DAS-2420
2.4 GHz Wireless Digital Audio Sender
with Portable Receiver
In the scenario, when you want to watch your favorite action movie at night, and all your
family members were sleep, you do not want to wake them up at this time, The DAS-2420
is the best solution. DAS-2420 deploy the 2.4GHz ISM band with frequency hopping and
WiFi auto-detection scheme to provide crystal clear audio.
Feature
2.4GHz ISM band
ID Pairing
34 channels Frequency hopping
1 1, 1 N Application
Portable receiver with batteries powering and DC adaptor powering
Frequency hopping to avoid co-channel interference
Volume controllable via rotatable switch
44.1KHz sampling frequency
Package of content
Before your installation, please check the content of package
DAS-2420 Tx X1
DAS-2420 Rx X1
AC/DC Adaptor X2
3.5 mm to RCA R/L audio cable X1
Stereo 3.5mm Cabel
Earphone X1
Transmitter
Receiver
Stereo 3.5 Cable Audio cable
Introduction
Adaptor
strap
1
earphone
Advertisement
Summary of Contents for Trans Electric DAS-2420
- Page 1 In the scenario, when you want to watch your favorite action movie at night, and all your family members were sleep, you do not want to wake them up at this time, The DAS-2420 is the best solution. DAS-2420 deploy the 2.4GHz ISM band with frequency hopping and WiFi auto-detection scheme to provide crystal clear audio.
- Page 2 Connectors and control Power Switch Pairing Switch Audio Power Switch DC Power input Volume LED Lamp LED Lamp Volume Pairing Audio DC Power Switch Transmitter Receiver...
- Page 3 CAUTION Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Tx unit, another RL connector to the “Speaker out” or “line out” of your TV set Step3: Take out the AC/DC adaptor, plug the barrel end to the DC socket of DAS-2420, the AC blade end to your AC outlet, please be noted, DO NOT OVERLOAD YOUR AC OUTLET.
- Page 5 Via AC/DC Adaptor DC jacket Volume AC adaptor Step1: Take out the Rx unit Step2: Take out the AC/DC adaptor included Step3: Connect the DC barrel end to the DC socket of RX Step4: Connect the AC blade end to your AC outlet, please be noticed, DO NOT OVERLOAD YOUR AC Outlet Note: When you using AC/DC Adaptor, the power from batteries is cut.
- Page 6 Operation When All the connection are finished, you can start to use this wireless audio sender system as followed steps Step1: Power on the Tx (press the power switch on the Tx) Power Switch Step2: Power on the Rx unit via sliding the Power key on the RX unit Power Switch Earphone Earphone...
- Page 7 ADDING A NEW RX The DAS-2420 is designed to work with various Rxs, it can be configured to work with more than 16 Rxs (within the transmission distance). How to add a new Rx Step1: Power the Transmitter unit, press the power switch.
-
Page 8: Safety Notice
SAFETY NOTICE INDOOR USE ONLY. THIS DEVICE WITH WIRELESS RF SIGNAL RECEPTION,CONSULT YOUR DOCTOR IF YOU WEAR PACEMAKER. IF YOU GO OUT FOR MORE THAN 2 WEEKS, PLEASE TAKE THE BATTERIES OUT FROM YOUR RX UNIT. CLEAN WITH DRY AND SOFT CLOTH. DO NOT OPEN THE UNIT. - Page 9 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
