2166306COM
TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B342166306COM
0
Tough
Advertisement
Related Manuals for Ameriwood HOME 2166306COM
Summary of Contents for Ameriwood HOME 2166306COM
- Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 1 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. - Page 4 Before You Start ameriwoodhome.com Tube...
-
Page 5: Board Identification
Board Identification Not actual size Right Panel Left Partition Right Partition Left Panel 32166306020 32166306030 32166306040 32166306010 Bottom TV Rail 32166306070 32166306060 32166306050 Divider Drawer Front 32166306100 32166306110 Upper Shelf Lower Shelf 32166306080 32166306090 Adjustable Shelf (x2) Back (x2) 32166306130 32166306120 ameriwoodhome.com Tube... - Page 6 Board Identification SIDE SIDE Left Drawer Side Right Drawer Side 39992140346010L 39992140346010R Back Panel K216630600 BACK Drawer Bottom Drawer Back 39992340075910D 39992140074800B ameriwoodhome.com Tube...
- Page 7 Board Identification This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. SIDE BACK SIDE ameriwoodhome.com Tube...
-
Page 8: Part List
Part List Actual Size (x6) (x22) (x22) (x17) (x10) #A12120 #A22610 #A22620 #A21660 #A13210 (x14) cam bolt 7/16" screw cam lock wood dowel 1-1/2" screw #A23030 confirmat (x8) (x10) (x26) (x2) #A17400 #A80250 #A11080 #A21110 7/8" bolt shelf support 7/16" screw nail (x4) #A11600... - Page 9 Part List Not Actual Size Left Cabinet Member Right Cabinet Member Left Drawer Member (x5) Right Drawer Member #A44160 foot (x1) #A56740 drawer slide pkg. (x1) #A54900 drawer brace ameriwoodhome.com Tube...
- Page 10 STEP 1 Quick Assembly (x6) (x2) Proper orientation of CAM LOCK ameriwoodhome.com...
-
Page 11: Left Side
STEP 2 Quick Assembly (x3) (x1) Proper orientation of CAM LOCK Left Side ameriwoodhome.com... -
Page 12: Right Side
STEP 3 Marked with a "L" (x1) (x3) (x4) Right Side ameriwoodhome.com... - Page 13 STEP 4 Quick Assembly (x3) (x1) Proper orientation of CAM LOCK Right Side ameriwoodhome.com...
- Page 14 STEP 5 Marked with a "R" (x1) (x3) (x4) Left Side ameriwoodhome.com...
- Page 15 STEP 6 Quick Assembly (x4) (x2) (x4) Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 16 STEP 7 Quick Assembly (x4) (x4) Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 17 STEP 8 Quick Assembly (x2) (x1) Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 18 STEP 9 (x2) finished edges up ameriwoodhome.com...
- Page 19 STEP 10 finished edges up ameriwoodhome.com...
- Page 20 STEP 11 (x10) (x5) finished surface ameriwoodhome.com...
- Page 21 STEP 12 (x8) finished edges up ameriwoodhome.com...
- Page 22 STEP 13 (x2) (x4) finished surface ameriwoodhome.com...
- Page 23 STEP 14 (x4) finished surface ameriwoodhome.com...
- Page 24 STEP 15 (x12) ameriwoodhome.com...
- Page 25 STEP 16 ameriwoodhome.com...
- Page 26 STEP 17 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. With the help of another person, turn the unit onto its front surface. Attached the back panel as shown nailing straight into the raw edges. Assure that the unit is square.
- Page 27 STEP 18 (x2) SIDE SIDE ameriwoodhome.com...
- Page 28 STEP 19 (x4) SIDE SIDE ameriwoodhome.com...
- Page 29 STEP 20 finished surface SIDE SIDE ameriwoodhome.com...
- Page 30 STEP 21 (x4) SIDE BACK SIDE ameriwoodhome.com...
- Page 31 STEP 22 (x4) (x2) (x1) (x2) Attach the slides first and then the knobs. SIDE SIDE ameriwoodhome.com...
- Page 32 STEP 23 (x1) (x2) BACK ameriwoodhome.com...
- Page 33 STEP 24 roller cabinet member drawer runner roller ameriwoodhome.com...
- Page 34 STEP 25 (x8) finished edges ameriwoodhome.com...
-
Page 35: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. No CRT (tube type) TV permitted. This item has been designed for most flat panel TV's having up to 64" (162.6 CM) diagonal screen size. The TV must weigh less than 95 lbs (43.1 kg). - Page 36 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
