- Page 1 Operation Manual (translation of original document) EHB702 Before installation, commissioning and operation of the lift this docu- mentation needs to be regarded imperatively! Keep this documentation at site of the lift.
- Page 3 E C – D E C L A R A T I O N O F C O N F O R M I T Y Manufacturer: Walter Finkbeiner GmbH Alte Poststrasse 9 - 11 D-72250 Freudenstadt Machine: Electro- hydraulic mobile lifting system for commercial vehicles...
-
Page 4: Table Of Contents
Environment protection ....................... 6 Disposal ..........................6 Origin, property rights ......................6 1.5.1 Made in Germany ....................... 6 1.5.2 © Copyright Walter Finkbeiner GmbH ................7 1.5.3 Trade mark ® ........................7 1.5.4 Patent rights ........................7 1.5.5 Technical changes ......................7 Safety ............................ - Page 5 Checklist on technical inspection ..................49 12.3 Inspection results before first commissioning by the competent person ......50 12.4 Inspection results on a regular verification ................. 51 Walter Finkbeiner GmbH 5 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011...
-
Page 6: General
General 1 General FINKBEINER products are based on decade-long experience in the manufacture of vehicle lifts. The most modern procedures in areas such as construction, production and quality assurance ensure the highest reliability and longevity. 1.1 Delivery of the equipment Before the equipment leaves our plant, it is subjected to careful inspection to ensure that it reaches you in perfect condition and with complete equipment according to your order. -
Page 7: Copyright Walter Finkbeiner Gmbh
1.5.3 Trade mark ® Is a international registered trademark. 1.5.4 Patent rights International patent rights have been registered and accorded to FINKBEINER lifts. 1.5.5 Technical changes Technical changes to the images and technical information reserved for progress purposes. Walter Finkbeiner GmbH... -
Page 8: Safety
Third hazard level. Indicates a possible situation which could result in light physical injury or damage to material assets if not observed. Environment information Information Explanations, tips and background information. Call to action Walter Finkbeiner GmbH 8 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 9: Intended Use
They must be familiar with the operation manual of the lift and the applicable safety regulations and requirements of the respective operating country. Walter Finkbeiner GmbH 9 / 56 Alte Poststrasse 9/11... -
Page 10: General Safety Notes
Unattended operation of the lift can result in severe accidents. • The operation person has to supervise constantly the lift and the lifted load and has to stop the operation immediately if anything is working not correctly. Walter Finkbeiner GmbH 10 / 56 Alte Poststrasse 9/11... - Page 11 The lift may be used on an even and sufficiently stable floor only. CAUTION Hazard of injury. • Wear suitable protective clothing according to the applicable safety regulations. Walter Finkbeiner GmbH 11 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011...
-
Page 12: Technics
Admissible temperature range: -5° bis 50° C Admissible ground inclination: 1° Noise level: < 70 dB(A) Hydraulic oil: HLP ISO-VG 32 Surface treatment: Powder coating Walter Finkbeiner GmbH 12 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 13: Safety Equipment
Pressure relief valve: protection from exceed pressure. • Mechanical lock: additional protection from unintended lowering. • Rear wheel jack: brake to prevent column to roll away. Walter Finkbeiner GmbH 13 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 14: Dimensions Ehb702
Technics 3.3 Dimensions EHB702 Walter Finkbeiner GmbH 14 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 15: Dimensions Ehb702 Version „Hymer
Technik 3.4 Dimensions EHB702 version „Hymer“ Walter Finkbeiner GmbH 15 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 16: Labels On The Lift
Baujahr: Tragkraft: Year: Capacity: Druck: Gewicht: Pressure: Weight: Motoranschluss: Operat. Voltage: Steuerspannung: Control Voltage: Made in Germany Wheel fork Oil level Capacity 2,5 t Walter Finkbeiner GmbH 16 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... - Page 17 Labels Control box master column Control box slave column Security advices Walter Finkbeiner GmbH 17 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
- Page 18 • Do not climb up the lift or the lifted vehicle. • After operation the main switch has to be switched-off and locked against unauthorised use. • Regard Operation Manual of the lift. Walter Finkbeiner GmbH 18 / 56 Alte Poststrasse 9/11...
