Glastar JUMP-START FUSELAGE Instructions

G
LA
I
NTRODUCTION
These instructions apply to the GlaStar Jump-Start Fuselage Option with the bulkheads
installed. Unlike most of Stoddard-Hamilton's option instructions, these are intended
primarily to tell you what
steps that have already been completed at the factory and to highlight what work
remains for the homebuilder.
In addition to these instructions, the Jump-Start Fuselage Option consists of three
elements:
1) The fuselage assembly itself, which consists of the two fiberglass fuselage shells
and Top Deck are seamed together and fastened to the steel-tube cage
structure, with Bulkheads A, B, C, D and E completely fabricated and installed.
2) A COM antenna installation (P/N 211-0112-501). The copper foil dipole
antenna elements are factory-bonded inside the vertical fin, and the triaxial
antenna cable is coiled at the base of the fin for later connection to the radio.
The remaining components of the installation (a BNC connector, heat shrink
tubing and instructions) are sealed in a plastic bag taped to the inside of the
fuselage just forward of the baggage door.
These instructions follow the sequence of steps of "S
GlaStar Assembly Manual
the
Note Wherever the term
taken as referring to the current revision of the
Advance Notices of Revision that may apply to the steps under discussion.
