- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 301061KW (B1&B2) California King Bed REVISION 0 : 03/10/2017 PAGE 1 OF 6 COASTERFURNITURE.COM PAGE 1 OF 2 REVISION 1 : 11/15/2019...
- Page 2 301061KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
- Page 3 1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately. 2. This product is for home use only and not intended for commercial establishments. HARDWARE IDENTIFICATION Z-B2 (BOX 2) - HARDWARE PACK IS LOCATED IN 301061KW (B2) SHORT BOLT 20PCS (M8 x 30MM - RBW)
- Page 4 301061KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 COASTERFURNITURE.COM PAGE 4 OF 6...
- Page 5 301061KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 COASTERFURNITURE.COM PAGE 5 OF 6...
- Page 6 301061KW (B1&B2) ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 COMPLETE COASTERFURNITURE.COM PAGE 6 OF 6...
- Page 7 301061KW (B1&B2) ITEM: 80.31" INNER SIZE : 72.68" X 85.43" 42.52" 3.54" 13.19" 7.87" 84.65" 71.26" 92.91" 76.38" 5.91" Note : Dimension tolerance ±5% COASTERFURNITURE.COM...
