For service information call 800-544-3057
Please have the following information available before calling. Information can be found
on the identification/certification tag:
•Model Number
•Serial Number
•Date of Purchase
•Part Description and number as shown in parts list
This manual contains important safety information concerning the maintenance, use and operation of this product.
Failure to follow these instructions could result in damaging equipment, voiding the warranty, serious injury or even death.
BERKELEY SERIES HOTPLATES
SINGLE, DOUBLE OR TRIPLE HOTPLATES
Installation and Operating Manual
IMPORTANT INFORMATION
Piper Products, Inc
300 South 84th Avenue
Wausau, WI 54401
Phone: 715-842-2724 . FAX: 715-842-3125
READ BEFORE USE
Advertisement
Table of Contents
Summary of Contents for Piper BERKELEY Series
- Page 1 BERKELEY SERIES HOTPLATES SINGLE, DOUBLE OR TRIPLE HOTPLATES Installation and Operating Manual For service information call 800-544-3057 Please have the following information available before calling. Information can be found on the identification/certification tag: •Model Number •Serial Number •Date of Purchase •Part Description and number as shown in parts list...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION FREIGHT DAMAGE CLAIMS ELECTRICAL CONNECTION ELECTRICAL SPECIFICATIONS INSTALLATION OF DROP-IN HOTPLATES DROP-IN HOTPLATE FITTING DIAGRAM INSTALLATION OF BUILT-IN HOTPLATES BUILT-IN HOTPLATE FITTING DIAGRAM INSTALLATION OF PORTABLE HOTPLATES HOTSPOTS GLASS SNEEZE GUARDS USE AND OPERATION OF HOTPLATES CLEANING INSTRUCTIONS MAINTENANCE AND REPLACEMENT PARTS BUILT-IN EXPLODED VIEW... -
Page 4: Introduction
Congratulations! You have just purchased one of the finest pieces of equipment on the market today. Before installing or operating your new Piper equipment, you should read through this manual. This manual should be retained for further reference as it contains installation and operating instructions, service tips, part lists and warranty information. -
Page 5: Electrical Connection
ELECTRICAL CONNECTION WARNING!!!! DO NOT USE EXTENSION CORDS (VOIDS WARRANTY) Ground: The electrical outlet must be provided with an efficient ground, and the voltage and the frequency of the electrical line matches those indicated on the data plate. If unsure about the efficiency of the ground, have your electrical circuit checked by a qualified electrician. - Page 6 ELECTRICAL SPECIFICATIONS (cont.) BUILT-IN SERIES - EXTRA DEEP Overall Overall Hot Plate Weight Model Options Volts Phase Watts Amps NEMA # Length Depth Sections (lbs.) B17060 None 23.62” 27.56” 5-15P B27060 None 47.4” 27.56” 1700 6-15P B37060 None 71.18” 27.56” 1800 6-15P B17060-HS...
- Page 7 ELECTRICAL SPECIFICATIONS (cont.) DROP-IN SERIES - STANDARD DEPTH Overall Overall Hot Plate Weight Model Options Volts Phase Watts Amps NEMA # Length Depth Sections (lbs.) D14050 None 5-15P D16050 None 5-15P D24050 None 5-15P D26050 None 49-3/4 1200 10.0 5-15P D240160 None 57-7/8...
-
Page 8: Installation Of Drop-In Hotplates
1. Follow the dimensions for the correct size opening in the counter surface. Refer to spec sheet or contact Piper Support 2. Apply a bead of mastic all around the opening so the stainless steel flange will sit directly onto the mastic to ensure a heat proof and hygienic seal (illustration 1B). -
Page 9: Drop-In Hotplate Fitting Diagram
DROP-IN HOTPLATE FITTING DIAGRAM 25mm 6mm SCHOTT Ceran Pyroceramic Expansion Seal Mastic Seal Electric Decorative Top Elements Insulation Illustration 1A Bead of Recommended Mastic Illustration 1B... -
Page 10: Installation Of Built-In Hotplates
1. Follow the dimensions for the correct size opening in the counter surface. Refer to spec sheet or contact Piper Support 2. Position the unit from the underside of the counter work surface and ensure that the hotplate is properly centered. - Page 11 Illustration 2A Illustration 2B Smooth down using plastic card for instance Masking Tape Hotplate Counter Top Illustration 2C...
-
Page 12: Built-In Hotplate Fitting Diagram
BUILT-IN HOTPLATE FITTING DIAGRAM 3-5mm Expansion Seal 6mm Ceran Bonded to case Counter Top Fully Insulated 70mm Heater Box Wood/Ply Base Adjustable Bracket Level Adjuster/ Access Panel Fixing Bracket TILED, LAMINATE, OR STONE COUNTER TOP 3-5mm Expansion Seal 6mm Ceran Stainless Steel Bonded to case Counter Top... - Page 13 Example Built-In Hot Plate Size. See Technical Sheet for Details. Example Hot Plate Cutout Size. See Technical Sheet for B + 8mm Details. A + 8mm...
