- Page 1 Product Name CLP500 4G Routing Equipment User Manual Number of Pages Produce Version V1.1 Date 2020/7/15 CLP500 4G Routing Equipment User Manual V1.1 Shanghai Yuge Information Technology Co., Ltd.
- Page 2 CLP500 4G Routing Equipment User Manual Revise history Version Date Author Description V1.0 2020/6/11 Document Group Initial Synchronization software V2.3 Synchronous hardware V1.1 V1.1 2020/7/15 Document Group Add remote diagnosis function (only applicable to Qualcomm platform module) - 2 -...
-
Page 3: Table Of Contents
CLP500 4G Routing Equipment User Manual Content Chapter 1. Overview.......................- 4 - Chapter 2. WEBUI management system................- 6 - 2.1 Login........................- 6 - 2.2 Home........................- 7 - 2.3 Internet........................- 9 - 2.3.1 WAN...................... - 9 - 2.3.2 LAN.......................- 9 - 2.3.3 Mobile Net...................- 10 -... -
Page 4: Chapter 1. Overview
CLP500 4G Routing Equipment User Manual Chapter 1. Overview CLP500 is a 4G routing terminal device that can be freely equipped with Qualcomm MDM9x07 and ASR platform 4G wireless communication module. Support three network ports, support dual WIFI antenna, support serial port transparent transmission function. - Page 5 CLP500 4G Routing Equipment User Manual 2) Supports LTE network indicator, flashes when there is no card or registration, and always lights up during normal registration. 3) Support WAN and LAN network port indicator and WiFi indicator. 4) WAN port can be configured as WAN or LAN function on the page.
-
Page 6: Chapter 2. Webui Management System
CLP500 4G Routing Equipment User Manual Chapter 2. WEBUI management system The device's default settings can work, or you can modify the default settings through the WEBUI management page. WEBUI management page supports Internet Explorer 11 and higher, Firefox, Chrome, Safari and other mainstream browsers. -
Page 7: Home
CLP500 4G Routing Equipment User Manual 2.2 Home This page displays the current network mode, connection status, IP address, LAN related information, WIFI related information, device IMEI and SIM card related information and device information (such as system time, boot time, device version number, etc.). Display current network status and related information (such as connected network type, signal strength value, etc.). - Page 8 CLP500 4G Routing Equipment User Manual Note: If there is no problem of registering the network or being unable to access the Internet, you can check whether the connection status has been successfully connected. The device time on this page shows that the network time cannot be synchronized. If you want to synchronize the network time, you can modify the settings by referring to "Time "...
-
Page 9: Internet
CLP500 4G Routing Equipment User Manual 2.3 Internet 2.3.1 WAN Select the network mode is to choose the way to go online. 4G mode: You need to insert a SIM card to go online. DHCP mode: You can not insert a SIM card, but you need to insert the interface labeled WAN into other routers or switches to automatically obtain an IP address for Internet access. -
Page 10: Mobile Net
CLP500 4G Routing Equipment User Manual 2.3.3 Mobile Net This setting modifies 4G related parameters, such as modifying the network mode (LTE only, GSM only, etc.). After setting to automatic mode, the device will automatically search for the best network according to the SIM card, for example, the LTE network is searched first, the WCDMA or EVDO network is searched second, and the GSM or CDMA 1x network is searched last. -
Page 11: Wi-Fi
CLP500 4G Routing Equipment User Manual according to the requirements of the SIM card operator and you still cannot access the network, you can try to modify the authentication type. The three authentication types are different, and you can try them all. -
Page 12: Client
CLP500 4G Routing Equipment User Manual 2.3.5 Client The device functions as a router. Wi-Fi AP and Ethernet are a local area network. This page displays the related settings of the local area network and the LAN client list.. - 12 -... -
Page 13: Firewall
CLP500 4G Routing Equipment User Manual 2.4 Firewall 2.4.1 WIFI MAC filter Accept list: Only MAC addresses added to the whitelist can access the network. Deny list: Only MAC addresses added to the blacklist cannot access the network. Before setting to accept list mode, add yourself to the accept list, otherwise you will be disconnected and can no longer connect to the device. -
Page 14: Dmz
CLP500 4G Routing Equipment User Manual 2.4.3 DMZ DMZ is used to map the host address of the router's internal network to the external network, so that the internal network's host can provide network services. After setting up the DMZ host, the external network's access to the router's IP address will be forwarded to the corresponding DMZ host. -
Page 15: App
CLP500 4G Routing Equipment User Manual 2.5 App 2.5.1 PING Net The PING function is a function to increase the stability of the mobile data connection. Sending PING packets will consume mobile data traffic. The PING function detects that PING data packets are sent at a set time interval. If no data packets are received within the timeout period, the data packets are sent a set number of times in succession. -
Page 16: Serial App
CLP500 4G Routing Equipment User Manual 2.5.2 Serial App Serial port transparent transmission is to transmit the frame-by-frame data received by the serial port to the server, and forward the data on the server to the serial port device. This page can change the serial port transparent transmission setting, and can also modify this setting by receiving commands through the serial port. -
Page 17: Auto Reboot
CLP500 4G Routing Equipment User Manual 2.5.3 Auto Reboot To maintain device stability, you can set the device to automatically restart. The mode every few hours means that the device will restart after a few hours from the start. Daily fixed time mode, which means that the device will restart at a set time every day, this mode requires clock synchronization to be turned on. -
Page 18: Admin
CLP500 4G Routing Equipment User Manual 2.6 Admin 2.6.1 User Management Modify login account and password. - 18 - Shanghai Yuge Information Technology co., LTD... -
Page 19: Time
CLP500 4G Routing Equipment User Manual 2.6.2 Time You can set the time zone and whether to enable the function of synchronizing to the network time. After setting, you need to restart the device. Disabled by default. 2.6.3 Telnet Service After enabling, the device can be connected through Telnet tool. -
Page 20: Remote Diag
CLP500 4G Routing Equipment User Manual 2.6.4 Remote Diag QXDM can grab log after filling in the correct IP address with the NC3 module. - 20 - Shanghai Yuge Information Technology co., LTD... - Page 21 CLP500 4G Routing Equipment User Manual - 21 - Shanghai Yuge Information Technology co., LTD...
-
Page 22: Upgrade Management
CLP500 4G Routing Equipment User Manual 2.6.5 Upgrade Management To upgrade the firmware, please obtain the firmware version through technical support. Failure to test the firmware may cause the upgrade to fail or fail to boot. Please upgrade the bootloader carefully. This operation may damage the device. - Page 23 CLP500 4G Routing Equipment User Manual - 23 - Shanghai Yuge Information Technology co., LTD...
- Page 24 CLP500 4G Routing Equipment User Manual The network will be disconnected during the upgrade process, and the network will automatically recover after the upgrade is successful. Upgrade bootloader: After logging in to the webui interface, select Admin----- Upgrade Firmware------select Bootloader ----- select the file to open, click upload to upgrade, wait for the device to restart.
- Page 25 CLP500 4G Routing Equipment User Manual - 25 - Shanghai Yuge Information Technology co., LTD...
-
Page 26: Reboot
CLP500 4G Routing Equipment User Manual Note: After successful upgrade, you need to press the factory reset button. 2.6.6 Reboot Restart the device. There are some items in the page settings that need to restart the device to take effect. If it cannot be used after setting, it is recommended to restart the device here. - Page 27 CLP500 4G Routing Equipment User Manual - 27 - Shanghai Yuge Information Technology co., LTD...
