ImproX (TAR) Time Attendance Remote Reader
SPECIFICATIONS
Working Environment .................
Input Voltage ................................
Power Requirements
Input Voltage 5 V DC,
Indicators ON, Back-lighting
ON ..........................................
Buzzer
Volume and Tone ...................
Status Indicators
Status LED .............................
Liquid Crystal Display (LCD)
Characters .............................
Character Set .........................
Contrast .................................
Back-lighting...........................
Keypad
Buttons ...................................
Back-lighting...........................
I
MPRO
INSTALLATION MANUAL
MODEL NUMBER: XTA905-1-0-GB-XX
X TAR
The Remote Reader is designed to work in an
indoor (dry) environment, similar to IP50. The
Remote Reader is, therefore, not sealed
against water.
5 V DC, polarity sensitive.
Current (mA)
130
Single tone, with a 4-step adjustable volume.
Bi-colour Red or Green LED (externally
visible). The functions are application specific.
16 Characters by 1 line.
English, Katakana.
Software adjustable in 8 discrete steps via the
Communications Protocol.
Permanently on.
4 Buttons, used for entering Reason Codes.
Permanently on.
Power (W)
0.65
Advertisement
Summary of Contents for impro ImproX XTA905-1-0-GB Series
- Page 1 MODEL NUMBER: XTA905-1-0-GB-XX X TAR MPRO ImproX (TAR) Time Attendance Remote Reader INSTALLATION MANUAL SPECIFICATIONS Working Environment ....The Remote Reader is designed to work in an indoor (dry) environment, similar to IP50. The Remote Reader is, therefore, not sealed against water.
-