-
Page 14: Installation Of Portable Hotplates
INSTALLATION OF PORTABLE HOTPLATES WHEN CONNECTING PORTABLE HOTPLATES TO AN ELECTRICAL SUPPLY THEY MUST CONFORM TO THE ELECTRICAL REGULATIONS OF THAT LOCATION As these models are portable, no special installation requirements are needed apart from the electrical details above. When setting it in place, be sure the unit is positioned on a stable and heatproof surface and at a height suitable for safe operation. -
Page 15: Use And Operation Of Hotplates
USE AND OPERATION OF HOTPLATES Each hotplate surface is individually controlled by a simmerstat/infinite controller. Preheat the unit by selecting full power for 20 minutes prior to placing any containers of food on the hotplate. This will bring the temperature of the hotplate to approximately 250˚F (120˚C). -
Page 16: Cleaning Instructions
CLEANING INSTRUCTIONS PYROCERAMIC HOTPLATES STOVE ENAMELLED BODY AND OHD STAINLESS STEEL GANTRIES CERAMIC HOTPLATES The following cleaners were successfully tested and approved by Schott for Ceran cooking surfaces. • Elco Cook Top Cleaning Crème • Golden Ventures Cerama Bryte • Hopes Cooktop Cleaning Crème To keep your surface looking good and easy to use for a long time to come, follow these hints and tips: •... - Page 17 CLEANING (cont.) DO NOT use abrasive sponges or scourers of any type. Corrosive cleaners such as oven sprays and stain removers and bleaches should also NOT BE USED. EPOXY COATED BODY (PORTABLE UNITS) • Use a damp cloth (mildly soapy) to remove any residue stains or a recommended stove enamel cleaner.
-
Page 18: Maintenance And Replacement Parts
MAINTENANCE AND REPLACEMENT PARTS WARNING: SWITCH UNIT OFF AND DISCONNECT FROM THE ELECTRICAL SUPPLY BEFORE CARRYING OUT ANY OF THE FOLLOWING. IT IS HIGHLY RECOMMENDED THAT ALL PROCEDURES BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN Ceran GLASS AND HEATER MAT •... - Page 19 MAINTENANCE AND REPLACEMENT PARTS (cont.) WARNING: SWITCH UNIT OFF AND DISCONNECT FROM THE ELECTRICAL SUPPLY BEFORE CARRYING OUT ANY OF THE FOLLOWING. IT IS HIGHLY RECOMMENDED THAT ALL PROCEDURES BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN TOGGLE/ROCKER/PUSH BUTTON ON/OFF SWITCH •...
-
Page 20: Built-In Exploded View
BUILT-IN EXPLODED VIEW 6mm Thick Schott Pyroceramic Glass Self Adhesive Heater Mat. Wattage as per O&M Manual Monolux Heat Resistant Board Adjustable Angle Supports and Sides 304 Grade Stainless Steel Case Stainless Steel Removable Base Plate Controller (3 switch shown) Comes with 2 meters of cable... -
Page 21: Drop-In Exploded View
DROP-IN EXPLODED VIEW 6mm Thick Schott Pyroceramic Glass Self Adhesive Heater Mat. Wattage as per O&M Manual Monolux Heat Resistant Board 25mm Stainless Steel Flange 304 Grade Stainless Steel Case Stainless Steel Removable Base Plate Controller (3 switch shown) Comes with 2 meters of cable... -
Page 22: Changing A Quartz Lamp
CHANGING A QUARTZ LAMP The quartz lights fitted are 375 Watts. They must only be changed when the counter is isolated from the electrical supply by a qualified technician. It is important not to touch the surface of the lights. They come wrapped in tissue paper and can be used to hold the lights in place. -
Page 23: Troubleshooting Guide
Was food placed on the unit at or above Does not maintain temperature Food Temperature 185°F? Infinite Control Is the Infinite Control set properly? Voltage Call a service technician. Call Piper Products directly at 800-544-3057 if you need further assistance. -
Page 24: Single Hotplate, 120V Wiring Diagram
SINGLE HOTPLATE, 120V WIRING DIAGRAM Heater Mat with Thermal Cutout light light toggle switch MAIN BLOCK... -
Page 25: Double Hotplate, 120V Wiring Diagram
DOUBLE HOTPLATE, 120V WIRING DIAGRAM Heater Mat Heater Mat with Thermal Cutout with Thermal Cutout light light light toggle switch MAIN BLOCK... -
Page 26: Double Hotplate, 208V/240V Wiring Diagram
DOUBLE HOTPLATE, 208V/240V WIRING DIAGRAM Heater Mat Heater Mat with Thermal Cutout with Thermal Cutout light light light toggle switch MAIN BLOCK... -
Page 27: Double Hotplate, 208V/240V With Hot Spot Wiring Diagram
DOUBLE HOTPLATE, 208V/240V WITH HOT SPOT WIRING DIAGRAM Heater Mat Heater Mat with Thermal Cutout with Thermal Cutout HOT PLATE light light light light toggle switch MAIN BLOCK... -
Page 28: Double Hotplate, With Heat Lamp 208V/240V Wiring Diagram
DOUBLE HOTPLATE WITH HEAT LAMP 208V/240V WIRING DIAGRAM Heater Mat Heater Mat with Thermal Cutout with Thermal Cutout light light Dimmer Switch light Fuse toggle switch MAIN BLOCK... -
Page 29: Triple Hotplate, 208V/240V Wiring Diagram
TRIPLE HOTPLATE, 208V/240V WIRING DIAGRAM Heater Mat Heater Mat Heater Mat with Thermal Cutout with Thermal Cutout with Thermal Cutout light light light light toggle switch MAIN BLOCK... - Page 30 Piper Products Service Department shall be final. Any defective parts to be repaired or replaced must be returned to Piper Products, Inc., 300 South 84th Avenue, Wausau, WI 54401, transportation charges prepaid, and they must be properly packed and tagged.
- Page 31 Piper Products, Inc 300 South 84th Avenue Wausau, WI 54401 Phone: 715-842-2724 . FAX: 715-842-3125...
