Summary of Contents for MMB OpenThread BRD21
- Page 1 BRD21 Quick Start Guide OpenThread Border Router/OpenThread Mesh Extender DRAFT Jul 19, 2022 MMB Networks 25 Adelaide St. E, Suite 400 Toronto, Ontario, Canada M5C 3A1 (416) 636-3145...
- Page 2 1206 (“The Radio Equipment Regulations 2017”). The products are entitled to carry the UKCA Mark and a formal Declaration of Conformity (DoC) is available at the product web page which is reachable starting from https://www.mmbnetworks.com/BRD21. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 3 Getting Started Guide | MMBNetworks.com/BRD21 Box Contents 1. BRD21 Device 2. USB-C Power Adapter Getting Started BR21 Device Overview Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 4 Thread ON/OFF Button Factory Reset Start Thread Join (Press > 20 seconds) (Toggle: Press < 2 seconds) WIFI ON/OFF (Press 5-20 seconds) Full LED and Button pattern specifications can be found at MMBNetworks.com/BRD21 Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 5 BRD21 3. On the rear of the BRD21, connect the Ethernet Cable from your LAN Router and then connect the USB-C- Power Adapter. Wait for the Status LED to turn Solid Green.. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 6 2. Using the reader, scan the QR Code on the front of BRD21. 3. Upload the TME’s device’s Thread joiner credentials to the BRD21 Thread Border Router’s WebUI. If not using a BRD21 Thread Border Router enter the BRD21 TME’s Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 7 7. Verify TME device has been commissioned onto the network via the Edge device. 8. Go to https://mmbnetworks.com/ to learn more about the BRD21 and how to connect to the Siemens Edge Device. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
-
Page 8: Mounting Instructions
The BRD21 can be mounted on walls or ceilings. The ideal orientation is vertically on a flat wall, with Power and Ethernet cables facing down. A clearance of 2cm on all sides should be maintained. Rev 0.1 MMB Networks 2022 • BRD21 QSG... - Page 9 Please ensure the mounting bracket is installed with enough clearance for the BRD21 to slide onto the mounting bracket. Final placement of the BRD21 in respect to the Mounting bracket can be seen below. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 10 Caution: Do not overtighten screws. Screws must be flush with the mounting bracket. # 4 Flat Head screws only. The mounting bracket should be level and installed flush to the wall or ceiling surface material. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
- Page 11 Getting Started Guide | MMBNetworks.com/BRD21 Attaching BRD21 Once the mounting bracket is correctly installed, and with Ethernet and Power cables connected to the BRD21, slide the BRD21 onto the bracket from left to right to mount.. Rev 0.1 MMB Networks 2022 • BRD21 QSG...
