CONSTRUCTION
S - 06
MANUAL

安装时间/Time to build: 2.5 hours
最大载重/Max weight:30Kg

Advertisement

loading
Need help?

Need help?

Do you have a question about the S-06 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DOCYKE S-06

  • Page 1 CONSTRUCTION S - 06 MANUAL   安装时间/Time to build: 2.5 hours  最大载重/Max weight:30Kg ...
  • Page 2 We recommends that you periodically review and reinforce the information in this manual with younger riders,and that you inspect and maintain your docyke rides to insure their safety.
  • Page 3 Keep your ride in a dry environment. 7) 多可 除螺钉外其余都为特别设计的零件,请不要和市场上类似零件混用。 Most of the docyke’s components are specially designed, please do not mix with similar parts on the market. 8) 检查充气轮胎气压不能大于1.8bar(1.8 kgf/cm² Check the air pressure in the tires to max 1.8bar 9)...
  • Page 4 2) 只能用 多可 制造商规定的充电器及电池进行充电. Recharge only with the charger and battery pack which specifically designated by DOCYKE. 3) 当电池不用时,将它远离其它金属物体,以防电池短路引起火灾或燃烧。 When battery pack is not use, keep it away from other metal objects that can shorting the battery terminal together may cause burns or fire.
  • Page 5 装配时螺钉需要拧紧。    Tighten the bolts with full force to prevent them coming loose.  M8x20  装配零件前先检查螺母 是否放置正确。  240mm  Cheeck  the  profile  nut  remains perfectly straight  in the slot.  M8x20 ...
  • Page 6 M8X20  M8X20  M8X20  80mm  M8  使用内六角扳手辅助装配  Take  Allen  M8X25  key, slide the  nut on it.   Stick the Allen  key  through  the part. ...
  • Page 7 螺丝在不同位置需要使用不同长度,请务必按照指导手册使用。    Be sure to use the correct screws according to the instruction.  重复步骤。Repeat steps.  200mm  M8X20=2  C  M8X50/60  ø8Xø16xh1.6 ø8Xø30xh2 ...
  • Page 8 200mm M8X20 M8X20...
  • Page 9 重复上述步骤。  Repeat the steps as figure.  120mm  D  ø8Xø30xh2  M8X20=2  ø8Xø16xh1.6 M8X50 ...
  • Page 10 请经常检查螺丝是否有松动,并拧紧。    Always check the screws and tighten.  M8X20=2 ø8Xø16xh1.6=2  M8X60 ...
  • Page 11 M8X20  60mm  M8X20  M8X20=2 ...
  • Page 12 M8X20=2  40mm  M8  M8X33  角度片的齿型分 2 种, 一种可安装成 5°,15°,25°,,,, ,等 一种可安装成 10°,20°, 30°, ,等 There are two types of knurled discs. One can be installed in 5°, 15°, 25°,,,,etc. The other can be installed in 10°, 20°,30°, etc.
  • Page 13 M8X25=2  M8=2  M8  M8X33 ...
  • Page 14 如果您有任何问题,或者更好,更酷的创意,欢迎联系我们。 If you have any questions, or better ideas, welcome to contact us.
