Page 3: Introduction
Introduction Overview Usage : Solar outdoor marking stud connected with LEDs with no cabling. The Crystal stud is standalone thanks to a solar panel and a battery. LEDs’ colors: - PLRE2: Amber or White 3000 K or White 4000 K. - PLRE4: Colors RGB + White 4000 K. -
Page 4: Operation
Operation Fixture positioning tips Choose a suitable location where sunlight can directly reach the solar panel. Avoid obscuration by eaves or trees. In the northern hemisphere, favor installation to the south of obstacles, to the east or west. Do not install due north. In the southern hemisphere, favor installation to the north of obstacles, to the east or to the west. -
Page 5: Control With The Nowatt Lighting Application
Control with the Nowatt Lighting application Download the Nowatt Lighting app The Nowatt Lighting application is free to download from the Play Store and the Apple Store. You can download it on a Smartphone or a tablet. Activate your Bluetooth connection Start the Nowatt Lighting application on your Smartphone The app asks you for permission to access Bluetooth. - Page 6 Operation Homepage information Identification number of your product Battery charge status Mode : OFF / Activated / Demo Your stud may display a 0% state of charge on startup. Wait Identification of the model of your a few seconds for the actual product percentage to display.
- Page 7 Operation PLRE4 - Select a color Tap "ON" then "Custom Color" at the bottom of the page to select your color. Use the color wheel or RGBW sliders, then press "Save" to save your color. To delete a color, long press on the color box and then press "yes".
- Page 8 Operation Confirm your product settings The scenario you chose is written here. If you selected a Monochrome scenario, confirm the color. Select the operating time of your device with the sliders: Total duration of use Number of hours after sunset Number of hours before sunrise Check your program with demo mode by tapping “Show Scenario".
-
Page 9: Grouping Function
Operation Grouping function The grouping function allows you to create groups to send the same scenario to several devices simultaneously (within the range of Bluetooth). However, this operation does not allow synchronized operation of the devices. They receive the same scenario, at the same time, but they do not communicate with each other. -
Page 10: Installation
Installation Installation in concrete floor This installation tutorial applies to poured concrete, paving stones and slabs, deactivated concrete, and concrete to be poured. Make a drill core hole of 130 mm in diameter for a minimum depth of 95 mm. Remove the drill core, possibly with the help of a perforator. - Page 11 Installation Set the stud’s height. Pour a resting mortar (if rolling space) or fill with sand according to the following two configurations: Flush stud: H (mortar height) = D (coring drilling depth) - 75mm Stud protruding from the height of the collar: H (mortar height) = D (core drilling depth) - 60mm Adjust flush and horizontality.
-
Page 12: Installation In Coated Soil
Installation Installation in coated soil This installation applies to coated soil, bitumen and asphalt. Make a 122/130 mm diameter coring for a 90 mm depth. 2. Pour a resting mortar over 1 to 1.5 cm. 3. Apply the primer. 4. Apply Sykaflex on the bottom of the stud (only on the metal background). - Page 13 Installation 5. Set the stud with a suction cup. 6. Make a finishing silicone seal.
-
Page 14: Installation In Gravel
Installation Installation in gravel ground Use of stainless steel fixing for stud. This device is screwed onto concrete blocks and maintained by 3 M4 screws. Tube height for a glass protruding installation : 62 mm. Low flange. Tube height for a flush glass installation : 75 mm. High flange. -
Page 15: Installation In Pebbles Or Gabions
Installation Installation in pebbles or gabions Use 140 mm PVC tubes. Cut lenghts equal to the depth of the installation of the pebbles or gabions. 2. Check that your stud is in OFF mode. 3. Install it at the end of the tube. 4. -
Page 16: Maintenance And Care
Waste management Please observe the legal obligations relating to waste management. Return old devices to your dealers or directly to Nowatt Lighting. Do not dispose of old devices with unsorted household waste. Do not throw old devices into fire or water. -
Page 17: Warranty
Maintenance and care Warranty Nowatt Lighting products are manufactured with the utmost care. The function and safety of this product have been tested according to the currently valid directives, with a final inspection. Nowatt Lighting guarantees faultless condition and operation.
