BOTTOMMOUNT
It is vitally important for all Able Equips ladder racks and accessories be securely and properly attached to your
vehicle according to installation instructions. Failure to do so could result in automobile accident, and could cause
serious bodily injury or death to you or to others. Responsibility of correct attachment lies with the purchaser of
this product. Additionally, the driver of the vehicle is responsible for checking the attachments prior to use, and
periodically inspecting them for wear, tear, or damage and to see if adjustment is needed. Please read and under-
stand all of the cautions and instructions supplied with this Able Equips product. If you do not fully understand all
of the instructions and cautions, or if you are not familiar with installation procedures, please feel free to contact
us for questions.
Ladder Restraint System
Fits One
Extension Ladder
Model LRS-BM
TOOLS NEEDED
(1) Drill with 1/4" Bit
(2) 7/16" Wrench or 7/16" Socket
WARNINGS
Advertisement
Summary of Contents for Able Equips Bottom Mount LRS-BM
- Page 1 Please read and under- stand all of the cautions and instructions supplied with this Able Equips product. If you do not fully understand all of the instructions and cautions, or if you are not familiar with installation procedures, please feel free to contact...
- Page 2 PLACEMENT OF LADDER RESTRAINT SYSTEM Mount Ladder Clamp and Restraint Strap as Far Apart as Possible PROPER MOUNTING TO MOUNTING HEIGHT A CROSSMEMBER Below are examples of using spacers to adjust height. 4 3/4” - 5 1/2” Handle should never rest past horizontal position CAUTION Spacers Installed Only as Needed...
- Page 3 STRAP MOUNTING Horizontal Tube or Angle Vertical Tube PROPER USE OF LADDER CLAMP FITS EXTENSION LADDER RUNGS Hook should freely swing up and wrap around extension ladder rung. PROPER USE LOCKING OF STRAP LADDER CLAMP Use Finger Loop and Pull Tight! EXTEND ALL THE WAY THROUGH Long Shank Padlock Required...
- Page 4 BEFORE DRIVING Check Tighten Clamp Strap Make sure cable lock Make sure clamp is is padlocked before secured around ladder operating vehicle. properly before operating vehicle. MAINTENANCE Check Strap Hook Weekly Check operation Check strap weekly, weekly, if necessary, if necessary, replace add a drop of with new strap.
