Principal Display Panel

Aero HygenX

RAY

AUTONOMOUS UVC ROBOT

REGISTRATION NO. 34541 PCPA

KEEP OUT OF REACH OF CHILDREN

This device is intended for commercial or industrial use only

READ LABEL AND THIS OPERATING MANUAL BEFORE USING.

WARNING - UV radiation emitted at 254 nm from this device

Reduces micro-organisms on surfaces

Aero HygenX Inc.

217-150 Katimavik Road

Ottawa, Ontario

K2L 2N2

CANADA

1-800-260-0787

NOTICE TO USER: This pest control product is to be used only in accordance with the directions on

the label. It is an offence under the Pest Control Products Act to use this product in a way that is

inconsistent with the directions on the label.

Table of Contents

Need help?

Do you have a question about the RAY and is the answer not in the manual?

Questions and answers

Summary of Contents for Aero HygenX RAY

Page 1 This device is intended for commercial or industrial use only READ LABEL AND THIS OPERATING MANUAL BEFORE USING. WARNING - UV radiation emitted at 254 nm from this device Reduces micro-organisms on surfaces Aero HygenX Inc. 217-150 Katimavik Road Ottawa, Ontario K2L 2N2...
Page 2: Table Of Contents
Manual RAY Operating Manual READ AND SAVE THESE INSTRUCTIONS! THIS DEVICE IS INTENDED FOR COMMERCIAL OR INDUSTRIAL USE ON AIRCRAFT ONLY. BEFORE USING THIS DEVICE READ ALL INSTRUCTIONS, WARNINGS AND CAUTIONS IN THIS MANUAL AND ON THE PRODUCT LABEL. TABLE OF CONTENTS 1.
Page 3: Precautions
Use Aero HygenX RAY – Autonomous UVC Robot only as described in this Operating Manual. Do not carry out any maintenance other than that shown in this manual, or...
Page 4  Human Face detection up to 3 metres (9.84 feet): If a human face is detected within 3.0 metres of the device, Aero HygenX RAY – Autonomous UVC Robot will stop and the UVC lamps will extinguish. Operator input is required before Aero HygenX RAY – Autonomous UVC Robot will re-start.
Page 5 Pushbuttons are UP, followed by the Master Power Switch being turned ON)  Master Power Switch: The large red rotary knob on the back end of Aero HygenX RAY – Autonomous UVC Robot is the Master Power Switch. Turning the Master Power Switch OFF disconnects the Main Battery from all electronics and lamps and allows for safe transport or maintenance of the unit.
Page 6: Features And Controls
2. FEATURES AND CONTROLS REAR VIEW Autonomous Robotics Emergency Push Button UVC and Drive Unit Power Down REAR Camera Situational Awareness Human Detection REAR Touchpad Countdown and Auto-pause REAR Lidar Autonomous Guidance Master Power Switch Full Power Disconnect REAR Sonar Object Detection Battery Charging Receptacle...
Page 7 FRONT VIEW FRONT Camera Situational Awareness Human Detection FRONT Touchpad Simple Built-in Touch Screen FRONT Lidar Autonomous Guidance FRONT Sonar Object Detection...
Page 8: Operation
3. OPERATION TREATMENT OF THE AIRCRAFT Supported efficacy claims for hard and soft surfaces within an aircraft cabin* Treatment Cycle Supported Claims Single pass at 0.125 m/s Kills 99.999% of SARS-CoV-2 Two passes at 0.125 m/s Kills 99.999% of SARS-CoV-2 Reduces viruses by 99% Two passes at 0.125 m/s with a 40 s stationary phase Kills 99.999% of SARS-CoV-2...
Page 9 AREA OF COVERAGE Aero HygenX RAY – Autonomous UVC Robot incorporates a unique design which has been engineered for both single and dual-aisle aircraft. The lamp array allows for maximum UVC light exposure on to the high-touch surfaces of an aircraft.
Page 10 (Power-up is verified by amber flashing lights on the top of the unit). The device will now go through a short System Health Check. When the System Health Check is complete, the “RAY” logo turns green and the device is ready for use.
Page 11 When the lamp warm-up is complete (default warm-up time is 2 minutes), the treatment will commence. The lamps will be fully illuminated and Aero HygenX RAY – Autonomous UVC Robot will start moving down the aisle. (If Aero HygenX RAY – Autonomous...
