Summary of Contents for Simplified Manufacturing AUDEX1
Page 1
HDCP 2.2 Thank you for purchasing this device The Simplified MFG AUDEX1 is designed to provide years of reliable service. At Simplified MFG, we want the experience with this device to be the best possible and are committed to helping achieve that experience.
Page 2
6. Warranty and Contact Info ........6&7 1. Introduction The AUDEX1 HDMI 18Gbps Audio Extractor extracts audio signals from any HDMI compliant source to digital optical or analog stereo L/R audio outputs. Both input and output HDMI connections support video resolution up to 4K2K@50/60Hz (YUV444)
Page 3
3. Package Contents • 1 x AUDEX1 HDMI 18Gbps Audio Extractor • 1 x 5V/1A Power Adaptor • 1 x User Manual 4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 and HDCP 1.4 Video Bandwidth 18 Gbps...
Page 4
5. Operation Controls and Functions 5.1 Front Panel DC 5V: Connect 5V/1A adaptor to AC wall outlet for power supply. Power LED: System power indicator. TV / Bit Stream / 2CH: This allows users to select audio format according to TV, Bit Stream or LPCM 2CH. HDMI In: Connect this to HDMI source devices such as Blu-ray or PS4 player Link LED: The LED will illuminate when detected HDMI input signal...
Page 6
Warranty Should you feel your product does not function adequately due to defects in materials or workmanship, we (referred to as “the warrantor”) will, for the length of the period indicated below (starting from the original date of purchase) either: a) Repair the product with new or refurbished parts.
Page 7
Simplified MFG Publication Disclaimer The material contained in this document consists of information that is the sole property of Simplified MFG. This document is intended to provide information to allow interfacing to the relevant Simplified MFG equipment by third party products. Simplified MFG IS NOT RESPONSIBLE FOR MALFUNCTIONS AND/OR THE IN-OPERABILITY WHICH MAY BE CAUSED BY THE APPLICATION OF THIS INFORMATION, WHETHER EXPECTED OR NOT.
Page 8
How to extract audio from HDMI 1. Audio Extraction with no conversion. AUDEX1 extracts the audio in the format sent up to 5.1 HDMI Cable or Extender AUDEX1 HDMI Stereo or up to 5.1 Audio Optical or Stereo Sound Bar Sound Bar 2.
