Fuel & Oil Cleanliness Analyser
User Manual
© Copyright 2022 Filtertechnik
Fax:
+44 (0)115 986 8875
Web:
www.filtertechnik.co.uk
FS9V4
August 2022
V1.01
Registered in England No: 03969985 VAT No: 760 821 731
1 of 26
Certification No. UK002838
Advertisement
Table of Contents
Related Manuals for Filtertechnik FS9V4
Summary of Contents for Filtertechnik FS9V4
- Page 1 FS9V4 Fuel & Oil Cleanliness Analyser User Manual August 2022 V1.01 © Copyright 2022 Filtertechnik Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk Registered in England No: 03969985 VAT No: 760 821 731 Certification No.
-
Page 2: Table Of Contents
Density ............................18 Viscosity ............................18 High-Pressure Device (HP) ........................19 Troubleshooting ............................ 20 General Operational Errors ....................... 20 Particle Counting ..........................20 Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk... - Page 3 Particle Count ISO Codes ........................22 ISO Codes (ISO4406) .......................... 22 ISO Decimal Codes ..........................23 Warranty Statement ..........................25 EC Declaration of Conformity ........................ 26 Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax:...
-
Page 4: Specifications
Factory calibration certificate CE declaration Verification frequency 12 months recommended PC requirements Windows/Mac (with USB port), spreadsheet software (e.g. MS Excel) Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk... -
Page 5: Component Identification
2.) Pump on/off switch 6.) Suction / Inlet (Minimess Test Point) 3.) Display/sensors on/off switch 7.) USB port (at rear of case) 4.) Charging port Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax:... -
Page 6: Suction & Return Hose Connections
Placing a finger over the end of the hose can prevent oil dripping out of the test point onto the fascia of the unit. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 7: Suction Strainer
The strainer can be disassembled for cleaning as shown below and should be checked periodically to ensure the flow is unrestricted. When taking apart the strainer, note the orientation of the mesh for correct reassembly. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 8: Operating The Unit
Time and remaining battery capacity is also displayed. The ISO code can change from white to green or red depending on the alarm limits set. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR... -
Page 9: Priming And Flushing The Pump
At the bottom left of the settings page the software version is displayed. Priming and Flushing the Pump In some situations, the pump speed may need to be increased for priming or flushing the unit. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 10: Iso Alarm Limits
This creates a new log file but does not delete the previous. Clearing log files from the device must be done through the software, either the Particle Pal CSV Reporting Tool or the Particle Pal Device Utility. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 11: Time Zone Adjustment
The display screen is pre-set with the date and date to GMT +0 (UK time) this can be adjusted according to your time zone if required. Specific time adjustments can be done via the Particle Pal Device Utility software. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 12: Entering A Test Name
The test name will show as a repeating field in the data log file, for easily finding the relevant test. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR... -
Page 13: Battery Charging
The charger has a small LED which when connected to a discharged unit will illuminate red. Once charging is complete the LED will turn green. Note the LED will not turn green if the unit is switched on and in use. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 14: Fluid Viscosity
The internal gear pump provides a steady flow for accuracy of results. Fluids above the rated viscosity can cause excess motor strain and cause it to overheat or slip. It’s important to pay attention to the grade of oil being analysed and its temperature. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 15: Water Sensor - % Saturation (Rh)
However, even dissolved water can cause damage, therefore every reasonable effort should be made to keep the saturation levels as low as possible. As a guideline we recommend maintaining saturation levels below 45% in all equipment. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 16: Sensor Specifications
If the fluid sample contains free water, it should not be passed through the portable analyser. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 17: Water Sensor - Parts Per Million (Ppm)
18-28 VDC Power consumption 30-70 mA Output 4-20 mA Protection type IP65 Recalibration Intervals depend on use, recommended annually Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk... -
Page 18: Density And Viscosity Sensor
Example: If the unit is showing a viscosity of 150 mPa.s and density of 886 kg/m³ then, 150 / 0.886 = 169.3 cSt Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600... -
Page 19: High-Pressure Device (Hp)
Fluid passing out of the discharge/outlet tube should be fed into a suitably sized sample container for disposal or emptying back into the fluid reservoir. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel:... -
Page 20: Troubleshooting
Water content Damaged moisture Permanent damaged due to excessive moisture. Sensor bouncing from sensor. will require replacing. near 0 to 100% Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk... -
Page 21: Water Sensor - % Saturation (Rh)
Negative measuring error Corrosion Return to supplier for cleaning Long-term drift Abrasion or repair Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk... -
Page 22: Particle Count Iso Codes
160000 320000 320000 640000 640000 1300000 1300000 2500000 2500000 ∞ Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk Registered in England No: 03969985 VAT No: 760 821 731 Certification No. -
Page 23: Iso Decimal Codes
13.1 44 18.1 1420 23.1 44000 28.1 1420000 8.2 1.54 13.2 48 18.2 1540 23.2 48000 28.2 1540000 Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk... - Page 24 14.8 144 19.8 4500 24.8 144000 – – 9.9 4.75 14.9 152 19.9 4750 24.9 152000 – – Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk...
-
Page 25: Warranty Statement
Limited Express Warranties, and no others: For a period of one (1) year from and after the date of delivery of a new Filtertechnik product, Filtertechnik warrants and guarantees only to the original purchaser/user that such a product shall be free from defects of materials and workmanship in the manufacturing process. -
Page 26: Ec Declaration Of Conformity
EC Declaration of Conformity Manufacturer’s Name: Filtertechnik Ltd. Manufacturer’s Address: 1 Central Park, Lenton Lane, Nottingham, NG7 2NR EC Representative’s Name: EC Representative’s Address: Equipment Description: Portable analysers for fuel and oil Equipment Model Designation: FS9V4 Application of Council Directive:...
