- Page 1 Since 1956 User Manual LWC694 Wine Storage Freestanding lemairappliances.com.au...
- Page 2 1800 444 357 or email service@hapl.com.au We also carry a complete range of spare parts for all Lemair products. For all your spare parts enquiries please contact our team at Pronto Parts on: 1300 306 973 Lemair is a division of Home Appliances PTY LTD...
-
Page 3: Table Of Contents
--CONTENTS-- IMPORTANT SAFETY INFORMATION ����������������������������������������������������1 DESCRIPTION OF APPLIANCE AND INSTALLATION ����������������������������3 270L ................................3 ACCESSORY INSTALLATION BEFORE OPERATING �������������������������������4 UNPACKING AND CLEANING THE WINE COOLER ................4 LOCK & UNLOCK THE DOOR (FOR OPTION) ..................4 OPERATING THE WINE COOLER ������������������������������������������������������������4 WORKING CLIMATE ..........................4 WINE STORAGE ............................5 CONTROL PANEL ............................6 POWER ON/OFF CONTROL ........................6... -
Page 4: Important Safety Information
INSTRUCTION MANUAL • Please removed all packaging, stickers and films from the products surface and clean the product’ s surfaces with a damp cloth and mild deturgent before using for the first time. • Let the appliance stand upright for approximately hours before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation. - Page 5 INSTRUCTION MANUAL • To ensure proper ventilation for the appliance, the front of the unit must be completely unobstructed. Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.). • Do not attempt to repair or replace any part of the appliance unless it is specifically recommended in this manual.
-
Page 6: Description Of Appliance And Installation
INSTRUCTION MANUAL DESCRIPTION OF APPLIANCE AND INSTALLATION The following pictures only show description of appliance. The dimension and shelf quantity may differ among the models of the same series. „ 270L Dual Zone Door Outside Canbinet Deep Shelf Control Panel Handle Gasket Shallow Shelf... -
Page 7: Accessory Installation Before Operating
INSTRUCTION MANUAL ACCESSORY INSTALLATION BEFORE OPERATING „ UNPACKING AND CLEANING THE WINE COOLER • Remove the exterior and interior packing materials. • 24 hours Let the appliance stand upright for approximately before connecting it to the power source, which helps to reduce the possibility of a cooling-system malfunction from handling during transportation. -
Page 8: Wine Storage
INSTRUCTION MANUAL „ WINE STORAGE • The standard shelves are designed perfectly for Bordeaux bottle storage. The maximum loaded bottles may vary subject to the different size or dimension wine bottles you store. • The shelves can be pulled out by 1/3 approximately for easy access to the wine storage.There are two designs for the pull-out shelves: 1. -
Page 9: Control Panel
INSTRUCTION MANUAL „ CONTROL PANEL • For Dual Zone Upper Zone Temp.Up Display Window Lock / Unlock Temp.Down Power Lighting ºC/ºF Bottom Zone Zone Select Interchange Display Window „ POWER ON/OFF CONTROL • When the appliance is plugged in to a power outlet, it powers on automatically. •... -
Page 10: Temperature Display Window
INSTRUCTION MANUAL „ TEMPERATURE DISPLAY WINDOW • The temperature is displayed in digital which is the best way to be read out. The digital is shown as the set temperature when you are setting the temperature, and it will change to be the real temperature of the inside cabinet after 10 seconds without being touched. -
Page 11: Care And Maintenance
INSTRUCTION MANUAL CARE AND MAINTENANCE „ CLEANING THE WINE COOLER • Turn off the power, unplug the appliance, and remove all items including shelves. • Wipe the inside surfaces with a sponge and baking soda solution. The solution should be about 2 tablespoons of baking soda to 1 quart (approx. 1 litre) of warm water. •... -
Page 12: Troubleshooting
INSTRUCTION MANUAL TROUBLESHOOTING If you feel the appliance is not working properly, follow these instructions to try to see if you can solve the problem simply by yourself before calling for service. No� PROBLEM PROBLEM POSSIBLE CAUSE / MEASURE Not plugged in. The wine cooler does not operate The appliance is turned off. -
Page 13: Reverse The Door Swing
INSTRUCTION MANUAL REVERSE THE DOOR SWING IMPORTANT INFORMATION We recommend that you secure the racks in place using adhesive tape to prevent causing damage when handling the appliance and store all removed parts carefully. Remove the Hole Cover and Upper Hinge Cover on top side using a flat-head screwdriver. Remove the Upper Hinge by unscrewing the Hex Head Srews (4pcs). - Page 14 INSTRUCTION MANUAL Bottom Hinge by unscrewing the Hex Head Screw (4pcs). Unscrew the Pan Head Screw (4pcs) from bottom left side. Now move the Bottom Hinge to the bottom left side and screw it tightly with the Hex Head Screws (4pcs). Move the Pan Head Screw (4pcs) to the bottom right side and screw it.
- Page 15 THIS PAGE HAS BEEN LEFT BLANK INTENTIONALLY...
- Page 16 lemairappliances.com.au...
