- Page 1 Operator's Manual TX210 UTV JUMP SEAT MODEL TX210 Maximum Field Rating 500 lbs. Get parts online at P/N: OMTX210 © 2020 Ardisam, Inc. C/N: 18294 www.yutrax.com All Rights Reserved REV2: 06/12/2020...
-
Page 2: Introduction/Warranty
WARRANTY Yutrax, a division of Ardisam Incorporated, offers a one year limited warranty to be free from defects in materials and workmanship for the service life of the product, not to exceed twelve consecutive months from the date of purchase. This warranty applies to the original owner with a proof of purchase and is not transferable. -
Page 3: Warnings
UTV with backrest against UTV cab. Never use when intoxicated or using over-the-counter medication or prescription drugs. Never use with more than two passengers. Never use carelessly – Think Safety! Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5... -
Page 4: Assembly Instructions
SEE FIGURE 1B. Receivers should both be mounted on what would be the “outer” sides of the upright frames when unit is completely assembled. locknut upright frame FIGURE 1B Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5... - Page 5 NOTE: Mount the seat frame so the hole in the side of frame are towards seat frame the front of the unit, away from the backrest. steel washers locknuts locknuts upright frames seat pivot tubes FIGURE 2B Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5...
- Page 6 This permanently attaches the seat belt strap to the Jump Seat. You may temporarily buckle the male ends to the seat belt receivers. SEE FIGURES 4A & 4B. FIGURE 4B Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5...
- Page 7 14. Attach the padded seat to the top side of seat frame and snap the side release buckles together. Pull straps tight so seat is not loose. Attach padded backrest to backrest frame and secure with Velcro. FIGURE 6 Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5...
- Page 8 1/4-20 X 2-1/4" 48851 SAFETY CAM STRAP 48017 SPRING LOCKPIN, ROUNDED 48828 STRAP ASSEMBLY, FEMALE RETAINER 1/4 X 2" 48829 STRAP ASSEMBLY, MALE 1401B BOLT, HHCS GR5 BLK 5/16-18 X 1-1/4" Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5...
-
Page 9: Illustrated Parts Breakdown
Operator's Manual TX210 UTV JUMP SEAT ILLUSTRATED PARTS BREAKDOWN Check for parts online at www.yutrax.com or call 800-345-6007 M-F 8-5... - Page 10 YUTRAX™, A Division of Ardisam, Inc. Phone: 800-345-6007 1160 Eighth Avenue, PO Box 666 Fax: 715-822-2124 Cumberland, WI 54829 www.yutrax.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product...
