Summary of Contents for Klutch 57392
- Page 1 1/2In. Mini Air Regulator Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #57392...
- Page 2 Thank you very much for choosing a Klutch™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Product ........................... 7 Assembly Instructions .......................... 8 Before Each Use ............................ 8 Operating Instructions .......................... 8 Maintenance ............................ -
Page 4: Intended Use
Flow Rate (Max)** Height Width Port Size Part # Size Inch ½” 1/8” 57392 4000 2.75 Important Safety Information ⚠WARNING Read and understand all instructions. Failure to follow all instructions may result in serious injury or property damage. ... - Page 5 this equipment for a purpose for which it was not intended. Industrial or commercial applications must follow OSHA requirements. ⚠WARNING WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury.
-
Page 6: Specific Operation Warnings
product with a damaged part. Store the air regulator when it is not in use. Store it in a dry, secure place out of the reach of children. Inspect the tool for good working condition prior to storage and before re-use. ... -
Page 7: Main Parts Of Product
Main Parts of Product Ref # Description Qty. Knob Locknut Indicator Ring Philip Head Screw Bonnet Bearing Washer Adjusting Screw Assembly Main Spring Diaphragm Assembly Venturi Tube Housing Port Plug Assembly Port Plug 12.1 O-Ring 12.2 Valve Cone Assembly Bottom Spring O-Ring Bottom Plug O-Ring... -
Page 8: Assembly Instructions
Assembly Instructions 1. Install in a clean/ acid free atmosphere. 2. Flush the piping for dirt, dust, and other foreign particles. 3. Use proper thread sealant for taper threads to create a leak-proof connection. 4. Screw the Inlet/Outlet pipe with the respective port. 5. -
Page 9: Maintenance
Maintenance 1. Before dismantling the unit, exhaust the air in the line completely. 2. Dismantle the components and clean them in kerosene and blow with compressed air. 3. Check for damages in the O-rings (15), (16.1), (17) and at sealing areas in the valve cone rubber, spherical relieving seating, seating area of the housing, etc. -
Page 10: Parts Diagram
Parts Diagram Page 10 of 13... -
Page 11: Parts List
Parts List Reference Item Description Quantity Knob Locknut Indicator Ring Philip Head Screw Bonnet Bearing Washer Adjusting Screw Assembly Main Spring 0.2 - 2 BAR (3 - 28 PSI) 0.2 - 4 BAR (3 - 58 PSI) 0.5 - 7 BAR (8 - 100 PSI) 0.5 - 10 BAR (8 - 145 PSI) Diaphragm Assembly Venturi Tube... -
Page 12: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 13 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in India Page 13 of 13...