Page 12 The starting position is at the front of the aircraft, adjacent to the lavatory, with the lavatory door open. The front of Aero HygenX RAY – Autonomous UVC Robot should be facing the first intended direction of travel.
Page 13: Transporting The Device
4. TRANSPORTING THE DEVICE a. When transporting Aero HygenX RAY – Autonomous UVC Robot to the aircraft, the device should remain upright. The Master Power Switch must be selected off to prevent damage to the drive unit. b. If Aero HygenX RAY – Autonomous UVC Robot...
Page 14: Maintenance & Cleaning
6. MAINTENANCE & CLEANING BATTERY EXCHANGE a. Power off Aero HygenX RAY – Autonomous UVC Robot by ensuring the Master Power Switch is OFF. b. Open side panel of Aero HygenX RAY – Autonomous UVC Robot (With panel open, top of battery will be visible).
Page 15 Connect the new battery by pushing the red connectors together (reverse of removal). i. Ensure correct polarity (per image). j. Close side panel. k. Ensure Aero HygenX RAY – Autonomous UVC Robot can be powered on. l. Ensure battery disposal is in compliance with local laws.
Page 16 LAMP EXCHANGE a. Ensure safety gloves are worn to avoid skin contact with glass and to avoid the possibility of injury if the lamp were to shatter. b. Open the side panel. c. Pull up gently on the bulb requiring replacement, holding on to the lamp as close to the base as possible.
Page 17 UVC holder. CLEANING a. Clean Aero HygenX RAY – Autonomous UVC Robot with a soft, dry cloth. b. For more stubborn stains, use a soft cloth slightly dampened with a solution of mild soap and warm water. Do not use alcohol or acetone-based cleaners.
Page 18: Troubleshooting
 Check main battery Master Power switch to connection connection “ON”  Swap battery Aero HygenX RAY – Obstruction on the floor or  Wait 20 seconds for Autonomous UVC Robot in the aisle Auto-Shutoff to becomes hung up during extinguish lamps travel down the aisle.
Page 19 Reset unit by turning message remains shown unresolved. Master Power Switch Off on Touchpad screen. for 10 seconds then ON. Aero HygenX RAY – Internal systems not ready. 1) Wait 30 seconds and re- Autonomous UVC Robot attempt directional countdown does not command.
Page 20: Warranty
8. WARRANTY The sole and exclusive obligation of Aero HygenX (AHX) to the Customer for any Product (including, without limitation, integral parts thereof not manufactured by AHX but excluding bulbs, fuses, or parts made from glass construction) and services made by AHX and sold hereunder are to be repaired, returned, or provided with a replacement Product, at the sole option of AHX.
Page 21 RETURN MATERIAL AUTHORIZATION (RMA) AHX will only accept Products returned under the AHX Return Material Authorization (“RMA”) process. The customer shall obtain an RMA number from AHX prior to returning any Product. Upon the issuance of an RMA, the customer shall diligently return the Product with prepaid shipping arrangements and sufficient insurance against the loss or further damage to the Product, to AHX’s facility.
Page 22: Specifications
9. SPECIFICATIONS Product Dimensions Length 66 cm Width 30 cm Height 132 cm Weight 44 kg Compatibility Aircraft Robotics Max Speed 0.15 m/s Direction Multi- (Forward/Reverse) Turning Radius 0.7m (Clockwise/Counter-Clockwise) Maneuverability 360 degree WiFi Bluetooth Cameras (2) 1080p, 30fps Sonar Lidar Autonomous Control Manual Control...
Page 23 Sticker AEROHYGENX “RAY” - AUTONOMOUS UVC ROBOT www.aerohygenx.com COMMERCIAL Inactivates up to 99.99% of micro-organisms on interior surfaces of aircraft. Read all instructions, warnings and cautions in the Operating Manual before using this device. The Operating Manual can be accessed via this QR code: CAUTION: This device emits UVC radiation.
