Page 1: Table Of Contents
Upper Room Air Germicidal Fixture All Models Safety Precautions, Site Planning, Installation, Operation, Maintenance S a f e g u a r d s Page 2 Saf et y W a r n i n g L a bel s Page 3 Saf et y I n s t r u c t i o n s Page 4...
Page 2: S A F E G U A R D S
IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS a) This equipment is designed for use with germicidal UV radiation sources and must be installed incompliance with competent technical directions to prevent risk of personal injury from UV radiation.
Page 3: Saf Et Y W A R N I N G L A Bel S
All personnel should be alerted to the potential hazards indicated by the product safety labeling on this unit. The following conventions are used to indicate and classify precautions in this manual and on product safety labeling. Failure to observe precautions could result in injury to people or damage to property. This is the safety alert symbol.
Page 4: Safety Instructions
Safety Instructions To guard against injury, basic safety precautions should be observed, including the following: 1. Read and follow ALL safety instructions. Avoid exposure to direct or reﬂected germicidal ultraviolet rays. Germicidal ultraviolet rays are harmful to the eyes and skin. 3.
Page 5: First Aid
Disclaimer: Illumisoft Lighting Canada Inc. does not promise or warrant that the use of the Products will protect any user from or prevent infection and/or contamination with any viruses, bacteria, protozoa, fungi, illness or disease. The Products are not approved and/or certified as a medical device by Health Canada or any other regulatory body.
Page 6: W A R R A Nt Y
LIMITED WARRANTY EFFECTIVE Aug. 17, 2021 Subject to the exclusions set forth below, Illumisoft Lighting Canada Inc. (“Illumisoft”) warrants its products to be free from defect in material and workmanship for a period of five (5) years from the date of shipment from Illumisoft’s facilities, except as follows:...
Page 7: Features
Features A d j u s t a bl e A p e r t u re s F o r D i ff e re n t C e i l i n g H e i g h t s R e m ova bl e F a n Tr a y s L i g h t S h a p i n g...
Page 8 SL-36KT-75/40 Specifications Upper Room Air Germicidal UVC Technology • 254 nm germicidal UVC with the industry’s highest UVC output • Industry first adjustable apertures to compensate for different ceiling heights • Powerful integral air handling circulates room air through the UVC energy field •...
Page 9 Wide Beam Set for Higher Ceiling Heights Narrow Beam Set For 8-9 Ft. Ceilings SL-OM-ENG-16-09-2021...
Page 10: Site P L A N N I N G : I N S T A L L A T I O N C O N S I D E R A T I O N S
Sanilume UVC Distribution Ceiling 9 Ft. Minimum Ceiling Height 7’ 9” Minimum Floor View UVC Light UVC Light SL-OM-ENG-16-09-2021...
Page 11 Room Size As a general guideline, one Sanilume with a 75-watt lamp can disinfect approximately 700 sq. ft. (65.03 sq. m.) regardless of ceiling height, as Sanilume fixtures have adjustable apertures to emit more UVC light as ceiling heights increase. (The installation instructions explain setting the adjustable aperture for different ceiling heights).
Page 12: Site P L A N N I N G : Line Of Sight
Light Degradable Materials: UVC light can degrade plastics, fabrics and other light degradable materials. Any such materials that are within approximately 20 ft of the fixture and 7 ft. above the floor may degrade over longer periods of time. Occupant Contact: Care must be taken that the UVC energy fields not be in any line-of-sight conditions of any room occupants.
Page 13: Site P L A N N I N G : E L E C T R I C A L
24/7 and the lamps be changed once per year. Sanilume Model Choice: The Sanilume SL-36KT-75 has a 75-watt UVC lamp, and the Sanilume SL-36KT-40 has a 40-watt UVC lamp. Spaces that have walls within 10 ft. of the fixture (not recommended) should use the SL-36KT-40 to avoid wall reflections that may exceed safety thresholds.
Page 14: Site P L A N N I N G : F I X T U R E M O U N T I N G Height & A P E R T Ur E A D J U S T M E N T
7’ 9” from the finished floor to the bottom of the fixture tip. Table 1 shows the recommended mounting heights and aperture settings for various ceiling heights. These settings were calculated using a Sanilume SL-36KT-75 in a room having a suspended ceiling the readings being under 0.2 ��/��...
Page 15 Fixture Mounting Heights Site Planning: & Aperture Adjustment Wide Aperture Setting Ceiling Un-Safe: Over 0.2 ��/�� 7 ft. Floor Narrow Aperture Setting Ceiling Safe: Under 0.2 ��/�� 7 ft. Floor SL-OM-ENG-16-09-2021...
