PARTS LIST
QTY
PART NUMBER
1
7201
HEX KEY
12
7213
CONNECTING BOLT
2
80000
BACK PANEL
1
80017L
SIDE PANEL
1
80017R
SIDE PANEL
2
80022
TOP/BOTTOM PANEL
1
80023
SHELF
CONNECTING BOLT
7213
Slots for back panels
TOP/BOTTOM PANEL
SHELF
TOP/BOTTOM PANEL
Item #VL1000/7147
DESCRIPTION
SHELF
80023
HEX KEY
7201
CAUTION: CHOKING HAZARD
Adult assembly required due to the
presence of small parts and sharp edges.
SIDE PANEL
80017L
TOP/BOTTOM PANEL
80022
CONNECTING BOLT
Lay out the parts as shown on a carpeted surface.
Assemble one side to the top panel, shelf and bottom panel
using the connecting bolts and hex key supplied. Be sure
the slots for the back panel are facing UP as you assemble
the panels to the side.
Dailey Industrial Park
Pacific, MO 63069
Questions? Please call:
1-800-346-6313
TOP/BOTTOM PANEL
80022
SIDE PANEL
9 Capper Drive
SIDE PANEL
80017R
