. 11.1) spindle speed n = 22,4 r.p.m.. By the line interpolation the chip section is about 11,2 square millimeters from 630 mm dia to 800 mm dia and n = 22,4 r.p.m.
Page 106 SUA 125 NUMERIC Warning: Spindle start will only then allowed when the reference points are against positions. Warning: In the moment of the change of transmission speed range dont open any safety guard! Note: In case that above mentioned state may happen, make the small movement from arrested position with lever for given transmission range and give the lever back into same arrested positions.
Page 107: Longitudinal And Transversal Stops
SUA 125 NUMERIC 11.4. Longitudinal and transversal stops. 11.4.1. Transversal stops (Fig.B) consist the couple of stops. • retarding • limit • emergency on one body (1) steady fixed with holder of ball nut (2) and couple of switches SQ 1,2,3 and SQ 4,5,6.
Page 108 SUA 125 NUMERIC Adjust the working position of longitudinal stops at tailstock acc. to required length L and it must be taken into consideration also the steady stops on the proper tailstock and switch SQ 7, 8, 9 steady connected with saddle, which limitate the distance between tailstock and saddle.
Page 109 SUA 125 NUMERIC Working path length is 650 mm Fig. B 34200003 TOS a.s. 02/2011...
Page 110 SUA 125 NUMERIC Longitudinal stops Fig. C 34200003 TOS a.s. 02/2011...
Page 111: Maintenance And Testing Of Lathe
SUA 125 NUMERIC Maintenance and testing of lathe. 12.1. Inspection. The inspection connected with - safety of operation. - reliability of operation. should be ensured by the lathe user in course of lathe life. The inspections of safety of operation are laid down by law and safety regulations in users’s country.
Page 112: Operation Breakdown
SUA 125 NUMERIC Operation breakdown When the power supply to the main electric motor and hydraulic circuit electric motor is broken, the work spindle of lathe will be stopped. The breakdown in the hydraulic circuit - a decrease in pressure, leads to spindle brake to stop.
Page 113: Data For Urgent Help
SUA 125 NUMERIC Data for urgent help. Lathe is equiped with an emergency stopping device in case of urgent help and hazard which is connected with the machining process. Hazards can be occured: - as a result of irregularities (malfunction of lathe, inacceptable characteristics of machined material, operator fault, etc.).
Page 114: The Rest
The symbols used in this Manual are in accordance with ČSN ISO 7000 Standard. Language versions. The Manual for „The SUA 125 NUMERIC Universal Centre Lathe“ has been worked out in the following language versions: English. The part of Manual concerning safety of work and service will be translated to the user’s mother tongue by our society on business contract.
Page 115: Determination Of The Torque Moment Mk For The Given Cutting Conditions According To The Motor Output
SUA 125 NUMERIC Determination of the torque moment Mk for the given cutting conditions according to the motor output This Instruction Manual and further accompanying documentation (Control System Instruction Manual, Software Book, Protocol on Accuracy) supplied with the machine have been focused to a safe, hygienic and ecological operation of the lathe.
Page 116 SUA 125 NUMERIC Tab. 8 Table chart of the specific cutting resistance for steel pevnost oceli Steel strength velikost posuvu Feed měrný řezný odpor Specific cutting resistance s (mm/r.p.m.) 34200003 TOS a.s. 02/2011...
Page 117 SUA 125 NUMERIC Tab. 9 Table chart of the specific cutting resistance for cast iron Skupina obrobitelnosti - (tvrdost HB) Machinability group - (HB hardness) Velikost posuvu Feed Měrný řezný odpor Specific cutting resistance s (mm/r.p.m.) 34200003 TOS a.s. 02/2011...
Page 118: Conclusion
Manual. Dear lathe user, the joint stock company TOS a.s. enters into contact with you mainly in the sphere of service and consultancy. We are sure that the contact will be usefull for both parts.
