- Page 1 图纸编码 RD-SS9461-SM-01(SS-I) 版本号 SS9461SCM 英文说明书 编辑日期 2021/4/21 制作 刘丽萍 审核 白丹 批准 余泽松 物料编码 1320109407 备注 以 A4 样板打印...
- Page 2 NEPTUNE 300 BEAM USER MANUAL NEPTUNE 300 BEAM SS9461 MODEL: SS9461SCM...
-
Page 3: Technical Specifications
1 PRODUCT 1.1 TECHNICAL SPECIFICATIONS Type SS9461SCM LED colors 1 LED(CW) 200W Angle 2° Power 320W Control Protocol DMX512，RDM，ARTNET，sACN，W-DMX（Optional） Voltage Range AC100~240V,50/60Hz Input Current 110V/3A,220V/1.5A Protection IP65 Operation Temperature -20℃~45℃ Dimensions 411x280x603mm Weight 28kg... -
Page 4: Safety Notes
1.2 Safety Notes IMPORTANT ． ． ． ． ． ． ． ． ． This product must be installed by a qualified professional. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes ... - Page 5 Keep the product well away from flammable materials ． ． ． ． ． ． ．． ． ． ． ． ． ．． ． ． ． ． ． ． ． ． ． ． ．． ． ． ．． ． ． ． ．． ． ． ． ． ． ． ． ． ...
-
Page 6: Truss Installation
2 INSTALLATION 2.1 MOUNTING Truss installation ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． ． Keep all combustible materials (e.g. fabric, wood, paper) at least 500 mm (20 in.) away from the product. -
Page 7: Data Network Requirements
2.3 POWER CONNECTIONS This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz. POWER Linking: 2 units@110V；4 units@220V. 2.4 Data network requirements Connect the DMX512 controller to the units in series. A DMX 512 data link is required in order to control the fixture via DMX. -
Page 8: Functions And Settings
3 FUNCTIONS AND SETTINGS 3.1 DISPLAY OPERATION LEFT：Used to access the menu or to return a previous menu option; RIGHT：Used to select and store the current menu or confirm the current function value or option within a menu; ... - Page 9 Select OFF blackout without delay Default) BLACKOUT Select ON Blackout delay 3s DIM4 Default) Dimming curves OFF (fast) to DIM4 (slow)； DIMMER Sets the PWM frequency 1200Hz Default) 2400Hz LED PWM 4000Hz 6000Hz 25000Hz Hold after loss of DMX signal SAVE Default) DMX ERROR...
- Page 10 LED USE HOURS LED use time TEMPERATURE LED temperature VERSION Software versions NETWORK Check network parameter 0x388Axxxxxxxx Check fixture's ID LABEL NEPTUNE 300 BEAM Check fixture's LABEL MEMORY IC Memory IC SYSTEM ANGLESENSOR Angle Sensor ERROR PAN SENSOR Pan Sensor...
- Page 11 PAN ENCODER Pan Encoder PAN DRIVEIC Pan Drive IC TILT SENSOR Tilt Sensor TILT ENCODER Tilt Encoder TILT DRIVEIC Tilt Drive IC TEMPERATURE Temperature COLOR RESET Color reset GOBO RESET gobo reset RGOBO RESET Rgobo reset COLOR GOBO RESET Color gobo reset PRISM 1 RESET Prism 1 reset PRISM 2 RESET...
-
Page 12: Using A Dmx512 Controller
4 USING A DMX512 CONTROLLER 4.1 DMX CONTROL BASIC STANDARD Extend Value Function (13CH) (18CH) (19CH) CH.1 CH.1 CH.1 000-255 PAN 0-540° CH.2 CH.2 000-255 PAN FINE CH.2 CH.3 CH.3 000-255 TILT 0-270° CH.4 CH.4 000-255 TILT FINE CH.3 CH.5 CH.5 000-255 PT Speed... - Page 13 ROTATING GOBO 5 SHAKE (SPEED 1 —> 100%) 091-098 ROTATING GOBO 6 SHAKE (SPEED 1 —> 100%) 099-106 ROTATING GOBO 7 SHAKE (SPEED 1 —> 100%) 107-114 ROTATING GOBO 8 SHAKE (SPEED 1 —> 100%) 115-122 123-127 WHITE ROTATING GOBO FLOWING WATER EFFECT (SPEED 100 —> 1%) 128-190 191-192 STOP WATER EFFECT...
- Page 14 CH.11 CH.15 CH.16 000-255 DIMMER CH.16 CH.17 000-255 DIMMER FINE STROBE NO FUNCTION 10-99 STROBE（ FROM SLOW TO FAST） CH.12 CH.17 CH.18 100-109 NO FUNCTION 110-179 LIGHTNING STROBE 180-189 NO FUNCTION 190-255 RANDOM SROBE CONTROL 000-010 NO FUNCTION 011-020 PAN/TILT BLACK ACTIVATED 021-030 PAN/TILT BLACK DEACTIVATED 031-040...
