- Page 1 ACCELERATION MEASUREMENT H I G H W A Y ACCELERATION MEASUREMENT BREAKING D I S T A N C E MEASUREMENT 1/4 MILE RACE 399.8 KM/H MAX. SPEED MOTOR CYCLE COMPUTER MC 18...
- Page 2 MC 1812 www.sigmasport.com MC 1812 Page 2...
-
Page 3: Table Of Contents
2.1 Attaching the bracket ............................ 7 2.2 Attaching the sensor ............................. 7 2.3 Connecting the sensor to the bracket ....................7 2.4 Attaching the Sigma MC 1812 to the bracket .................. 8 2.5 Initial use ................................8 2.6 Initial use of the sensor ..........................8 2.6.1... - Page 4 MC 1812 Contents 5.6 Acceleration measurement ........................18 5.7 Highway acceleration measurement ...................... 19 5.8 Braking measurement ..........................19 5.9 Drag race/quarter-mile race ........................19 Reset functions ..........................20 6.1 General functions ............................20 6.2 Mode 2 functions ............................20 Important information, troubleshooting, and FAQ ..............21 7.1 Important information ...........................
-
Page 5: Functions And Packaging Contents
Thank you for choosing a SIGMA SPORT motorcycle computer. Your new MC 1812 will be a loyal companion for your motorbike trips for years to come. To familiarize yourself with and learn how to use the many functions of your new motorbike computer, please read these operating instructions carefully. -
Page 6: Packaging Contents
MC 1812 quick start guide 1.3 MC 1812 functions The MC 1812 is a versatile motorcycle computer. In addition to the classic functions, the MC 1812 can also measure the average speed, maximum speed, acceleration, highway acceleration, braking coefficient, and braking distance. -
Page 7: Attaching The Mc 1812 And Initial Use
MC 1812 Attaching the MC 1812 and initial use Attaching the bracket Attaching the MC 1812 and initial use Detailed attachment information can be found in the quick start guide provided. 2.1 Attaching the bracket − Attachment to the handlebars or cockpit −... -
Page 8: Attaching The Sigma Mc 1812 To The Bracket
The MC 1812 jumps to setting mode. 2.6 Initial use of the sensor To use the sensor, the MC 1812 must be clicked into the bracket. As soon as at the wheel has rotated at least twice, the speed, for example, will appear on the display. -
Page 9: Operating Concept
MC 1812 Operating concept Button functions Operating concept 3.1 Button functions Reset button Mode 2 button Press this button to scroll Press this button to scroll forward backward through the Mode 2 through the Mode 2 functions. functions. Basic settings menu: Press and hold this button to (+) button, forward. -
Page 10: Button Functions For Basic Settings
Unit Wheel size Time 3.2 Display structure The MC 1812’s display is divided into two main areas: 3.2.1 Top display segment This always displays your current speed in either KMP or MPH. The unit can be set in the basic settings menu. -
Page 11: Basic Settings
MC 1812 Basic settings Acceleration measurement Basic settings Mode 2 Reset Accessing the basic settings menu: - Press and hold the button for three seconds. - ‘Setting OPEN’ appears in the bottom display segment. - ‘Setting OPEN’ flashes. - The first menu item appears on the display: ‘Accel.’ and Mode 1 ‘0 - 100’... -
Page 12: Highway Acceleration Measurement
MC 1812 Basic settings Highway acceleration measurement 4.2 Highway acceleration measurement Reset Mode 2 Press the button to switch to the ‘highway acceleration’ menu. Mode 1 Press the button. ‘Start speed’ and ‘60’ (default value) appear. Press (+) or (-) to set the value you desire. -
Page 13: Total Distance
MC 1812 Basic settings Total distance 4.4 Total distance Reset Mode 2 Use this area to enter existing values (e.g. transferred from your old device). New values are then added to these (see also section „5.2 Trip distance“). Press the button to switch to the ‘Total dist.’... -
Page 14: Contrast
MC 1812 Basic settings Contrast 4.6 Contrast Reset Mode 2 Press the button to switch to the default menu item ‘Contrast’. Mode 1 Press the button. The digit displayed flashes. Press (+) or (-) to set the value. (1=weak/3=strong) Mode 2... -
Page 15: Wheel Size
MC 1812 Basic settings Wheel size 4.9 Wheel size Reset Mode 2 Press the button to switch to the ‘Wheel size’ menu. Mode 1 Press the button. The first two digits for entry flash. Press (+) or (-) to set the value. -
Page 16: Time
MC 1812 Basic settings Time 4.10 Time Reset Mode 2 Press the button to switch to the ‘Time’ menu. Mode 1 Press the button. The hours digit flashes. Press (+) or (-) to set the value. Mode 2 Reset Press the button to move to the minutes. -
Page 17: General Mc 1812 Functions
You bear full responsibility for the use of this device. Press any button on the MC 1812 to exit standby mode. The speed indicator appears in the top display segment and ‘Trip distance’, for example, appears in the bottom display segment. -
Page 18: Average Speed
5.6 Acceleration measurement Reset The MC 1812 has an acceleration measurement function. The function ‘0...100/sec’ (default value) starts from standstill. During the measurement, ‘calc.’ appears on the display. On reaching the target speed, the measurement stops and the result is displayed in the format xx.x sec. -
Page 19: Highway Acceleration Measurement
5.9 Drag race/quarter-mile race The MC 1812 has a drag race function. The measurement begins from a standing start. During the measurement, ‘calc.’ appears on the display. On reaching a distance of quarter of a mile, the measurement stops and the result is displayed in the format xx.x sec. -
Page 20: Reset Functions
MC 1812 Reset functions General functions Reset functions 6.1 General functions The general functions such as: - Trip distance - Trip time - Avg. speed - Max. speed - Acceleration measurement - Highway acceleration measurement - Braking coefficient measurement - Braking distance... -
Page 21: Important Information, Troubleshooting, And Faq
Important information Important information, troubleshooting, and 7.1 Important information MC 1812 water resistance The MC 1812 is watertight. It can be used in the rain without any risk of damage. The buttons can be pressed. 7.2 Troubleshooting No speed displayed −... - Page 22 The battery life depends on how much the device is used and whether the light manager is used. In general, the MC 1812 is designed so that the CR 2450 battery used lasts at least four years (based on one hour of usage each day).
-
Page 23: Technical Data
MC 1812 Technical data Max, min, and default values Technical data 8.1 Max, min, and default values Unit Min. Max. Speed Current speed km/h; mph Avg. speed km/h; mph 399.8 Max. speed km/h; mph 399.8 Braking coefficient m/s² m/s²; ft/s²... -
Page 24: Changing The Batteries
Changing the batteries 8.2 Changing the batteries The MC 1812 indicates if the battery needs to be changed. The display alternates between the text ‘Computer’ and the battery icon plus ‘low’. After changing the battery, only the time needs to be reset. -
Page 25: Warranty And Guarantee
MC 1812 Warranty and guarantee Temperature, batteries Warranty and guarantee We are liable to our contracting partners for defects in line with legal provisions. The warranty does not extend to batteries. In the event of a warranty claim, please contact the retailer from whom you purchased your motorcycle computer. - Page 26 SIGMA-ELEKTRO GmbH Dr. - Julius - Leber - Straße 15 D-67433 Neustadt /Weinstraße SIGMA SPORT USA 3487 Swenson Ave. St. Charles, IL 60174, U.S.A. SIGMA SPORT ASIA 4F, No.192, Zhonggong 2 Rd., Xitun Dist., Taichung City 407, Taiwan...