-
Page 19: Commissioning
The columns are shipped in vertical position and are connected by wooden or steel beams. • Remove packing material before unloading. • Move columns individually out of the container Walter Finkbeiner GmbH 19 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 20: Electrical Connection
• If the lift is used at some other location or at use of an electrical extension cable the phase se- quence may be incorrect and needs to be checked again. Walter Finkbeiner GmbH 20 / 56 Alte Poststrasse 9/11... -
Page 21: Detailed Operation Instructions
Wheel jack is self-lowering under load. • Under load the column must lower completely to the ground. • Adjust ground clearance as small as possible. Walter Finkbeiner GmbH 21 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 22: Hydraulic Travelling Device (Option)
Crushing hazard when lowering the travelling device. • Do not crush feet underneath base frame when lowering. Lower the travelling device completely to ground after movement of column. Walter Finkbeiner GmbH 22 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 23: Installation
The master (black) can be located at every position. Information • One master column is suitable to be operated with up to 5 slave columns (at 400 V / 3 Ph / 50 Hz). Walter Finkbeiner GmbH 23 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 24: Cable Connection
• The fork tines must lie close to the underside of the wheel, so that, should the tyre lose air, there is no danger of the tyre to slip through. Walter Finkbeiner GmbH 24 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... - Page 25 It is prohibited to cause height differences between the columns, for example in individual operation. Without load Overlaod vehicle centre of gravity Overlaod Without load This lift is too low Walter Finkbeiner GmbH 25 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
-
Page 26: Wheel Fork
Adjust wheel forks according to the respective wheel size. Position the columns at the vehicle. Join columns to one another using the connecting cable around the vehicle. Lock the plugs in the sockets. Walter Finkbeiner GmbH 26 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 27: Operation
The EMERGENY-STOP push-button at each column switches off immediately the complete lift set. • The activated EMERGENY-STOP push-button is locked and needs to be released to operate the lift. Walter Finkbeiner GmbH 27 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 28: Lifting And Lowering
For lifting and lowering press the corresponding push button. Raise the vehicle off floor approx. to a height of 5 centimetre and check safe contact of load sup- port immediately. Walter Finkbeiner GmbH 28 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 29: Cleaning
Remove all dirt carefully with a sponge or brush. Regard no residues of detergents remain on the lift. Dry the lift after cleaning with a cloth and spray it with wax or oil spray. Walter Finkbeiner GmbH 29 / 56 Alte Poststrasse 9/11... -
Page 30: Inspection And Maintenance
Check operation elements, cables and plug connections for damage. Check oil level of oil tank and refill oil if required. • Oil to be used: see chapter “oil change” Walter Finkbeiner GmbH 30 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 31: Annual Inspections
Grease switch cams (3.01, carriage rollers (3.04, 4 pcs.) and flat spring on wheel jack (2.01) with multipurpose grease. Instruction At multi-shift operation or if the lift is used in wet areas, the maintenance rate must be reduced. Walter Finkbeiner GmbH 31 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 32: Oil Change
Yearly • Visual and function inspection by a competent expert with entry in the Inspection Log. Differing maintenance intervals to be regarded according the country-specific regulations. Walter Finkbeiner GmbH 32 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 33: Failures
Shut down the lift and secure the main switch with a padlock until competent repairs have been carried out. • The lift may only be returned into operation if it is in perfectly safe condition. Walter Finkbeiner GmbH 33 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 34: Possible Failures And Fault Repair
L1 and L2 at plug of power supply. Cable connection to valve Check cable connection, clean or „lifting“ (hydraulic diagram change valve. pos. 13) or valve defective. Walter Finkbeiner GmbH 34 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 35: Locating Defective Column
“fault repair on the defective column”. If first slave column is operative: Extend the system successively by one further slave column, until the defective slave column is located see next chapter. Walter Finkbeiner GmbH 35 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 36: Fault Repair On The Defective Column
Check connections inside of plugs / sockets as well as the interconnect cable for contact or dam- age. Check the roller limit switches and switch cam see chapter “check of limit cycle switches and switch cam“. Walter Finkbeiner GmbH 36 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 37: Emergency Lowering - Lowering During Failure
Hazard of vehicle to fall by non-prescribed emergency lowering. • Observe the vehicle do not get into a dangerous inclined position. • Lower the columns individually within small increments. Walter Finkbeiner GmbH 37 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... - Page 38 Lower the columns one by one, within small increments. Close all emergency lowering screws and fix all counternuts. Switch-off the main switch and secure the lift against unauthorized use until lift has been repaired. Walter Finkbeiner GmbH 38 / 56 Alte Poststrasse 9/11...
