- Page 2 THIS PAGE INTENTIONALLY LEFT BLANK...
-
Page 3: Table Of Contents
Disclaimer While all care has been taken in the development of this product, no loss of any kind is accepted by HES Winches Australia or its agents arising from the use of this document. HES Winches Australia makes no representations or warranties with respect to the contents of this document, and specifically disclaims any express or implied warranties or fitness for any particular purpose. -
Page 4: Preface
This 316 stainless steel marine winch has been manufactured and distributed by HES Winches Australia Pty Ltd. This equipment is also the result of extensive design and development and is acknowledged as being a superior product in its category. -
Page 5: Winch Overview
Owner's Manual OZWINCH - Marine Winch WARNING DO NOT use this winch for lifting applications. • DO NOT use this winch to transport people or animals • DO NOT exceed the hauling limitation of the winch. • DO NOT lengthen the handle for additional leverage. •... -
Page 6: General Assembly
Owner's Manual OZWINCH - Marine Winch General Assembly Figure 1. General assembly parts identification diagram. Table 2. General Assembly Parts Listing Description Replacement Part Number Grub Screw to suit OzWinch 316 POMW-SS316-GS Stainless Steel Marine Winch Winch Handle to suit OzWinch 316 POMW-SS316-WH Stainless Steel Marine Winch Webbing Strap 7.5mt to suit OzWinch... -
Page 7: Installing The Ozwinch 316 Stainless Steel Marine Winch
Owner's Manual OZWINCH - Marine Winch Installing the OzWinch 316 Stainless Steel Marine Winch This winch is designed to be attached to a mounting plate or structure capable of supporting the load that is intended to pull its rated capacity. Mounting location and hardware must support your winch and load. - Page 8 Owner's Manual OZWINCH - Marine Winch For maximum strength and safety, this winch should be mounted with a minimum of three (3) Grade 8 M10 bolts, washers, and nylon lock nuts (not included, sold separately). The bolt should attach the winch to the mounting structure utilising the outside rear holes or slots matched according to either existing mounting holes or new mounting holes to be drilled.
-
Page 9: Webbing Strap Replacement
Owner's Manual OZWINCH - Marine Winch Webbing Strap Replacement This OzWinch 316 Stainless Steel Marine Winch is already supplied with a 7.5m webbing strap and stainless steel safety hook (OzWinch part POMW-SS316-WS). The parts should be replaced if damaged or worn. To replace the Webbing Strap 1) Put ratchet pawl in reel out position. -
Page 10: Maintenance
Greasing of gears and drum shaft with a white lithium grease product 2) Add a drop of oil on drive shaft sleeves. HES Winches Australia also recommend the use of a lanolin-based protective spray for prolonged longevity of your OzWinch product. - Page 11 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 12 Owner's Manual OZWINCH - Marine Winch...
