Summary of Contents for Racelogic RLACS112F
- Page 1 Li-ion Battery Pack User Manual • 01 - Li-ion Battery Pack Introduction • 02 - Li-ion Battery Pack Charging • 03 - Li-ion Battery Pack Short Circuit Protection • 04 - Li-ion Battery Pack Disposal • 05 - Li-ion Battery Pack Technical Specification •...
- Page 2 01 - Li-ion Battery Pack Introduction A 12 V, 5 Ahr battery pack for use with Racelogic VBOX products. Universal rechargeable Li-ion A battery pack is especially useful if you cannot access the auxiliary power supply of your car or motorcycle, or if you want to avoid accidental data loss which can happen when the unit is power cycled before the data has been transmitted.
-
Page 3: Key Features
• Minimum of 5 hours of use from a full charge (dependent on the power draw of the VBOX unit in use) Versions Product Code Description Compatability Universal rechargeable Li-ion For use with VBOX Micro RLACS112F battery and charger with 2 way Performance Box Sport Fischer Plug Universal rechargeable Li-ion For use with Video VBOX RLACS112H... - Page 4 Set the ON/OFF switch (underneath battery pack) to the 'ON' position. Pressing the 'Test' button should cause the battery charge status to be displayed on the LED gauge. If no LEDs are illuminated, the battery requires charging using the supplied AC adapter. https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 02_-_Li-ion_Battery_Pack_Charging...
- Page 5 AC Charger LED behaviour No power Battery charging Green Battery full charge https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 02_-_Li-ion_Battery_Pack_Charging...
- Page 6 The battery pack features protection against direct short circuit. If the short circuit protection is activated, the battery output will be switched off. To re-instate battery output, set the ON/OFF switch to 'OFF' and then back to 'ON'. https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 03_-_Li-ion_Battery_Pack_Short_Circuit_Protection...
- Page 7 04 - Li-ion Battery Pack Disposal The battery pack contains Lithium-ion cells. Please ensure that it is disposed of at an approved recycling centre. https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 04_-_Li-ion_Battery_Pack_Disposal...
- Page 8 -20 to +60°C (recommended -10 to +50°C) Storage temperature -10 to +40°C (recommended -5 to +35°C) Battery size 157 mm x 76.4 mm x 22 mm Battery weight 420 g Battery gauge Five level LED indicator Over-charge/ over-discharge/ excess current/ short Battery protection circuit https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 05_-_Li-ion_Battery_Pack_Technical_Specification...
- Page 9 This class B digital device complies with part 15 of the FCC rule, EMC standard regulations EN 55022 Class B and Canadian ICES-003. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. https://en.racelogic.support//Product_Info/Modules_and_Accessories/Lithium-ion_Battery_Pack/Li-ion_Battery_Pack_User_Guide/ 06_-_Li-ion_Battery_Pack_Declaration_of_Conformity...