-
Page 39: Spare Parts Lists And Circuit Diagrams
Spare parts lists and circuit diagrams 10 Spare parts lists and circuit diagrams 10.1 Overview mechanical parts with spare parts list Walter Finkbeiner GmbH 39 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... - Page 40 XCMN2102L2 spring D165A housing for limit cycle switches 706070100007 hydraulic power unit See hydraulics control box (see chapter electrics) See electrics Walter Finkbeiner GmbH 40 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
-
Page 41: Overview Hydraulics With Spare Parts List
WT1089 Oil tank steel 7060803016-RAL7015 Pressure relief valve VENDB DBT1 Valve lifting VEN2/2S024NO Valve lowering VEN2/2S024NC 2.10 Current regulating valve 69007829-03 Walter Finkbeiner GmbH 41 / 56 Alte Poststrasse 9 - 11 PB-BA-EHB702-101GB 72250 Freudenstadt / Germany 11/2010 www.finkbeiner.eu... -
Page 42: Overview Electrics
Spare parts lists and circuit diagrams 10.3 Overview electrics Master column Slave column Walter Finkbeiner GmbH 42 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... - Page 43 S1 cable to cycle switch S2 cable to lifting valve cable to lowering valve cable to solenoid of mechanical lock Walter Finkbeiner GmbH 43 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011...
-
Page 44: Electrical Circuit Diagram Master Column
Spare parts lists and circuit diagrams 10.3.1 Electrical circuit diagram master column Walter Finkbeiner GmbH 44 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 45: Spare Parts List Master Column
(16 pol.) MHO16L32 plug inset (16 pol.) JCSEM16 socket housing (16 pol) 7132516280 socket inset JCSEF16 power supply cable, 4x2.5, 10m with plug KAB-706-ZUL Walter Finkbeiner GmbH 45 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 46: Electrical Circuit Diagram Slave Column
Spare parts lists and circuit diagrams 10.3.3 Electrical circuit diagram slave column Walter Finkbeiner GmbH 46 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 47: Spare Parts List Slave Column
HT-D 70-N 24VDC electric motor interconnect cable black 10m with plug KAB-706-RING-10M-PUR plug housing MHO16L32 plug inset JCSEM16 socket housing 7132516280 socket inset JCSEF16 Walter Finkbeiner GmbH 47 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 48: Accessory
Turn key-switch clockwise and keep it in this position. Press UP or DOWN push button. Information FINE-operation • When releasing the UP/DOWN push button the movement of the lift is interrupted immediately. Walter Finkbeiner GmbH 48 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011... -
Page 49: Inspection Log
Functional inspection of lift with nominal load (vehicle) • Completeness of operating manual incl. inspection log • Entry in inspection log • Attach inspection label on lift • Write inspection report Walter Finkbeiner GmbH 49 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... -
Page 50: Inspection Results Before First Commissioning By The Competent Person
The lift has been tested in operation und function; thereby no failures were ascertained. There are no objections to commission the lift. The Competent Person ppa. Guenther Obmann Employed at: Walter Finkbeiner GmbH Alte Poststrasse 9-11 72250 Freudenstadt Walter Finkbeiner GmbH 50 / 56... -
Page 51: Inspection Results On A Regular Verification
/ stamp of authorized expert / competent person Operator Deficiencies noticed: _____________________________________ signature operator Deficiencies repaired (date): _____________ _____________________________________ signature operator *) Delete non-applicable Walter Finkbeiner GmbH 51 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu... - Page 52 / stamp of authorized expert / competent person Operator Deficiencies noticed: _____________________________________ signature operator Deficiencies repaired (date): _____________ _____________________________________ signature operator *) Delete non-applicable Walter Finkbeiner GmbH 52 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
- Page 53 / stamp of authorized expert / competent person Operator Deficiencies noticed: _____________________________________ signature operator Deficiencies repaired (date): _____________ _____________________________________ signature operator *) Delete non-applicable Walter Finkbeiner GmbH 53 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
- Page 54 / stamp of authorized expert / competent person Operator Deficiencies noticed: _____________________________________ signature operator Deficiencies repaired (date): _____________ _____________________________________ signature operator *) Delete non-applicable Walter Finkbeiner GmbH 54 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
- Page 55 / stamp of authorized expert / competent person Operator Deficiencies noticed: _____________________________________ signature operator Deficiencies repaired (date): _____________ _____________________________________ signature operator *) Delete non-applicable Walter Finkbeiner GmbH 55 / 56 Alte Poststrasse 9/11 PB-BA-EHB702-102GB 72250 Freudenstadt / Germany 22.02.2011 www.finkbeiner.eu...
- Page 56 Walter Finkbeiner GmbH Alte Poststrasse 9 - 11 72250 Freudenstadt / Germany Tel.: +49-7441-4031 Fax: +49-7441-87778 E- mail: info@finkbeiner.eu www.finkbeiner.eu...
