Mainstays MS16-D4-1007-01 Assembly Instructions Manual page 9

STEP 3
x 4 x 4 x 4 x 4
1 . L a r g e 3 . C a m B o l t 4 . C a m 8 . B l a c k C a m
W o o d e n C o v e r
D o w e l
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Carefully tap small wooden dowels into place. Leave 1/2" of the dowels sticking out.
2. Screw-In cam bolts must be screwed down flush.
3. Refer to page 6 for instructions on how to use the cam lock system.
9
