Robertson Harness CRC 600 Series Manual

Robertson Harness
Fort Collins, Colorado
Sales@RobertsonHarness.com
www.RobertsonHarness.com
(970) 682-4470
These instructions are provided to the user by the manufacturer and should be saved
for Future Reference.
Usage & Applications
▪
This harness is a basic ANSI rated harness designed specifically for use in the zip-line /
adventure park industry to meet industry standards for workers and customers at
height if Fall Protection is required. The Dorsal D ring is easily adjustable on rear of
the chest. (Rated for Fall Arrest ) Should be used for all Class III full body fall arrest
applications. Attach only ANSI compliant lanyards and shock absorbing/decelerating
devices to dorsal D ring Attachment points on the back dorsal. Maximum free fall
distance is dictated by type of fall protection lanyard or system utilized. Following
current ANSI specifications, Dorsal attachment allows for 6 or 12 ft. free fall if utilizing
energy absorbing lanyards designed for 6 or 12 ft. free fall. Ensure complete
inspection and qualified person verification of fall protection system to meet needed
protection. The "Front" Connection or Belay is for "Suspenstion & Descent Control"
and "ladder access." The "Rear" structural loop and "Front" Belay loop are rated for
"Work Positioning" fall restraint. Harnesses belays are color coded to easily
distinguish sizing. This harness was designed for workers and customers at height in
need of a Dorsal "Fall Arrest" rated connection for leap applications or if able to fall
more than 2'. This harness is intended to support a customer while attached to the
belay loop on the front of the harness for fall restraint. The Dorsal if able to fall
more than 2' - fall arrest. This harness was not intended for use in any SUPERMAN
syle attachments or inverted attachments of ride customers.

Requirements

▪
These items are designed to connect the user to a suitable fall protection
anchor to avoid or limit a fall, and may also allow for safe attachment
to appropriate pulley used in zip line and canopy tours.
▪
Anchorages selected for personal fall arrest systems must be capable
of sustaining a 5,000 lb. (22.2 kN) static load or twice the maximum arrest
force permitted on the system.
▪
These items are designed for a single user unless otherwise specified.
▪
Lanyard connections to the harness must be approved connectors to the
appropriate fall arrest attachments on the harness.
▪
Robertson Harness recommends a "before use" visual inspection, along
with an annual examination of general condition and function
to be carried out and recorded by a Third Pary "Qualified Person."

Qualifications

▪
The Dorsal connection passed ANSI/ASSE Z359.11-2014 Safety Requirements
for Full Body Hanresses for Fall Arrest applicatons
▪
This product has been pull tested to >5000 lb. (22.24 kN)
▪
Complies to PRCA/ANSI 1.0-1.3 5000 lb. (MBS) minimum breaking strength
▪
Complies to ANSI Z359.1 required 5000lb. Breaking strength.
▪
Meets and Exceeds ASTM F-1772 Standard Specification for harnesses
used in Rescue, Safety, and Sport Activities.
▪
Qualifies ASTM F-1772 12.1.3 Full Body Harness
▪
Meets and exceeds CE qualifications and standards.
Robertson Harness
Tested to : ANSI / ASSP Z359.11-2014
Safety Requirements for
Full Body Hanresses
CRC 600 Series w/ Adjustable Dorsal
SM. # CRC601 Red - Up to 30" waist / 5'3" Max Height
M/L. # CRC600 Blue - Up to 47" waist / 6'3" Max Height
L/XL # CRC602 Grey - Up to 58" waist / 6'11" Max Height
Maximum capacity of harness is 310 lbs. per
ANSI/ASSE Z359.11-2014
Users and Operators need to maintain a log of identifying
the history record of the equipment.
Sample Maintenance and Inspection Log
Product Record Card
Product Type:
ID /Serial #:
Purchase Date:
Date Inspected Pass/Fail

Inspection

▪
Inspect harness to ensure that it is in a serviceable condition.
▪
Check webbing for visible signs of wear and tear such as: wear, cuts
burns, frayed edges, or other damage.
▪
Inspect to ensure that all buckles work properly and that they do not
have any sharp edges, burrs, cracks, or corrosion.
▪
Inspect all stitching for abrasion, discoloration and wear to ensure
integrity.
▪
Thoroughly inspect harness after any period of extended storage.
▪
Discontinue use of product if it has come in contact with any corrosive or caustic
chemical agents such as acids, bleach, or petroleum products.
▪
Remove from service and destroy if the equipment has been exposed
to flame or high temperatures.

Maintenance

▪
Protect and store the equipment from direct sunlight or extreme heat
sources. Webbing should never be exposed to temperatures above
120° F (62° Celsius) or below -80° F. (Above 48° Celsius).
▪
Protect the equipment from nylon damaging chemicals such as acids,
alkalis, oxidizing agents, petroleum products and bleach.
▪
Hand wash the harness in cool water with small amounts of mild soap.
Rinse thoroughly to remove all soap residue. Failure to remove all the
soap will leave webbing stiff and will need to rinsed again.
▪
Do not wash webbing in Woolite.
▪
Repairs or modifications made by anyone other than Robertson
Harness Inc. will void all warranties and liability.

Service Life

▪
Please see the our Service Life documentation for more detail.
Service Life is "One minute to Ten Year Service Life or condition, with a Fifteen
Year Shelf Life." Terms and Conditions do apply on Shelf Life. Contact the
manufacturer for details.
Proudly Made In The USA
Date of 1st Use:
Comments Signature