Page 16 Fixture Mounting Heights & Site Planning: Aperture Adjustment Thoroughly Review the Site Planning Guide Before Beginning. There are several factors that must be considered before installing Sanilume fixtures. General Rule #1. The optimal Sanilume mounting height for spaces with higher ceiling heights will be the height that maximizes the irradiated space above the Sanilume, while not exceeding the irradiance thresholds below 7 ft.
Page 17 Fixture Mounting Heights Site Planning & Aperture Adjustment Ceiling reflections. Reflective ceiling and exposed duct materials such as aluminum will greatly increase the potential for ceiling reflections being at an unsafe level. In such cases, ceiling to fixture distances can be increased and the aperture can be at a lower opening setting. Suspended Light Fixtures.
Page 18 Aperture Adjustment & Mounting Height Ceiling The fixture will come from the factory with the apertures set at a factory recommended setting for Bottom the minimum ceiling height of 9 ft, with the aperture screws installed on the 3rd hole from the bottom of the aperture, and a recommended mounting height of 7’...
Page 19 Below is a copy of our Excel Site Planning spreadsheet. You can download this from our website sanilume.ca under the “Resources” section. Customer Requirements 9 FT. MIN AREA #1: CEILING HEIGHT (FT.) SQ. FT. QTY 40W QTY 75W 36KT-40 40 WATTS UVC LAMP, 64 WATTS POWER - 100-277 VAC under 18' 18' to 23' 36KT-75 75 WATTS UVC LAMP, 113 WATTS POWER - 100-277 VAC...
Page 20: M O U N T I N G H A R D W A R E & A C C E S S O R Y Kit
Installation Accessory Kit: What’s Included 1. UVC Meter 2. 7 ft. Collapsible Rod for UVC Meter Sensor Mounting 3. Digital level 4. Eye & Face Protection 5. Protective Gloves 6. Aperture Pins (to hold an aperture open during installation and maintenance) 7.
Page 21 Fixture Placement Please review the section on site planning for fixture placement, orientation etc. The Sanilume fixture is recommended for use in rooms with a ceiling height of 9 feet or more and where occupants remain for prolonged periods. The minimum ceiling height under any circumstances is 9 ft, and a mounting height of 7’...
Page 22 Handheld radiometers are used to measure irradiance for a safe occupant levels of UVC. After fixture installation, it is mandatory to check UVC levels to ensure no UVC level is above the accepted threshold of safety anywhere in the room below 7 ft. in height above the floor. exceeding the Threshold Limit Value (TLV) of effective irradiance of 0.2 ��/��...
Page 23 Make measurements with the sensor face at a 90-degree angle to the ceiling and floor and positioned in the center of the fixture (maximum UVC output). To test for proper UVC output, at a distance of 1 M from Sanilume SL-36KT-75, the reading should be about 240 ��/�� and 140 ��/��...
Page 24 Personal protection equipment, such as gloves; long sleeves with no gaps between cuffs and gloves, and ultraviolet resistant face shield, are required when entering the irradiated space, above 6 ½ feet from the floor, with the germicidal lamp operating. Always disconnect power to the fixture before performing any service or maintenance. Ultraviolet rays are harmful to the eyes and skin.
Page 25 Lamp Removal 1. Pry the lamp upwards using a screwdriver beneath the plastic lamps ends to remove the lamp from the lamp holder clips. This must be done very gently! To remove the lamp from the connector, use the screwdriver to pry the lamp connector away from the lamp. Lamp Installation 1.
Page 26 Cleaning Shut down power to the fixture. 2. Raise up one of the fan trays up and insert the pins to keep the aperture in the up position. If cleaning is indicated, the bottom egg crate lovers can be dusted from both sides, and the top louvers can be dusted from the bottom only.
Page 27: Uvc Measurement Quick Start Guide
UVC Measurement Quick Start 1. Push the white button on the sensor and the receiver to turn them on. 2. Wait for the two units to automatically Bluetooth pair. ready to go. Make sure the display looks the same and the units are ��/�� 3.
Page 28: About
(DLC Qualified Products Listings). They are now applying their technical expertise to help the world become a safer place to live, work and play. Contact: info@illumisoftlighting.com Illumisoft Lighting Canada Inc., 160 Spruce St, Ottawa ON K1R 1C6 Canada Sanilume.ca SL-OM-ENG-16-09-2021...

This manual is also suitable for:

Sanilume sl-36kt-40
