SKETCHNBUILD SNB-PX24 Manual

25” planer
Hide thumbs

Advertisement

Quick Links

Download this manual
SNB-PX24 25" PLANER
MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the SNB-PX24 and is the answer not in the manual?

Questions and answers

mario vera
January 26, 2025

where made?

0
mario vera
January 26, 2025

wher is sketchnbuild made

0

Summary of Contents for SKETCHNBUILD SNB-PX24

  • Page 1 SNB-PX24 25” PLANER MANUAL...

  • Page 2: Table Of Contents

    SNB-PX24 PLANER MANUAL CONTENTS 1. TECHNOLOGY PARAMETER AND SPECIFICATION INDEX...………………….….3 2. OPERATION AND SAFETY…………………….……………………..……………………….…4 3. ELECTRICAL CONFIGURATION……………………………………….……………………….5 4. OILING SYSTEM.…………………………………………………………………….………….…...5 5. OPERATION…………………………………………………………….…………………….………..7 6. ADJUSTMENT ……………………………………………….……………………………..………...7 7. TESTING …………………………………………………………………………………………………10 8. ACCESSORY & PARTS LIST………………………………………………………………….……10 CAUTION: Read these instructions carefully before turning on the machine.

  • Page 3: Technology Parameter And Specification Index

    SNB-PX24 PLANER MANUAL 1. PARAMETER AND SPECIFICATION INDEX SNB-PX24 Parameter Specification Max working width 24”/600mm Max working 8”/200mm thickness Min working length 8”/200mm Max cutting depth 0.2”/5mm Cutter head speed 5000r/min Feeding speed 6.5-9m/min Spindle motor 5HP/7.5kw Equipment weight 1168lbs/530kg NOTE: The above design and specifications might differ on each machine model.

  • Page 4: Operation And Safety

    SNB-PX24 PLANER MANUAL 2. OPERATION AND SAFETY 1. Keep doors closed and all the tools and adjustment wrenches away from the work table before operation. 2. Be sure all parts are securely tightened and oil relevant parts before operation. 3. TURN DOWN the triangle belt of motor by hand to ensure the shaft of blade, gear work well and without collision.

  • Page 5: Electrical Configuration

    SNB-PX24 PLANER MANUAL 3. ELECTRICAL CONFIGURATION The motor is controlled by a magneto-electricity starter. This provides the advantages of a simplified connection, easy operation and over load prevention. In the graphic below, electric principle A, connecter will be looped when the start button is pulled, and then the loop will be locked as the power gets through the connecter to make the motor run.
  • Page 6 SNB-PX24 PLANER MANUAL Oiling Instructions Drops of Oiling Area Oiling Part Type of Oil Oiling Time instruction Take the front cover apart and Every 6 Motor Bearing CAS#3 remove the months cover of motor Lever on work Take apart and...

  • Page 7: Operation

    SNB-PX24 PLANER MANUAL Drive system of Take the end Every 6 delivery and bearing Cas#3 cover apart months press roller Take the end Every 6 Gear box gear Cas#3 cover apart months Take the end Every 6 Gera box Bearing...
  • Page 8 SNB-PX24 PLANER MANUAL 1) Lift the breaker, and use the wrenches to loosen the bolt on the pressing strip, take out the blade for sharpening or changing 2) Setting and adjustment of planer blade: a) Make sure both ends of blade machine are even and fixed, and then adjust four adjustable bolts to keep them in the same position (1mm more or less).(Graph B)
  • Page 9 SNB-PX24 PLANER MANUAL 4) Up and down adjustment for delivery roller and press roller. The positions of the bearing of the delivery roller and press roller have been factory adjusted. If bearings to the right or left become uneven, the user can loosen the four fastening nuts under the bearing so that outer diameter of the delivery roller and press roller are positioned over the blade shaft by about 1mm.

  • Page 10: Testing

    SNB-PX24 PLANER MANUAL Loosen the fastening bolts, and revolve the transfer bolt to align to the bottom of the breaker and back press machine just above the cutting circle of blade shaft (about 0.5mm, then tighten the fastening bolts after adjustment.
  • Page 11 SNB-PX24 PLANER MANUAL Parts List Precision Part Code # Dimension Name Quantity Remark grade Single redial Blade shaft 30x70x19 ball bearing Delivery ＆Press Single radial 20x47x14 Roller ball bearing Single radial ball bearing Holding roller on 61004 20x40x12 with work table...
  • Page 12 SNB-PX24 PLANER MANUAL cover Single radial ball bearing Tension wheel 80201 12x32x10 with dustproof cover Motor box 1803 Triangle belt Gear box 1397 Triangle belt 990(preparati Gear box 1041 Triangle belt 6/2016...
